Operating Instructions
GB
English, 1
HAGL 51 P
HAGL 51 K
PLEASE PHONE US TO REGISTER YOUR APPLIANCE AND ACTIVATE YOUR PARTS GUARANTEE ON 08448 24 24 24
Contents
Installation Instructions,5-8
Grill, 12
Oven, 13
50cm Gas Cooker
GB

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HAGL 51 P and is the answer not in the manual?

Questions and answers

Related Manuals for Hotpoint HAGL 51 P

Summary of Contents for Hotpoint HAGL 51 P

  • Page 1: Table Of Contents

    Contents Introduction, 2-3 English, 1 For Your Safety, 4 Installation Instructions,5-8 Burner and Nozzle Specification, 8 Features, 9 HAGL 51 P Control Panel, 10 HAGL 51 K Hotplate, 11 Grill, 12 Oven, 13 Oven Cooking Chart, 14 Care and Cleaning, 15...

  • Page 2: Introduction

    Introduction Your new cooker is guaranteed and will give lasting To the Installer: Before installation, fill in the product details on the back service. cover of this book. The guarantee is only applicable if the cooker has The information can be found on the rating plate. been installed in accordance with the Installation Instructions.

  • Page 3: Electrical Connection

    Electrical connection Connect the Green & Yellow wire to terminal marked “E” or coloured Green or Green & Yellow. Connect the Brown wire to the terminal marked “L” or THE APPLIANCE MUST BE EARTHED coloured Red. Connect the Blue wire to the terminal marked “N” or Install a standardised plug corresponding to the load indicated coloured Black.

  • Page 4: For Your Safety

    For your Safety in or on the cooker, or in cabinets immediately above Please read the precautions below before using your cooker. or next to the cooker. NEVER fill a deep fat frying pan more than 1/3 full of oil, ALWAYS .
  • Page 5 Installation Installation of the cooker The appliance must only be installed by a competent For a correct installation of the cooker the following person. In the UK, CORGI registered installers precautions must be followed: undertake to work to safe and satisfactory standards. The height of the cooker can be adjusted by means of Before moving your cooker check that it is cool, and adjustable feet in the plinth (900mm - 915mm).
  • Page 6 Installation Moving the Cooker Connecting the gas supply To make the connection, a flexible hose should be used corresponding to the current gas regulations which are: • the hose must never be at any point in its lenght in contact with the “hot” parts of the cooker; •...
  • Page 7 Installation Take particular care handling the spark plug wires c) Minimum regulation of the hob burners: and the thermocouple pipes. • turn the tap to minimum; • Replace all the parts, following the steps described • remove the knob and adjust the regulation screw, above in the reverse order.

  • Page 8: Burner And Nozzle Specification

    On completion of the operation, replace the old rating sticker with one indicating the new type of gas used. This sticker is available from our Service Centres. HAGL 51 P Note HAGL 51 K Should the pressure of the gas used be different (or...

  • Page 9: Features

    Features HOB VENTILATION SLOTS 1900W 1900W 2600W 1000W CONTROL PANEL GRILL/MEAT PAN WITH REMOVABLE HANDLE AND WIRE FOOD SUPPORT MODEL & SERIAL GRILL/TOP OVEN NUMBER GRILL DOOR DOOR MAIN OVEN W I R E W O R K INNER GLASS SHELF SUPPORTS 'STAY CLEAN' PANEL...

  • Page 10: Control Panel

    Control Panel RIGHT RIGHT LEFT LEFT MAIN GRILL FRONT FRONT REAR REAR OVEN BURNER BURNER BURNER BURNER ELECTRONIC* INIECTION BUTTON Control Knobs for the gas burners • The position of the gas burner controlled by each one of the knobs is shown by a solid ring .

  • Page 11: Hotplate

    Hotplate The hotplate lid is fitted with a safety device which cuts or fat. off the gas supply to the hotplate burners unless the lid 2. Never leave oil or fat unattended during the heating is fully open. Do not use the safety device as a means or cooling period.

  • Page 12: Grill

    Grill GRILLING MUST BE DONE WITH THE GRILL DOOR Relighting‘ the burner OPEN. In the event of the burner flames being accidentally CONTROL KNOBS MAY BECOME HOT DURING extinguished, turn off the burner control and do not GRILLING. attempt to re-ignite the burner for at least one minute. CAUTION: ACCESSIBLE PARTS WILL BECOME HOT WHEN THE GRILL IS USED - CHILDREN SHOULD BE KEPT AWAY.

  • Page 13: Oven

    Oven The main oven is fitted with a safety device that will ROASTING OF LARGE POULTRY The maximum weight of poultry that can be cut off the gas supply to the burner if the flame has accommodated is 11.5kg (25 lbs) of suitable shape. been extinguished for any reason.

  • Page 14: Oven Cooking Chart

    Oven Cooking Chart The following times and setting are for guidance only. You may wish to alter the setting to give a result more to your satisfaction. When a different setting to that shown below is given in a recipe, the recipe instructions should be followed.

  • Page 15: Care And Cleaning

    Care and Cleaning Grill Remove the rod shelves and grill pan. Use a fine steel Remove the grill pan and the wire grid food support, wool soap pad to remove stubborn stains from the rod it is best to wash these items immediately after use to shelves, grill pan and the floor of the oven.

  • Page 16: Cooking Results Not Satisfactory

    Cooking Results Not Satisfactory? Problem Check Grilling Ensure that the grill pan is positioned centrally below Uneven cooking front to back the grill element. Fat splattering Ensure that the grill is not set to too high a temperature. Oven Baking Ensure that the oven shelves are level by using a spirit Uneven rising of cake level on the rod shelf and adjusting, using suitable...

  • Page 17: Something Wrong With Your Cooker

    Something Wrong with your Cooker? Before contacting your Service Centre or Installer, check the problem guide below, there may be nothing wrong with your cooker. Problem Check Ignition does not work If all burners fail to ignite: Check that sparks appear at the burners; A clicking noise should be heard.

  • Page 18: Disposal Of The Appliance

    Disposal of your product To minimise the risk of injury to children please dispose of your product carefully and safely. Remove all doors and lids. Remove the mains cable (where fitted) by cutting off flush with the appliance and always ensure that no plug is left in a condition where it could be connected to the electricity supply.

  • Page 19: Guarantee Information

    90 days of ownership. Simply call our Hotpoint Service Hotline on 08448 224 224 (ROI 0818 313 413) for telephone assistance, or, where necessary, to arrange for an engineer to call.

  • Page 20: Service Information

    XEROX FABRIANO 05/2013 - 195114732.00 After Sales Service No one is better placed to care for your Hotpoint appliance during the course of its working life than us - the manufacturer. Essential Contact Information Hotpoint Service We are the largest service team in the country offering you access to 400 skilled telephone advisors and 1100 fully qualified engineers on call to ensure you receive fast, reliable, local service.
