Electro-Voice ETX-18SP Specifications

Electro-Voice | ETX-18SP
ETX-18SP
▪ 1800 W amplifier and 135 dB peak
▪ Single-knob DSP includes presets for multiple
configurations and top+sub combinations
(performance style, locations, and space)
▪ Loudspeaker system performance monitoring via
integrated LCD and front panel LED
▪ Includes DSP preset for true cardioid performance
▪ Enclosure includes removable casters and a combo
pole cup (insert and threaded) for use with the two-
way models
ETX-18SP from Electro-Voice is a powered subwoofer;
it can be used in a variety of portable and permanent
applications. The DSP (Digital Signal Processing)
menus offer extensive configurations, crossovers, true
cardioid presets, protection limiters, EQ mode, and a
lock out mode that prevents casual changes to the
system. Loudspeaker system performance is optimized
via an LCD screen. The front LED indicates power or
can be configured to indicate limit.
EV's FIR-Drive technology utilized the latest FIR (Finite
Impulse Response) filter technology to optimize
transducer linearity and advanced limiter algorithms
for independent peak and thermal transducer
protection. True cardioid DSP preset delivers true
cardioid response across all frequencies.
The enclosure is constructed out of 18-mm, 13-ply
birch plywood finished with EVCoat. Subwoofers
include professional-grade castors, and combination
pole mount receptacle for threaded and unthreaded
loudspeaker poles.
ETX Powered Loudspeakers combine EV-engineered
intelligent DSP, high-powered amplifiers and
high-efficiency transducers to deliver that legendary
EV sound and performance.
Technical specifications
Frequency Response (-3 dB):
Frequency Range (-10 dB):
Maximum SPL:
33 Hz – 150 Hz
1
28 Hz – 180 Hz
1
135 dB peak
2
Power Rating:
LF Transducer:
Low Pass Frequency:
Connectors:
Enclosure:
Grille:
Dimensions (H x W x D):
Dimensions (H x W x D):
without casters
Net Weight:
Shipping Weight:
Power Consumption:
1. Half space measurement using the music DSP preset
and 150 Hz low pass.
2. Maximum SPL is measured at 1 m using broadband
pink noise at maximum amplifier output.
3. Current rating is 1/8 power.
1800 W
DVX3180A 457 mm (18 in)
Adjustable: 80 Hz, 100 Hz, 120 Hz,
150 Hz
(2) XLR/TRS Combo Jack and (2)
XLR link Output
18 mm, 13-ply birch plywood with
EVCoat
16AWG steel with powdercoat
550 mm x 675 mm x 910 mm
(22 in x 27 in x 36 in)
550 mm x 675 mm x 777 mm
(22 in x 27 in x 31 in)
51.8 kg (114.2 lb)
58.9 kg (129.9 lb)
100 – 240 V~, 50 – 60 Hz, 1.6 –
0.8 A
3
