  • Page 1 projecting pure enter tainment ™ User’s Guide...
  • Page 3 FCC Warning Canada Safety Certifications...
  • Page 4 Declaration of Conformity Australian Certification C-tick mark Trademarks...
  • Page 5 TABLE OF CONTENTS Safety Instructions Introduction Setting up the Projector Using the Projector...
  • Page 6 Maintenance & Troubleshooting Appendix Index...

  • Page 7: Safety Instructions

    SAFETY INSTRUCTIONS Safety Definitions: Warning: Caution: Safety Symbols: Attention: Warning: Safety Terms: Warning: Warning: Warning:...
  • Page 8 NOTE: For general product information, please call 1-800-294-6400. Warning: Caution: Caution: Caution: Caution: Caution: Important Operating Considerations Technical Support 1-800-799-9911 Do not place objects in this area in front of the projector techsupport@infocus.com (31) 20 579 2820 (65) 6353-9449...

  • Page 9: Introduction

    INTRODUCTION Image Resolution Compatibility Unpacking the Projector Contact your InFocus dealer imme- diately if anything is missing. NOTE: The LS110 automatically expands 640x480 computer images to 800x600. You can dis- play these images at their native resolutions by using the Resize fea- ture.
  • Page 10 4XL.N 6WDUW IGURE Shipping box contents Projector + lens cap Soft carry case User’s Guide and quick start card Power cord Remote control Enhanced Connectivity module Computer cable Audio/Video (A/V) cable S-video cable...
  • Page 11 Back view of projector with Enhanced Connectivity Module attached power cord connector height adjustment button IGURE Front view of projector IGURE Back view of projector IGURE...
  • Page 12 NOTE: For general product information, please call 1-800-294-6400. Usage Guidelines If You Need Assistance http://www.infocus.com/service. 1-800-799-9911 techsupport@infocus.com (31) 20 579 2820 (65) 6353-9449 http://www.infocus.com.
  • Page 13 Warranty...

  • Page 15: Setting Up The Projector

    7.4 ft IGURE Projected image size at minimum zoom NOTE: To ensure adequate cable access, place the projector at least 6 inches (0.15m) from a wall or other objects. NOTE: Place the projector at least 5.6 feet (1.7 m) from the...
  • Page 16 WARNING: Do not place the projector on a tablecloth or other soft covering that may block the vents. Do not use a non-InFocus ceiling mount. In the unlikely event of the bulb rupturing, thoroughly clean the area in front of the...

  • Page 17: Connecting The Enhanced Connectivity Module

    (for all video sources) Connector panel with enhanced connectivity module attached Audio in IGURE Connector panel Control (RS-232) not used composite monitor S-video video IGURE NOTE: Before you continue, make sure the projector is unplugged and your equipment is turned off.
  • Page 18 HDTV, Video 3-Component, Video 1 S-Video, Video 2-Composite, PC 2-Component, and PC 2-Analog. NOTE: Specific RS-232 commands can be found on our website at www.infocus.com. NOTE: Monitor out is only available for analog computer, 480p, and HDTV sources. IGURE Connecting the connectivity module to the projector...

  • Page 19: Connecting A Video Device

    Connecting a Video Device 16x9 image in a 4:3 space 4x3 image in a 16:9 space IGURE 4:3 and 16:9 screen aspects...
  • Page 20 Input Signal Connector cable S-video cable VESA cable IGURE Cables included with the projector Connector Source name on Label on Screen Projector yellow white black black...
  • Page 21 To watch regular TV If your TV tuner has S-video output: Connecting the projector to a TV tuner using the S-video cable S-video cable IGURE NOTE: If needed, you can pur- chase longer cables at your local electronics store.
  • Page 22 IGURE Connecting the projector to a TV tuner using the S-video cable and the A/V cable S-video cable A/V cable power...
  • Page 23 source video menu/select volume...
  • Page 24 If your TV tuner has composite video output: cable IGURE Connecting the projector to a TV tuner using the audio video (A/V) cable If your TV tuner has component video output:...
  • Page 25 To watch a DVD or VHS tape If your video device has S-video output: Connecting the projector to a video player using the S-video cable S-video cable IGURE NOTE: If needed, you can pur- chase longer cables at your local...
  • Page 26 IGURE Connecting the projector to a video player using the S-video cable and the A/V cable S-video cable A/V cable power...
  • Page 27 source video volume menu/select...
  • Page 28 If your video device has composite video output: composite video cable IGURE Connecting the projector to a video player using the audio video (A/V) cable...

