Lorex CVC6997 Specifications

The CVC6997 bullet camera offers value-added performance
in an economical package. Ideal for any indoor or outdoor
application, the advanced features, including exceptional image
quality and 75 ft Infrared (low light) illumination, put this
camera in a class by itself.
Advanced 1/4" CCD Image Sensor with 250,000
I
effective pixels
62 IR LEDs provide illumination up to 75ft*
I
Weatherproof** Design (IP67) with Removable
I
sunshade ideal for outdoor installations
Color in the day, automatically switches to B/W at night
I
3.6mm wide angle lens
I
* IR illumination range of 75 ft. under ideal conditions. Objects at or beyond this
range may be partially or completely obscured, depending on the camera application.
** Not recommended for direct exposure to water, rain or snow.
CVC6997
STRATEGIC VISTA INTERNATIONAL INC.
300 Alden Road, Markham,
Ontario L3R 4C1
Canada
H O M E A N D B U S I N E S S S E C U R I T Y
DAY/NIGHT IR CAMERA
3700 Koppers Street, Suite 100
Baltimore, Maryland 21227,
USA
LONG RANGE COLOR
S P E C I F I C A T I O N S
Image Sensor
Effective Pixels
Scanning System
Resolution
Shutter Speed
S/N Ratio
Sync. System
Min. Illumination
White Balance
Video Output
Lens
Power Supply
Current Consumption
Operating Temp
Operating Humidity
Dimentions
88.5mm
(3.5")
As our product is subject to continuous improvement, SVII & subsidiaries
reserve the right to modify product design, specifications & prices without
UPC Code: 778597069976
1/4" Interline transfer type color CCD
512 H x 492 V (252k PIXELS)
525 Lines 2:1 Interlace
Horizontal 350 TV lines
1/60 ~ 1/10,000 sec
More than 48dB (AGC off)
Internal
1.0Lux (without LED)
AWB
VBS 1.0 Vp-p (75 ohms load)
Fixed Lens (3.6mm)
DC12V ±10% (Regulated)
100mA (without LED)/520mA (with LED)
14F to 113F (-10~45 degree C)
90% RH max.
107mm (4.2")
www.lorexcctv.com
©2005 Strategic Vista International Inc.
notice and without incurring any obligation. E&OE
