RADIO CONTROLLED
BIPLANE
94840
Assembly & OPERATING INSTRUCTIONS
Important: If damage is caused due to a crash; your warranty is void.
Due to continuing improvement, actual product may differ slightly from product described herein.
®
3491 Mission Oaks Blvd., Camarillo, CA 93011
Visit our Web Site at www.harborfreight.com
©
®
Copyright
2006 by Harbor Freight Tools
. All rights reserved. No portion of this manual or
any artwork contained herein may be reproduced in any shape or form without the
express written consent of Harbor Freight Tools.
For technical questions and replacement parts please call 1-800-444-3353.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Harbor Freight Tools 94840
Summary of Contents for Harbor Freight Tools 94840
- Page 1 . All rights reserved. No portion of this manual or any artwork contained herein may be reproduced in any shape or form without the express written consent of Harbor Freight Tools. For technical questions and replacement parts please call 1-800-444-3353.
- Page 2 HANK YOU for choosing a HARBOR FREIGHT TOOLS product. For future reference, please complete the owner’s record below: Model______________ Serial No._____________ Purchase Date_______________ SAVE THE RECEIPT, WARRANTY AND THESE INSTRUCTIONS. It is important that you read the entire manual to become familiar with the unit BEFORE you begin assembly.
- Page 3 Store idle equipment. When not in use always lock up the Biplane and keep it out of the reach of children. Dress properly. Wear restrictive hair covering to contain long hair. Use eye protection. Always wear ANSI-approved impact safety goggles when using and assembling this product.
- Page 4 WARNING: The warnings, cautions, and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this product, but must be supplied by the operator.
- Page 5 Figure 4 Figure 3 LED readout Turn Control Charging Stick Jack On/Off Switch Battery Pack (4) Transmitter/Charger Unit (2) Climb Control Stick Operating the Radio Transmitter The Transmitter uses 8 “AA” batteries (not included). Remove the Battery Compartment Cover (12)-see Figure 4. Insert the batteries into the Battery Compartment making certain to line up the batteries with the polarity indicated in the Battery Compartment.
- Page 6 Operating and Flying the Biplane Preparing for Take-Off Choose a day when the wind is light. The ribbon attached to the Radio Transmitter antenna should be blowing slightly (not greater than 30 degrees) and not be blowing straight out. Find a wide-open field. Turn ON the Radio Transmitter.
- Page 7 Before each use check for loose screws, misalignment or binding of moving parts, cracked or broken parts, damaged housing, damaged wiring, loose wheels and any other condition that may affect its safe operation. If abnormal noise or vibration occurs, have the problem corrected before further use.