  • Page 29: To Watch Hdtv

    To watch HDTV If your HDTV tuner has a 15-pin VGA output: VESA cable Connecting the projector to an HDTV source using the VESA cable NOTE: If needed, you can pur- chase longer cables at your local electronics store. IGURE...
  • Page 30 video menu/select volume power source...
  • Page 31 If your HDTV tuner has a DVI or component output: To play a video game To play a game from a video machine: To play a video game from a computer: To connect a camcorder...
  • Page 32 NOTE: Lamp life will be extended if you turn the power off, then wait 1 minute while the lamp cools before unplugging the projector. The Lamp LED will light green when the lamp has cooled. Turning Off the Projector standby...

  • Page 33: Connecting A Computer

    Connecting a Computer computer cable Do you want to play your computer’s audio on the projector? Do you want to display the image on your desktop computer’s moni- tor as well as on the projection screen? IGURE Connecting the projector to a computer...
  • Page 34 NOTE: Always use the power cord that shipped with the projector. Displaying your Computer Source power...
  • Page 36 NOTE: Lamp life will be extended if you turn the power off, then wait 1 minute while the lamp cools before unplugging the projector. The Lamp LED will light green when the lamp has cooled. source...

  • Page 37: Using The Projector

    USING THE PROJECTOR Basic Image Adjustment Adjusting the Projector focus ring zoom ring IGURE Focus ring and zoom ring NOTE: To obtain the best overall focus quality, open the menu and focus on the text. This will ensure that the best overall image quality...
  • Page 38 IGURE Adjusting the height of the projector IGURE Turning the leveling knob elevator button (under finger) elevator foot...

  • Page 39: Using The Remote Control

    Using the Remote Control power menu/select zoom + zoom - forward backward zoom mode data video keystone standby IGURE Remote control...

