- Page 1 USER MANUAL GUIDE D’UTILISATION BENUTZER INFORMATION...
- Page 2 english...
- Page 3 Welcome Thank you for choosing BionX™. It is our goal to provide you with the highest quality electric propulsion systems available, and offer you the best possible after sales experience. This document serves as a supplement to your bicycle user manual. Please read this manual thoroughly, even if you are an experienced cyclist.
-
Page 4: User Precautions
5. Make sure that the tires have the pressure recommended by the manufacturer before riding the bike. 6. Make sure that the brakes are operating properly before riding the bike. 7. Do not use a mobile phone or any other electronic devices while riding an electric bicycle; it is imperative that you pay attention to traffic. -
Page 5: Table Of Contents
Table of Contents User Precautions Description of the BionX SL Propulsion System Description of the BionX PL Propulsion System Inserting or Removing the Console Inserting or Removing the Battery Handling and Charging the Battery Power supply Chargers Assist Mode / Generate Mode /... -
Page 6: Description Of The Bionx Sl Propulsion System
Description of the BionX SL Propulsion System G2 Console Removable G2 console Illuminated LCD display with battery state-of-charge Remote throttle (where applicable) 48V Down Tube Battery Removable, lockable 48V Rear Rack Battery Removable, lockable... - Page 7 SL Motor Brushless, gearless Generate mode for energy recuperation Integrated torque sensor Brake switch A surface mounted reed switch and magnet – connected to the BionX console Power Supply...
-
Page 8: Description Of The Bionx Pl Propulsion System
Description of the BionX PL Propulsion System G2 Console (systems 2011 to present) Removable G2 console Illuminated LCD display with battery state-of-charge Remote throttle (where applicable) G1 Console (systems 2010 and earlier) Illuminated LCD display with battery state-of-charge 22, 26 or 37V Down Tube Battery... - Page 9 Generate mode for energy recuperation Integrated torque sensor Brake switch A surface mounted reed switch and magnet – connected to the BionX console 37V Single LED Battery Charger (PL systems 2011 to present) 22V, 26V or 37V Two LED Battery Charger...
-
Page 10: Inserting Or Removing The Console
Inserting or Removing the Console Inserting the console Slide the console into the console mount on the handlebar Removing the console Release the console by pushing the release lever on the console mount Slide the console out of the console mount... -
Page 11: Inserting Or Removing The Battery
Inserting or Removing the Battery Inserting the down tube battery Place the battery onto the docking station Slide the battery down the rail gently towards the connector The release arm will begin to move to the closed position as the battery slides towards the connector When the release arm is almost closed, hold it in place and simultaneously push in the lock cylinder –... -
Page 12: Handling And Charging The Battery
Handling and Charging the Battery WARNING BionX batteries shall only be recharged with BionX chargers or BionX power supplies. Never short circuit the battery by connecting the contacts of the battery. Never open the battery, as this could damage the battery and possibly lead to overheating. The battery cannot be serviced by the user. - Page 13 The battery can be charged when mounted on the bicycle or removed from the docking station. A Lithium Ion battery does not have a memory effect, which means that the battery’s maximum energy capacity is not affected if it is repeatedly recharged after only being partially discharged.
-
Page 14: Power Supply
The power supply is suitable for line voltage ranges of 110-115V or 220-230V, and com- pensates automatically. The 48V battery is designed to be charged by a 26V BionX power supply. The battery has an integrated charger which permits the use of a small, portable... -
Page 15: Chargers
2011 to present (single LED charger) Connect the charger and battery by inserting the charge connector into the charge port. The BionX system should be turned off Connect the charger to a power receptacle The light on the charger will turn red automatically... -
Page 16: Assist Mode / Generate Mode / Mountain Mode (Where Applicable)
Generate mode. In the Assistance mode, your pedaling is assisted proportionally by an electric motor that drives the rear wheel. A torque sensor is located on the axle of the BionX motor and measures the effort provided by the rider; this produces a natural feeling assistance from the motor. -
Page 17: Operating The Bionx Propulsion System
Operating the BionX Propulsion System G2 Console Power 7. Speedometer Cycle State-of-charge indicator 11. Wrench symbol Turn the system on Briefly push either top button on the console. The battery will beep 4 times and you will see a countdown, this is the system perfoming a self check. - Page 18 Turn on backlight and bicycle light (if applicable) Push and hold key for 4 seconds - display backlight turned on. Turn off backlight Push and hold key again for 4 seconds. Select the cycling computer functions Briefly push the Trip Distance...
-
Page 19: Operating The G2 Throttle
Generation 1-4: From press for more resistance for less resistance NOTE The G2 throttle is only compatible with the G2 console, and may not be available in all jurisdictions. Check with your local BionX dealer for local legislation and/or availability. -
Page 20: Programming The Basic Settings
Programming the Basic Settings In general, all settings of your BionX electric propulsion system are pre-set. Basic display functions can be set by entering the programming mode. Contact your dealer to customize the advanced functions of your system. Turn on the programming mode... -
Page 21: Removing And Installing The Rear Wheel
Removing and Installing the Rear Wheel We recommend the removal and installation of the rear wheel to be done by a qualified dealer. WARNING Always turn off the propulsion system prior to connecting or disconnecting the motor cables. CAUTION It is essential that the axle nuts are tightened to 40Nm (30lb-ft); this assures that the propulsion system functions properly. -
Page 22: Maintenance And Care
It must be ensured that no dirt or humidity penetrates the battery docking station when the battery is removed. The BionX motor does not require maintenance. -
Page 23: Cleaning
Make absolutely certain that the bike rack on your car is suitable for the increased weight and the unique frame style of your electric bicycle. A rack that is not suitable can be damaged or even break during the transport of the electric bicycle. The electric bicycle can be damaged by an unsuitable bike rack. -
Page 24: Troubleshooting
WARNING If you bypass the brake switch you also disable regenerative braking, in doing so your BionX system will not provide any additional braking. We recommend that you contact a dealer as soon as possible. The motor is not as powerful after a repair or service in the direction of 6 o’clock. -
Page 25: Warranty Information And Guarantee
BionX. 7. Costs for repair work performed in advance by persons who have not been authorized by BionX will not be reimbursed. In such a case, any warranty claim will cease. - Page 26 It excludes any claims as to the reimbursement of property damages, downtimes, expenses for renting or leasing equipment, travel expenses, lost profit or any other claims. BionX liability in connection with this warranty is limited to the respective acquisition value of the product.
- Page 27 BionX, BionX Design and powered by BionX are trademarks of BionX International Corporation. ©2012 BionX International Corporation. All Rights Reserved.
