- Page 1 USER MANUAL VERSION V1.0 November 2010 EVO-TP4 Hardware System...
-
Page 2: Important Safety Instructions
Copyright 2010 November All Rights Reserved Manual Version 1.0 Part Number: 3LMPP4850210 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. - Page 3 CE MARK This device complies with the requirements of the EEC directive 2004/108/EC with regard to “Electromagnetic compatibility” and 2006/95/EC “Low Voltage Directive”. This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference.
- Page 4 LEGISLATION AND WEEE SYMBOL 2002/96/EC Waste Electrical and Electronic Equipment Directive on the treatment, collection, recycling and disposal of electric and electronic devices and their components. The crossed dust bin symbol on the device means that it should not be disposed of with other household wastes at the end of its working life.
- Page 5 Revision History Changes to the original user manual are listed below: Revision Description Date • Initial release 2010 Nov.
-
Page 6: Table Of Contents
Table of Contents 1. Packing List ......1 1-1. Standard Accessories ..........1 1-2. Optional Accessories ..........2 2. System View ......3 2-1. Front & Side View ............3 2-2. Rear View with stand ..........3 2-3. I/O Ports View ............4 2-4. System Dimension ...........4 3. - Page 7 4-4. Wall Mount Kit Installation ........12 4-5. Cable Cover Installation .........13 4-6. Cash Drawer Installation ........14 5. Specifications ......16 6. Jumper Setting ......17 6-1. For C48 Motherboard ..........17 6-1-1 Motherboard Layout ..........17 6-1-2. Connectors & Functions .......... 19 6-1-3 Jumper &...
- Page 8 The page is intentionally left blank. viii...
-
Page 9: Packing List
Packing List 1-1. Standard Accessories System (with stand) Driver bank Power adapter Power cord RJ45-DB9 cable (x3) -
Page 10: Optional Accessories
1-2. Optional Accessories MSR Module VFD Module (with RJ-45 cable) Second Display (with VGA cable) Wall Mount Kit Cable Cover... -
Page 11: System View
System View 2-1. Front & Side View Item No. Description Touch screen MSR module (optional) Rugged footprint Ventilation HDD door 2-2. Rear View with stand Item No. Description VFD dummy cover MSR dummy cover... -
Page 12: I/O Ports View
2-3. I/O Ports View f g h i j k Item No. Description Power Button 2nd VGA Parallel USB x 4 COM 1, 2, 3, 4 (from right to left) Line-out Mic-in Cash Drawer Power Switch DC-IN 2-4. System Dimension 361mm 248mm... -
Page 13: System Assembly & Disassembly
System Assembly & Disassembly 3-1. Stand Disassembly Loosen the thumb screw (x1) and slide the stand towards the IO panel to release it from the system. Reverse the steps above to attach stand to the system. 3-2. Power Adapter Replacement Power adapter is secured into the system stand by a holding bracket and screws. -
Page 14: Hdd Replacement
3-3. HDD Replacement For replacement, please remove the current HDD first. Romove the HDD from the System Power the system down. Remove the screw(x1) from the HDD door. Open the HDD door. While pinching the HDD bracket tabs pull the HDD from the system. -
Page 15: Open The System
To install a new HDD. Attach the HDD to the bracket until it clicks in place. Make sure to press the edges of the drive not the center to avoid damaging the drive. Finally slide the HDD into the slot till it clicks. -
Page 16: Ram Replacement
3-5. RAM Replacement Follow the steps in Chapter 3-4 to open the system. The RAM is located on the right side of the system (see picture). Installing a RAM module Slide the memory module into the memory slot and press down until it locks in place. -
Page 17: Peripheral Installation
Peripheral Installation 4-1. MSR Installation MSR module can be installed to either side of the system. Choose one side and follow the steps below. Remove the screws (x2) to release the MSR dummy cover. Connect MSR cable to the connector on system side. Insert MSR module in place and fasten the screws (x2) on the back to secure the module. -
Page 18: Vfd Installation
4-2. VFD Installation Follow steps in Chapter 3-1 to disassemble the system stand. Attach the VFD module to system by fastening the screws (x2). Route the cable through cable mangement on the system stand. Connect the RJ-45 cable to COM 4 on the systems IO panel. Make sure the system is powered off. -
Page 19: Second Display Installation
4-3. Second Display Installation Follow steps in Chapter 3-1 to disassemble the system stand. Connect one end of the VGA cable to 2nd Display. Route the cable through cable mangement on the system stand. Attach the 2nd Display to system by fastening the screws (x2). Connect the other end of the VGA cable to 2nd VGA port on system IO panel. -
Page 20: Wall Mount Kit Installation
4-4. Wall Mount Kit Installation The Wall Mount Kit includes a wall plate, a metal bracket, and one screw. (refer to Chapter 1-2 item e) Please follow the steps below for installation. Secure the wall plate to the wall by fastening screws (x4). -
Page 21: Cable Cover Installation
4. Fasten the screw (x1) through the metal bracket to secure the wall mount kit. 4-5. Cable Cover Installation There are two different cable covers. These can be utilized separately or togeth- er. When both are needed, please take care that they are installed in the correct order. -
Page 22: Cash Drawer Installation
4-6. Cash Drawer Installation You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Cash Drawer Pin Assignment Signal DOUT bit0 DIN bit0 12V / 19V DOUT bit1 Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer. - Page 23 Bit 7: Reserved Bit 6: Cash Drawer “DIN bit0” pin input status. = 1: the Cash Drawer closed or no Cash Drawer = 0: the Cash Drawer opened Bit 5: Reserved Bit 4: Reserved Bit 3: Cash Drawer “DOUT bit1” pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 2: Cash Drawer “DOUT bit0”...
