Use Only. This brewer has an attached, 3-prong grounded cord set and requires 2-wire service with ground, rated 120 volts AC, 7½ amps (NHBX), 7 amps (STX), single phase, 60 Hz. NHBX model 900-watts total, STX model 850-watts total. Dimensions and weight NHB - 13 ”...
Welcome Thank you for purchasing a BUNN home brewer. BUNN home brewers are uniquely designed to do exactly what BUNN commercial brewers do: give you great-tasting coffee – quickly, simply and consistently. Table of Contents Important Safeguards ......................2 General Information ......................3 Hot Water ...........................3...
IMPORTANT SAFEGUARDS Follow these basic safety precautions when using electrical appliances to reduce the risk of fire, electric shock, and/or personal injury: Allow to cool before putting on or taking off parts, and before cleaning. or is damaged in any manner. Return the brewer to an Authorized Service Facility for cleaning, as specified in this manual.
(when you’re facing the brewer). Press I to turn on and O to turn off. On the STX, it is on the lower back of the brewer. To turn it on, press in the top of the switch (I) and to turn off press in the bottom (O). The red power light on the right front of the STX trunk will be illuminated when the power is on.
5. Now, plug in the brewer. 6. Press the vacation switch, located on the side (NHBX) or the back (STX) of the brewer, to turn unit on (Press I to turn on and press O to turn off.) Wait 15 minutes for the water in the tank to heat.
Do not touch hot grounds. 30 seconds. Empty before brewing coffee into carafe. BUNN filters are unique. Made with a special grade of paper for best coffee flavor, our filters are designed for strength, so the sides are taller and you don’t end up with overflow and grounds...
With most coffee makers, water drips straight through without evenly Use of decaffeinated, fine grind coffee and/or softened water may cause an overflow of grounds into your decanter. Visit www.bunn.com or call BUNN Customer Service at 800-352-2866 to order a flow restrictor sprayhead free of charge.
Page 9
Make sure to clean your decanter every day. Pre-heat the thermal carafe with hot water for best results. Use only BUNN paper filters for proper fit and function. Using a shorter filter may result in overflow. Dispose of filter and grounds immediately after brewing to prevent drip-through of unwanted flavors trapped in used coffee grounds.
6. Plug in the brewer and allow the water in the tank to reheat before using PERIODIC CLEANING You should clean your BUNN brewer at least every 3 months. The frequency of cleaning depends on the mineral content of your water.
While cleaning your brewer, don’t forget to check your glass decanter handle. If loose, use a standard screwdriver to tighten. brew through valve THERMAL CARAFE ROUTINE CLEANING (STX MODEL) The carafe may be disassembled for cleaning. Rotate the lid counterclockwise to remove. Occasionally, the brew through valve should be removed and cleaned.
DRAINING YOUR BREWER The water in your BUNN coffee brewer should be emptied whenever it is taken on a trip, shipped, stored in an unheated location with a chance of freezing, or goes unused for a 1. Unplug the brewer. Remove the brew funnel and sprayhead from the brewer and set them aside.
Troubleshooting Suggestions Problem Coffee not coming out be refilled. See initial set up on page 4. instructions (step 5) on page 8. Brewed only partial refilled. See initial set up on page 4. decanter and filter. You may need to adjust water input accordingly.
LIMITED WARRANTY time of manufacture and appearing within one of the following warranty periods: a) Three (3) years from the date of original purchase of a NEW BREWER. b) The later of three (3) years from the date of original purchase or one (1) year from the date REPAIRED OR REPLACEMENT BREWER is received by the customer c) One (1) year from the date REPAIRED OR REPLACEMENT BREWER is received by d) One (1) year from the date of purchase of a REMANUFACTURED BREWER.
Page 15
Bunn-O-Matic Corporation 1400 Stevenson Drive Springfield, IL 62703 USA 1-800-352-BUNN (2866) www.bunn.com...
