Summary of Contents for InFocus sp8600hd3d
- Page 2 Adobe Systems Incorporated. DLP®, DLP Link and the DLP logo are registered trademarks of Texas Instruments and BrilliantColor™ is a trademark of Texas Instruments. InFocus, In Focus, and INFOCUS (stylized) are either registered trademarks or trademarks of InFocus Corporation in the United States and other countries.
- Page 3 General Safety Information Do not open the unit case. Aside from the projection lamp, there are no user-serviceable parts in the unit. For servicing, contact InFocus at www.infocus.com/support Follow all warnings and cautions in this manual and on the unit case.
- Page 4 Preface Projector Installation Notice Place the projector in a horizontal position The tilt angle of the projector should not exceed 15 degrees, nor should the projector be in- stalled in any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically, and may lead to other unpredictable damages.
- Page 5 SP8600HD3D/IN8601 User’s Manual Power Safety Only use the supplied power cord. Do not place anything on the power cord. Place the power cord where it will not be in the way of foot traffic. Remove the batteries from the remote control when storing or not in use for a prolonged period.
-
Page 6: Table Of Contents
Preface Table of Contents GETTING STARTED................................1 ................................1 ACKING HECKLIST ............................... 2 IEWS OF ROJECTOR ARTS Front-right View ................................2 Top view—On-screen Display (OSD) buttons and LEDs..................3 Rear view..................................4 Bottom view................................... 5 ..............................6 EMOTE ONTROL ARTS SETUP AND OPERATION.............................. - Page 7 SP8600HD3D/IN8601 User’s Manual ................................ 39 IMING ABLE ..............................42 ROJECTOR IMENSIONS REGULATORY COMPLIANCE............................43 FCC W .................................. 43 ARNING .................................... 43 ANADA WEEE ....................................43 ..............................43 AFETY ERTIFICATIONS RS-232C P ................................44 ROTOCOL — vi —...
-
Page 8: Getting Started
Preface ETTING TARTED Packing Checklist Carefully unpack the projector and check that the following items are included: DLP P ROJECTOR CD-ROM EMOTE CONTROL CABLE ’ ATTERIES NOT INCLUDED S MANUAL & W OWER CORD AFETY ARRANTY OOKLET UICK TART UIDE VARIES PER COUNTRY Contact your dealer immediately if any items are missing, appear damaged, or if the unit does not work. -
Page 9: Views Of Projector Parts
SP8600HD3D/IN8601 User’s Manual Views of Projector Parts Front-right View ABEL ESCRIPTION EE PAGE Elevator button Push to release elevator foot Elevator foot Adjusts level of projector Lens Projection Lens IR receiver Receives the remote control IR signal Focus ring Focuses the projected image... -
Page 10: Top View-On-Screen Display (Osd) Buttons And Leds
Preface Top view—On-screen Display (OSD) buttons and LEDs Menu Enter ABEL ESCRIPTION EE PAGE Solid Power On / Standby Green Power LED Power Off (AC Off) Solid Red The lamp is powered on. Lamp LED Flashing The lamp is warming up or cooling down. (see LED Error Messages on page 33) Temp LED Solid Red... -
Page 11: Rear View
SP8600HD3D/IN8601 User’s Manual Rear view ABEL ESCRIPTION EE PAGE AC IN Connect the POWER CABLE. COMPONENT Connect the COMPONENT CABLE from a display. COMPOSITE Connect the COMPOSITE CABLE from a video device. Connect the RGB CABLE from a computer. HDMI – 1 Connect the HDMI CABLE from an HDMI device. -
Page 12: Bottom View
EE PAGE Leveling foot Rotate leveling foot to adjust angle position. Only use with an InFocus ceiling mount system (p/n PRJ-MNT-UNIV). Ceiling support holes See your InFocus dealer or go to www.infocusstore.com. Elevator foot drops down when elevator button is Elevator foot pushed. -
Page 13: Remote Control Parts
SP8600HD3D/IN8601 User’s Manual Remote Control Parts Important: 1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency fluo- rescent lights can disrupt remote control operation. 2. Be sure nothing obstructs the path between the remote control and the projector. If the path be- tween the remote control and the projector is obstructed, you can bounce the signal off certain reflective surfaces such as projector screens. - Page 14 Preface ABEL ESCRIPTION EE PAGE Power ON Turn the projector on. LED indicator Only lights when the remote keys are pressed. Display Mode Choose a suitable preset mode for usage environment. Contrast Display the Contrast setting bar and use the right and left keys to adjust. Display the Brightness setting bar and use the right and left keys to ad- Brightness just.
