Digital Projection LIGHTNING 30-1080p Specifications

L I G H T N I N G 3 0 - 1 0 8 0 p • L I G H T N I N G 4 0 - 1 0 8 0 p • L I G H T N I N G 4 5 - 1 0 8 0 p • L I G H T N I N G 1 0 8 0 p U l t r a C o n t r a s t
P E R F O R M A N C E S P E C I F I C A T I O N S
Brightness (±10%)
30-1080p: 15,000 ANSI Lumens
40-1080p: 20,000 ANSI Lumens
45-1080p: 30,000 ANSI Lumens
Ultra Contrast: 10,000 ANSI Lumens
Contrast Ratio (±10%)
30-1080p: 2000:1
40-1080p: 2000:1
45-1080p: 2000:1
Ultra Contrast: 4000:1
Display Type
3 x .95" Darkchip 1080p DMD™ with
Fast Transit Pixels for smooth
greyscale and improved contrast
DMD Specification
1920 x 1080 pixels native, 12˚ tilt angle
Fill Factor
87%
Sealed Optics at DMD™ Interface
Protects DMD's™ from optical contamination
Source Compatibility
• Composite, s-video, and color difference
video standards
• RGB graphics standards up to 1920 x
1080
• DVI standards
• High definition RGB and color difference
standards
• High definition / standard definition serial
digital formats (SD/HD-SDI)
Video Processing
• Enhanced 7 point color correction
• Class leading Video de-interlacing/processing
of SD and HD sources using auto 3:2 and
2:2 extraction, ruggedized for editing
discontinuities
• Pixel-based motion adaptive interpolation
• User selectable preset, parametric
de-gamma and user downloadable
de-gamma
• Frame Delay: as low as 1 frame, source
dependant
• Auto mode selection - plug and play setup
Specifications subject to change without notice DP V4 09/09 ©2009 Digital Projection, Inc.
™DLP, Digital Light Processing and DMD are trademarks of Texas Instruments, Inc.
LIGHTNING Pro Series II
Network Connection
LAN via RJ 45, Wireless 802.11b,
full protocol feature set
Lamp Type
Proprietary xenon arc, bubble. Hyper-
cooled lamp module with directional-flow
reflector mask and radial heat exchanger.
Digital Hour meter.
Lamp Life (typical)
1
30 -1080p: 750 hours
40/45 -1080p: 500 hours
Lens Mount
Zoom: Motorized horizontal and vertical
lens shift, zoom and focus
Fixed: Manual Focus
Lens Shift (maximum)
Fixed 1.12 and Zoom Lenses:
• Vert: +0.7, -0.5 frame; Hor: ±0.1875 frame
0.67 Fixed lens:
• Vert: ±0.1 frame; Hor: ±0.1 frame
Lens Options
0.67 :1 fixed 1.87-2.56 :1 zoom
1.12 :1 fixed 2.56-4.16 :1 zoom
1.16- 1.49 :1 zoom 4.16-6.96 :1 zoom
1.39-1.87 :1 zoom 6.16-10.49 :1 zoom
• 1.12:1 Lenses include manual aperture
• High-contrast lenses available for 0.67:1
and all zoom lenses
Mechanical Mounting
Floor or ceiling, front or rear. Integrated
handles and rigging frame with pitch and
roll adjustments, flexible stacking/rigging
points. Rugged, stager tolerant chassis .
Orientation
360˚ front to back
±15˚ left to right
Weight (chassis only)
249 lbs (113 kg)
O v e r v i e w
Digital Projection International (DPI), Texas Instruments'
first DLP™ partner and the original innovator of the 3-chip
DLP™ projector, proudly introduces the LIGHTNING
30-1080p, 40-1080p, 45-1080p and 1080p Ultra Contrast.
These new Pro Series II projectors employ the latest in
dark metal, 3-chip DLP™ technology, and include DPI's
exceptional RapidRig™ staging and stacking hardware
with integrated pitch, roll and yaw adjustments. When
considered along with their 10,000-30,000 ANSI lumen
brightness and 2000:1 contrast performance, not to men-
tion the Ultra Contrast's 5000:1 contrast, the 30-1080p,
40-1080p, 45-1080p and 1080p Ultra Contrast are ideally
suited for the most challenging staging and large-venue
permanent installations in the world.
The LIGHTNING 1080p projectors also incorporate DPI's
Hyper-Cooled lamp module, one of our CoolTek innova-
tions. Engineered with a proprietary, directional-flow
reflector mask and radial heat exchanger, the Hyper-
Cooled module dramatically improves projector thermal
characteristics and extends reflector life and lumen
maintenance. In turn, these operating benefits provide a
significant reduction to the long-term cost of ownership,
while also enhancing component reliability.
Other key benefits of the LIGHTNING 1080p line include:
• DP's NextGen electronics with class leading video de-interlacing.
SD and HD sources are processed using auto 3:2 and 2:2
extraction
• Minimal video delay from input to screen - as low as 1 frame,
depending on source
• Sealed optics to protect DMD's and other focal plane compo-
nents from airborne contaminants
• Six user-selectable inputs including HDCP compliant DVI
• ColorMax calibration capabilities, including enhanced seven-
point color correction for broader color space and accurate color
alignment
• DP's CoolTek engineering, which delivers the highest lumen
performance with the lowest thermal (BTU) and noise level (dB)
output
• A range of precision optics with extended lens shift, compatible
with all TITAN and LIGHTNING sx+ and 1080p models
The LIGHTNING 30-1080p, 40-1080p, 45-1080p and
1080p Ultra Contrast Pro Series II projectors - ultra-pow-
erful display systems for major events and applications -
bring the precision of Digital Projection to every venue.
I N P U T C A P A B I L I T I E S
Type
Composite
S-Video
Component
Interlaced/Std def Y, Cr/Pr, Cb/Pb, S
Graphics
Progressive RGB/Progressive Interlaced
Hi def Y, Cr/Pr, Cb/PB
RGBHV (Progressive)
Digital RGB
Serial Digital
SD/HD-SDI (SMPTE 259M/292M)
Connector
Quantity
BNC 1
4-pin mini DIN
1
1
BNCx4
1
BNCx5
D sub (15-pin)
1
DVI 1
1
BNC
