Lorex CVC6997HR Quick Setup Manual

4. Camera Specifications
Specifications:
Image Sensor Hi-Res 1/3" Color CCD
Horizontal Res. 480 TV lines
# Effective Pixels 768 (H) x 494 (V) (380K)
Sync. System Internal Sync.
S/N Ratio >48dB (AGC Off)
Electronic Shutter 1/60 ~ 1/10,000 Sec.
Illumination 0 Lux / F 1.2 (LED on)
IR Distance 100 ft. / 30 m.
Lens Fixed 6.0 mm
Video Output 1.0Vp-p @ 75 ohms
LED 23 LED
IR LED Wavelength 850 nm
°
14 F ~ 113
Operating Temp
°
~ 45
(-10
Power Supply DC 12V ± 10% 600mA
Dimension 7.9" (H) x 6.9" (D)
200mm (H) x 175mm (D)
Dimensions:
It's all on the web
Product Information
User Manuals
Quick Start Guides
°
F
°C)
VISIT
www.lorexcctv.com
LOREX Technology Inc.
Copyright © 2006 LOREX Technology Inc. As our
products are subject to continuous improvement,
LOREX and its subsidiaries reserve the right to mod-
ify product design, specifications and prices, without
notice and without incurring any obligation. E&OE
Specification Sheets
Software Upgrades
Firmware Upgrades
H O M E & B U S I N E S S S E C U R I T Y
100FT/30M NIGHT VISION
HIGH RESOLUTION COLOR
BULLET CAMERA
Model: CVC6997HR
Quick Set-up Guide
