Countertop Electric Griddles
TECG732467, TECG732470, TECG733667, TECG733670, TECG734867, TECG734870
Standard Features:
1/2" griddle plate
Adjustable temperature control
O
from 150 - 450
F
Thermostat with positive
"OFF" position
Stainless steel front, top an
sides, including top rail
Aluminized steel rear
4" steel legs
Stainless steel grease trough
3-1/2" rear and side splash guards
Griddle capacity is:
24", 36", 48" Wide
(7324, 7336, 7348) Wide
24" Long
Model Shown:
May ship UPS
Application
The Toastmaster Countertop Electric
Griddle is the most economical and
flexible Countertop Griddle in the
food service industry. It offers
unsurpassed performance,
combining a proven control system
with Toastmaster quality and
durability. Available in three different
sizes: 24", 36", and 48".
Heating:
Heating is accomplished by
performed tubular heating elements
that are pressure clamped to the
underside of the griddle surface. The
heaters are designed to provide
perimeter heat to assure even
heating.
Toastmaster
®
5600 13th Street, Menominee, MI 49858 • www.toastmastercorp.com
Toll Free: 1-800-338-9886 • Telephone: 1-906-863-4401 • Fax: 1-906-863-5889
TECG732467
Standard Features:
Stainless steel front, top and
sides, including top rail
Aluminized steel rear
4" steel legs
Griddle capacity is:
24", 36", 48" Wide x
24" depth to 7324, 7336, and
7348 respectively.
1/2" thick polished rolled steel
plate with 4" high rear and side
splash guards
Full width stainless steel grease
trough mounted at the front of
of the cooking surface
Griddle temperature controlled
by thermostat adjustable from
o
o
150
F to 450
F, with indicator
light per thermostat
Electrical:
All electrical connections are made
to terminal block in compartment at
rear. Knockouts located adjacent to
terminal block. Available 208/240V
AC 1-phase or 480V AC 3 phase.
Foodservice Equipment
Job
Item#
Construction:
Stainless steel front including top
rail, with aluminized steel rear and
sides. Full width stainless steel
grease trough and easy to access
1
grease drawer. 3-
/
" rear and side
2
splash guards.
Controls:
Temperatue is controlled by
thermostat adjustable from
o
o
150
F to 450
F with a positive
"OFF" position. A cycle light is
associated with each thermostat.
Warranty:
Product warranty includes one year
parts and labor. (USA only) Call
factory for warranty authorization.
Cleanability:
Full with stainless steel grease
trough mounted in front of the unit
Grease trough drains through
grease chutes into drawer type
receptacle.
