Lorex Professional CVC6993CL Specifications

F e a t u r e s
1/4" Color CCD provides excellent picture quality
ß
Waterproof Camera - Ideal for Outdoor and indoor applications
ß
High Resolution color camera during the day
ß
Picture automatically turns B&W in lower light conditions
Removable sunshade housing protects camera from weather elements
ß
12 LED emitters ideal for low light conditions
ß
Effective Night Vision range of 15 ft*
ß
Weatherproof rating: IP67**
ß
Camera Mounts easily to Walls or Ceilings
ß
Built-in 3.6mm Wide Angle Lens
ß
Includes 63 Ft. Cable, Versatile Mounting Bracket and Power Supply
ß
s p e C i F i C a t i o N s
Image Sensor: 1/4" Color CCD Image Sensor
Video Format: NTSC
H: 512, V: 492
Effective Pixels:
Resolution: 350 TV Line
Scan System: 2:1 Interlace
Sync System: Internal
S/N Ratio: More than 48dB
Iris: AES
1/60~1/10000 Sec
AES Shutter Speed:
0.1 Lux without IR LED, 0 Lux with IR LED
Mini Illumination:
Video Output: Composite 1.0Vpp @ 75 ohm
Lens/ Lens Mount: 3.6mm F 2.0/ Fixed
FOV (Diagonal): 70 degree
Termination: Video: BNC Female, Power: Barrel Female
IR LED/ Night Vision Range: 12 IR LED 850nm/ 4.5m
12Vdc
Power Requirement:
Less than 200mA @ 12Vdc
Power Consumption:
Operating Temp Range: -10°~45°C(14°~113°F)
Dimension: DIA: 65mm, L: 90mm with Sunshade
Unit Weight: 1.05 lbs (476g)
Environmental Rating: IP 67
* Under ideal conditions. Objects at or beyond may be partially or
completely obscured, depending on the camera application
** Not recommended for submersion in water
CVC6993Cl
Lorex Technology Inc.
300 Alden Road, Markham,
3700 Koppers Street, Suite 504
Ontario L3R 4C1
Baltimore, Maryland 21227,
Canada.
USA.
P r o f e s s i o n a l s e r i e s
Color seCurity Camera
p r o D u C t i N F o r m a t i o N
UPC:
Package Weight:
Package Dimensions:
Package Cube:
D i m e N s i o N s
As our product is subject to continuous improvement, Lorex Technology & subsidiaries reserve
the right to modify product design, specifications & prices without notice and without incurring
With Night VisioN
7-7859706993-8
5 lbs / 2.26799 kg
(W x H x D) 14.3" x 10.4" x 4.8"
363mm x 264mm x 121mm
0.413 inches
2.5in /
3.5in /
90mm
65mm
w w w . l o r e x c c t v . c o m
©2007 Lorex Technology Inc.
4.3in /
110mm
any obligation. E&OE
1-16022007
