DUAL ROTOR RADIO
CONTROLLED MINI HELICOPTER
AssEMbLy AND OPERATION INsTRUCTIONs
RC transmitter has safety feature that will keep it from
transmitting to helicopter until left control stick is raised to top,
then dropped to bottom.
Power LED illuminates steadily to indicate transmitter ready.
Warranty voId IF damage caused by crasH.
Diagrams within this manual may not be drawn proportionally.
Due to continuing improvements, actual product may differ slightly from the product described herein.
Distributed exclusively by Harbor Freight Tools
Visit our website at: http://www.harborfreight.com
Read this material before using this product.
Failure to do so can result in serious injury.
SaVe THiS manual.
Copyright
of this manual or any artwork contained herein may be reproduced in any shape
or form without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
Model
Important!
3491 Mission Oaks Blvd., Camarillo, CA 93011
2006, 2007 by Harbor Freight Tools
©
Manual Revised 02/07
95125
. All rights reserved. No portion
®
.
®