-
Page 24: Specifications
Specifications Motherboard CPU Support Intel Pinevew D525 1.8G L2 1M, duo core Intel Atom N270 processor 1.6GHz L2 512K Chipset CPU with Graphic built-in + ICH 8M Intel 945GSE Express + ICH7M FSB 533MHz System Memory 2 x DDR3 DIMM up to 4GB FSB800Mhz 2 x DDRII SO-DIMM slot, up to 2GB Graphic Memory Shared system memory up to 256MB... -
Page 25: Jumper Setting
Jumper Setting 6-1. For C48 Motherboard 6-1-1. Motherboard Layout C48 V2.0 TOP LAYER... - Page 26 C48 V2.0 BOTTOM LAYER...
-
Page 27: Connectors & Functions
6-1-2. Connectors & Functions Connector Purpose Power Button Connector Printer Port Reset Printer Port CN5/8 HDD Power CN11 COM5 For Touch CN13 Card Reader Connector CN14 Line out CN15 HDD LED CN16 Speaker & MIC CN18 MIC IN CN20/JP10 System Indicator CN22 USB Port CN23... -
Page 28: Jumper & Bios/Utility Setting
6-1-3. Jumper & BIOS/Utility Setting COM2 RS232/485/422 Setting Function 1 3 5 7 9 5 7 9 11 ▲RS232 6 8 10 6 8 10 12 5 7 9 5 7 9 RS485 8 10 8 10 5 7 9 5 7 9 11 RS422 8 10... - Page 29 System Indicator Function JP10 ▲Disable Enable Inverter Selection Function JP14 ▲ CCFL CMOS Operation Mode CMOS Reset To clear the CMOS, 1. Remove the power cable from the system. 2. Open the system, and set the ‘CMOS Operation jumper’ from ‘CMOS Normal’ to ‘CMOS Reset’.
- Page 30 COM3 & COM4 Power Setting For C48, COM3/COM4 power adjustment must be made by BIOS/Utility and Jumper. Since COM3/COM4 default is “None“ meaning no power, power must be on through BIOS prior to physical jumper change. BIOS/Utility setup Press <DEL> key to enter BIOS SETUP UTILITY when system boot up.
- Page 31 LCD ID Setting Several configurations are applied to different sizes of panel. Please refer to the followings to complete relevant settings. • Jumper Setup LVDS Resolution Output Interface Bits Channel 800 x 600 Single 1024 x 768 Single 1366 x 768 Single 1st: LCD Panel 2nd: VGA port...
- Page 32 4. To switch on the power, select "+12V". Please save the change before exiting BIOS to avoid data lost. • Intel Graphics Driver Setting Right click Desktop. Find "Graphics Properties" and enter the manu. 2. Make sure the Display Device is same as follows.
-
Page 33: For B68 Motherboard
6-2. For B68 Motherboard 6-2-1. Motherboard Layout Version: B68 v1.0... -
Page 34: Connectors & Functions
6-2-2. Connectors & Functions Connector Purpose BAT1 CMOS Battery Base ( Use CR2023) Power On Button Power LED SATA1 HDD Power Connector SATA2 HDD Power Connector LCD Interface Connector For External Touch Connector Inverter Connector CN10 Card Reader Connector CN12 CN14 Speaker &... -
Page 35: Jumper Setting
6-2-3. Jumper Setting COM2 RS232/485/422 Setting Function 5 7 9 5 7 9 11 ▲RS232 6 8 10 6 8 10 12 5 7 9 5 7 9 RS485 8 10 8 10 5 7 9 5 7 9 11 RS422 8 10 COM3 &... - Page 36 Cash Drawer Power Setting Function JP11 +12V ▲+19V (for 24V Cash Drawer) Power Mode Setting Function ▲ATX Power AT Power VGA Power Setting Function ▲No Power +12V System Reset Function JP12 ▲System Normal System Reset ▲ = Manufacturer Default Setting...
- Page 37 LCD ID Setting LVDS Output Panel# Resolution Interface Bits Channel LVDS 1366 x 768 Single Panel LVDS 1440 x 900 Dual Panel LVDS 1920 x 1080 Dual Panel LVDS 1024 x 768 Single Panel LVDS 1280 x 1024 Dual Panel LVDS 800 x 600 Single...
-
Page 38: Appendix: Drivers Installation
Appendix: Drivers Installation The shipping package includes a Driver CD in which you can find every individual driver and utility that enables you to install the drivers on the system. Please insert the Driver CD into the drive and double click on the “index.htm” to select the models.