-
Page 15: Setup And Operation
SP8600HD3D/IN8601 User’s Manual ETUP AND PERATION Inserting the Remote Control Batteries Remove the battery compartment cover by sliding the cover in the di- rection of the arrow. Insert the batteries (not included) as shown in the illustration. Replace the cover. -
Page 16: Starting And Shutting Down The Projector
Preface Starting and Shutting down the Projector Connect the power cord to the pro- jector. Connect the other end to a wall outlet. POWER LED will be on. Turn on the connected devices. Ensure the POWER LED dis- plays a solid green. Then press the Power ON button on the projector keypad or remote ( The projector splash screen displays... -
Page 17: Adjusting The Projector Level
SP8600HD3D/IN8601 User’s Manual Adjusting the Projector Level Take note of the following when setting up the projector: • The projector table or stand should be level and sturdy. • Position the projector so that it is perpendicular to the screen. -
Page 18: Adjusting The Zoom Ring, Focus And Keystone
Preface Adjusting the Zoom ring, Focus and Keystone Use the Zoom control (on the projector only) to resize the projected image and screen size Use the Focus control (on the projector only) to sharpen the pro- jected image Use the KEYSTONE buttons (on the projec- tor or the remote control) to correct im-... -
Page 19: Adjusting The Volume
SP8600HD3D/IN8601 User’s Manual Adjusting the Volume Press the Volume but- tons (on the projector or the remote control). The volume control appears on the display. Use the Vol +/- buttons (on the projector or the remote control). Press the MUTE button... -
Page 20: On-Screen Display (Osd) Menu Settings
Preface (OSD) M CREEN ISPLAY ETTINGS OSD Menu Controls The projector has an OSD that lets you make image adjustments and change various settings. Navigating the OSD You can use the remote control cursor buttons or the projector keypad to navigate and make changes to the OSD. -
Page 21: Setting The Osd Language
SP8600HD3D/IN8601 User’s Manual Setting the OSD Language Set the OSD language to your preference before continuing. 1. Press the MENU button. Press the cursor ◄► button to navigate to SETUP>>Basic. 2. Press the cursor ▲▼ button until Language is highlighted. -
Page 22: Osd Menu Overview
Preface OSD Menu Overview Use the following illustration to quickly find a setting or determine the range for a setting. – 15 –... -
Page 23: Picture>>Basic Menu
SP8600HD3D/IN8601 User’s Manual PICTURE>>Basic Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the PICTURE>>Basic menu. Press the cursor ▲▼ button to move up and down in the PICTURE>>Basic menu. Press ◄► to change values for settings. -
Page 24: Picture>>Advanced Menu
Preface PICTURE>>Advanced Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the PICTURE>>Advanced menu. Press the cursor ▲▼ button to move up and down in the PICTURE>>Advanced menu. Press ◄► to change values for settings. ESCRIPTION Noise Reduction Press the cursor ◄►... -
Page 25: Hsg Adjustment
SP8600HD3D/IN8601 User’s Manual HSG Adjustment Press the ENTER/SELECT button to enter the HSG Adjustment sub menu. ESCRIPTION Press the ◄► buttons to set the Primary Color. Primary Color Notes: There are six colors (R/ G/ B/ C/ M/ Y) to be customized. -
Page 26: Display Menu
Preface DISPLAY Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the DISPLAY menu. Press the cursor ▲▼ button to move up and down in the DISPLAY menu. Press ◄► to change values for settings. ESCRIPTION Press the cursor ◄►... -
Page 27: Pc Detail Adjustment
