GENERAL
Display:
Data Entry:
Stored Settings:
Size:
Weight:
Power:
Operating Range:
Storage Range:
Environmental:
Options:
Safety:
EMC:
20 character x 4 row alphanumeric LCD.
Keyboard selection of mode, waveform etc.; value entry direct by
numeric keys or by rotary control.
Up to 9 complete instrument set−ups may be stored and recalled
from battery−backed memory. Up to 100 arbitrary waveforms can
also be stored independent of the instrument settings.
3U (130mm) height; 350mm width (2 and 4 channels),
212mm (½−rack) single channel; 335mm long.
7.2 kg. (16 lb), 2 and 4 channels; 4.1kg (9lb) 1 channel.
230V, 115V or 100V nominal 50/60Hz, adjustable internally;
operating range ±14% of nominal; 100VA max. for 4 channels,
75VA max. for 2 channel, 40VA max. for 1 channel. Installation
Category II.
+5°C to 40°C, 20−80% RH.
−20°C to + 60°C.
Indoor use at altitudes up to 2000m, Pollution Degree 2.
19 inch rack mounting kit.
Complies with EN61010−1.
Complies with EN50081−1 and EN50082−1.
