Harbor Freight Tools 95149 Assembly And Operating Instructions Manual

Radio-controlled fast charge airplane
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

RADIO-CONTROLLED FAST
CHARGE AIRPLANE
MODEL 95149
ASSEMBLY AND OPERATING INSTRUCTIONS
Due to continuing improvements, actual product may differ slightly from product described herein.
IF THE AIRPLANE SHOULD CRASH WHILE FLYING, THE WARRANTY IS VOIDED.
®
3491 Mission Oaks Blvd. Camarillo, CA 93011
Visit our Web site at http://www.harborfreight.com
®
Copyright© 2006 by Harbor Freight Tools
. All rights reserved. No portion of this
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions and replacement parts, please call 1-800-444-3353.