SP8600HD3D/IN8601 User’s Manual PC Detail Adjustment Press the ENTER/SELECT button to enter the PC Detail Adjustment sub menu. Note: Customizing the settings in PC Detail Adjustment menu is only available when PC input source (analog RGB) is selected. ESCRIPTION Press the RE-SYNC button on the projector keypad or the AUTO IMAGE button on Auto the remote control to automatically adjust frequency, phase, and position. -
Page 28: 3D Settings
Preface 3D Settings ESCRIPTION 3D mode Press the cursor ◄► button to to enable or disable 3D Mode. 2D to 3D mode Press the cursor ◄► button to enable or disable 2D to 3D mode. Press the cursor ◄► button to select 96Hz or 120Hz when a 1080p 24Hz "Frame 3D Type Packing"... -
Page 29: Setup>>Basic Menu
SP8600HD3D/IN8601 User’s Manual SETUP>>Basic Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the SETUP>>Basic menu. Press the cursor ▲▼ button to move up and down in the SETUP>>Basic menu. Press ◄► to change values for settings. -
Page 30: Menu Settings
Preface Menu Settings Press the ENTER/SELECT button to enter the Menu Settings sub menu. ESCRIPTION Press the ◄► buttons to select from five OSD locations: Menu Position Top-Left/ Top-Right/ Center/ Bottom-Left/ Bottom-Right. Press the ◄► buttons to set the Menu Display timer before the OSD times out. Menu Display Time (Range: 5sec/ 10sec/ 15sec/ 20sec/ 25sec/ 30sec) Source... -
Page 31: Setup>>Advanced Menu
SP8600HD3D/IN8601 User’s Manual SETUP>>Advanced Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the SETUP>>Advanced menu. Press the cursor ▲▼ button to move up and down in the SETUP>>Advanced menu. ESCRIPTION Press the ENTER/SELECT button to enter the Audio sub menu. -
Page 32: Audio
Preface Audio Press the ENTER/SELECT button to enter the Audio sub menu. ESCRIPTION Volume Press the ◄► buttons to adjust the audio Volume. Treble Press the ◄► buttons to adjust the audio Treble. Bass Press the ◄► buttons to adjust the audio Bass. Mute Press the ◄►... -
Page 33: Closed Caption
SP8600HD3D/IN8601 User’s Manual Closed Caption Press the ENTER/SELECT button to enter the Closed Caption sub menu. ESCRIPTION Closed Caption En- Press the ◄► buttons to turn on or off Closed Caption. able Caption Version Press the ◄► buttons to select the Caption Version. -
Page 34: Status Menu
Preface STATUS Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the STATUS Menu. ESCRIPTION Display Mode Displays the current display mode. Aspect Displays the current aspect ratio setting. Source Displays the activated input source. Resolution Displays the native resolution of input source. -
Page 35: Maintenance And Security
ECURITY Replacing the Projection Lamp The projection lamp should be replaced when it burns out. Be sure to use the InFocus lamp module de- signed for this projector. You can order new lamps from www.infocusstore.com (in select areas), your retailer or your dealer. Only genuine InFocus lamps are tested for use in this projector. Use of non InFo- cus lamps may cause electrical shock and fire, and may void the projector warranty. - Page 36 Preface Remove the single screw on the lamp compartment cover, using a small Philips screwdriver. Remove the lamp com- partment cover. Remove the three screws , using from the lamp module a small Philips screwdriver Lift the module handle up. –...
- Page 37 SP8600HD3D/IN8601 User’s Manual Pull firmly on the module handle to remove the lamp module. Reverse steps 1 to 6 to in- stall the new lamp module. While installing, align the lamp module with the connector and ensure it is level to avoid damage.
