- Page 2 Use of this document and the subsequent results shall be entirely on the user’s own responsibility. Abetechs GmbH (Grundig Security) reserves the right to change the contents of this document without prior notice. Design and specifications are subject to change without prior notice.
- Page 3 OPEN SOURCE SOFTWARE LICENSE INFORMATION The software components provided with Grundig products may contain copyrighted software that is licensed under various open source software licenses. For detailed information about the...
- Page 4 The appearance of the products, functions and firmware or software upgrade may differ from this manual. GRUNDIG reserves the right to perform needed changes without prior notice. Safety Instructions Make sure that you only use the power adapter that is specified in the specifications sheet of the product.
- Page 5 Improper use or replacement of the battery may result in the hazard of explosion. Do not use any accessories that are not recommended by GRUNDIG. Do not modify the product in any way. If the product starts to smell or smoke comes out of the device, immediately stop using the product and disconnect it from the power supply to prevent fire or electric shocks.
- Page 6 Installation Instructions It is necessary to fix the device firmly if the product is installed on a wall or ceiling. Do not install the product on surfaces or in places that are vibrating. Do not install the product near radiation sources. Do not install the product near heat sources, like radiators or other equipment that produces some heat.
- Page 7 Do not apply any pressure to the monitor screen as the screen may break. Do not install the monitor in a location that is exposed to direct sunlight, dust, mechanical vibration or shock. Always place the monitor on a flat surface. Connect the power supply to the socket and plug the video cable or VGA cable to the desired signal source.
- Page 8 Do NOT use any liquid cleaners based on alcohol, methylated spirit or ammonia or aerosol cleaners, as this may damage any coating present on the glass surface of the monitor. Use only mild soap or detergent with water or special cleaners for cleaning glass panels.
- Page 9 Content 1 Connections ..................9 2 Installation ..................10 3 Operating ..................11...
- Page 10 1 Connections The overview of the connections is shown below. Figure 1-1 Overview of the connections...
- Page 11 2 Installation 1. Take out the monitor and other accessories. 2. Align the groove between the column and the base. 3. Press the column into the chassis groove. 4. Complete the installation of column and base. Figure 2.1 Base installation 5.
- Page 12 3 Operating Press the ON/OFF key to switch on the monitor. Open the local menu by pressing the Menu key. Select the functions with the B/C-keys. After entering the menu select the corresponding function with the B-/C-key and press the E-key to confirm your selection. With the D-key you will go back in the menu.