-
Page 38: Cleaning The Projector
Preface Cleaning the Projector Cleaning the projector to remove dust and grime will help ensure trouble-free operation. Warning: 1. Be sure to turn off and unplug the projector at least 60 minutes before cleaning. Failure to do so could result in a severe burn. 2. -
Page 39: Troubleshooting
SP8600HD3D/IN8601 User’s Manual ROUBLESHOOTING Common Problems and Solutions These guidelines provide tips to deal with problems you may encounter while using the projector. If the problem remains unsolved, contact your dealer for assistance. Often after time spent troubleshooting, the problem is traced to something as simple as a loose con- nection. -
Page 40: Led Error Messages
In the event of an error, please disconnect the AC power cord and wait for one (1) minute before re- starting the projector. If the POWER or LAMP LEDs are still blinking or the TEMP LED is lit, contact InFocus Technical Support at www.infocus.com/support. Image Problems Problem: No image appears on the screen 1. -
Page 41: Lamp Problems
SP8600HD3D/IN8601 User’s Manual 1. Set the Frequency and Phase settings on the Display >> PC Detail Adjustment menu of the OSD to the default settings. 2. To ensure the problem is not caused by a connected PC’s video card, connect to another computer. -
Page 42: Audio Problems
3. Have the projector serviced. Having the Projector Serviced If you are unable to solve the problem contact InFocus Technical Support at www.infocus.com/support. If your projector needs repair, pack the projector in the original carton and include the return authorization number on the outside of the box. -
Page 43: Hdmi Q & A
SP8600HD3D/IN8601 User’s Manual HDMI Q & A Q. What is the difference between a “Standard” HDMI cable and a “High-Speed” HDMI cable? Recently, HDMI Licensing, LLC announced that cables would be tested as Standard or High- Speed cables. ˙Standard (or “category 1”) HDMI cables have been tested to perform at speeds of 75Mhz or up to 2.25Gbps, which is the equivalent of a 720p/1080i signal. -
Page 44: Specifications
Preface PECIFICATIONS Specifications SP8600HD3D/IN8601 Model TI DLP DMD 0.65” Display type 1920 x 1080 Native Resolution 1 meters ~ 10 meters ( 3.28 ft ~ 32.8 ft ) Projection distance 23.5" ~ 300" ( 59.7cm ~ 762cm ) Projection screen size... -
Page 45: Projection Distance Vs. Projection Size
SP8600HD3D/IN8601 User’s Manual Projection Distance vs. Projection Size Projection Distance and Size Table 16:9 SCREEN PROJECTION DISTANCE VERTICAL OFFSET DIAGONAL WIDTH HEIGHT AVERAGE LENGTH LENGTH INCH INCH INCH INCH (WITH MAX ZOOM) (WITH MIN ZOOM) 1063(42) 1169(46) 1275(50) 56(2) 664(26) -
Page 46: Timing Mode Table
Preface Timing Mode Table The projector can display several resolutions. The following table outlines the resolutions that can be displayed by the projector. HDMI IGNAL ESOLUTION OMPOSITE OMPONENT ANALOG DIGITAL — NTSC — 15.734 60.0 － － — PAL/SECAM — 15.625 50.0 －... - Page 47 SP8600HD3D/IN8601 User’s Manual HDMI IGNAL ESOLUTION OMPOSITE OMPONENT ANALOG DIGITAL 480p 31.5 60.0 — 720p 37.5 50.0 — 720p 45.0 60.0 — 1080i 33.8 60.0 — HDTV 1080i 28.1 50.0 — 1080p 67.5 60.0 — — 1080p 56.3 50.0 2D to 3D support timings :...
- Page 48 — O: Frequency supported —: Frequency not supported (*) VGA support EDTV/SDTV/HDTV component with an adapter. The SP8600HD3D and IN8601 projector's native resolution is 1920 x 1080. Resolutions different than this may display uneven lines or text. – 41 –...
-
Page 49: P Rojector D Imensions
SP8600HD3D/IN8601 User’s Manual Projector Dimensions — 42 —... -
Page 50: Fcc W Arning
Preface EGULATORY OMPLIANCE FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device pur- suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. -
Page 51: Rs-232C P Rotocol
SP8600HD3D/IN8601 User’s Manual RS-232C Protocol RS232 Setting Baud rate: 9600 Parity check: None Data bit: Stop bit: Flow Control None Minimum delay for next command: 1ms Control Command Structure The command is structured by the Header code, command code, data code and end code. - Page 52 Preface Remote Command The remote commands simulate the code send from IR remote handset. Button’s name ASCII UP arrow 7Eh 72h 55h 0Dh ~ r U CR DOWN arrow ~ r D CR 7Eh 72h 44h 0Dh LEFT arrow ~ r L CR 7Eh 72h 4Ch 0Dh RIGHT arrow ~ r R CR...
- Page 53 SP8600HD3D/IN8601 User’s Manual Query Command ITEM ASCII Software Version ~ q V CR 7Eh 71h 56h 0Dh Power State 7Eh 71h 50h 0Dh ~ q P CR Input Select 7Eh 71h 53h 0Dh ~ q S CR Lamp Hours 7Eh 71h 4Ch 0Dh...