  • Page 40: Using The Keypad And Remote Buttons

    NOTE: If you have turned Auto Source off (page 47), you may need to press the source button more than once to display an active source. The sources switch in this order: PC 1-Analog, PC 1-Digital, Video 3-Component HDTV, Video 3-Component, Video 1 S-Video, Video 2-Composite, PC 2-Component, and PC 2-Analog.
  • Page 41 Keystone + - keystone + keystone - decreasing keystone increasing keystone IGURE Adjusting the keystone Forward/back buttons (remote only) Up/down/left/right arrow buttons (remote only) Power button...
  • Page 42 Zoom mode/Zoom +/Zoom - Zoom mode zoom + zoom - Standby standby standby standby Volume (keypad only) volume - zoom mode volume +...
  • Page 43 Using the On-Screen Menus menu/select NOTE: Some menu items may be grayed out (dimmed) at certain times. This indicates the item is not applicable to your setup or the item is not enabled until another selection is made. IGURE Main menu menu/select menu/select menu/select...
  • Page 44 Display Menu menu/select IGURE Display menu Keystone menu/select menu/select Brightness menu/select menu/select Contrast menu/select...
  • Page 45 menu/select menu/select Tint menu/select menu/select Color menu/select menu/select Sharpness menu/select menu/select Screen Aspect menu/select menu/select Blank screen menu/select menu/select NOTE: The color setting applies to video sources only. The tint set- ting applies to NTSC video sources only. NOTE: Some DVD players allow you to select 16:9 or 4:3 mode.
  • Page 46 Audio Menu IGURE Display menu Volume menu/select menu/select Mute menu/select menu/select...
  • Page 47 Image Menu for Video Sources menu/select Resize Resize menu/select IGURE Image menu for video sources NOTE: Your viewing preferences may vary from those listed. Cycle through the resize options and pick the one you like the best.
  • Page 48 Table 1: Resize options for various setups and this If you have screen this source aspect choose this resize to get this image option...
  • Page 49 Enhanced Widescreen 16x9 image input 16:9 input on 4:3 screen with Resize set to Enhanced Widescreen Widescreen Letterbox Letterbox image input 16:9 input on 16:9 screen with Resize set to Widescreen Letterbox 16x9 image on 4:3 screen IGURE 16:9 image fills 16:9 screen IGURE NOTE: A source that says “Anamorphic”...
  • Page 50 Standard 4:3 image input IGURE 4:3 input on 16:9 screen with Resize set to Standard Native Resize menu/select 4:3 image on 16:9 screen menu/select...
  • Page 51 Overscan Zoom Zoom keystone + keystone - zoom mode Video Standard Video standard menu/select menu/select menu/select menu/select NOTE: If you already know the video standard used in your geo- graphical area, it’s often best to manually select it.
  • Page 52 Image Menu for Computer Sources menu/select IGURE Image menu for computer sources Resize Resize Enhanced Widescreen Widescreen Letterbox Native Resize menu/select Zoom Zoom menu/select keystone + keystone - zoom mode menu/select Standard menu/select menu/select...
  • Page 53 Auto Image Auto image menu/select Manual Sync Auto image menu/select Manual Tracking menu/select Horizontal/Vertical Position menu/select Auto image menu/select, Auto Image menu/select menu/select NOTE: The Manual Sync, Manual Tracking, Horizontal Position and Vertical Position options are available only for ana- log computer sources.
  • Page 54 NOTE: Your viewing preferences may vary. Cycle through the degamma options and pick the one you like the best. Color Management Menu IGURE Color Management menu Degamma Degamma menu/select Color Space Standard Color Space Standard Color Temperature Red, Green, Blue menu/select menu/select menu/select...
  • Page 55 Control Menu menu/select Auto Source source Auto source menu/select Default Source Default source Standby Time menu/select IGURE Control menu data video menu/select menu/select...
  • Page 56 Advanced Menu IGURE Advanced menu Rear Project Rear Project Rear Project Ceiling Project Ceiling Project menu/select Display Messages Display Startup Screen menu/select...
  • Page 57 Reset menu/select Language Menu menu/select menu/select menu/select IGURE Language menu menu/select...
  • Page 58 Status Menu menu/select IGURE Status menu Lamp Hours Used Video Standard Computer Resolution (computer sources only) Source Software Version...

  • Page 59: Maintenance & Troubleshooting

    MAINTENANCE & TROUBLESHOOTING Cleaning the Lens Replacing the Projection Lamp WARNING: To avoid burns, allow the projector to cool for at least 30 minutes before you open the lamp module door. Never extract the lamp module while the projector is operating.
  • Page 60 The lamp module is designed to contain these fragments, but use caution when removing the lamp module. CAUTION: Never operate the projector with the lamp door open or removed. This disrupts the air flow and causes the projector to overheat. &...
  • Page 61 volume - IGURE Removing the lamp module power source volume - WARNING: Do not drop the lamp module or touch the glass bulb! The glass may shatter and cause injury.
  • Page 62 & Cleaning the Projection Lamp Filter Screens IGURE Lamp module screens screen screen...
  • Page 63 Replacing the Batteries in the Remote Control...
  • Page 64 & Troubleshooting Table 2: LED behavior and meaning LED color/behavior Meaning...
  • Page 65 Table 3: Problem with the projector Symptom Remedy Projector not running (LED not lit green) Projector not running (LED lit green) Projector running (LED lit green) but nothing appears on projection screen Projector running (LED blinking series of 3 fast...
  • Page 66 Lamp getting dimmer Lamp shuts off & Table 3: Problem with the projector...
  • Page 67 Table 4: Problem with a video image Symptom Remedy Image out of focus Image not centered on the screen Image too wide or narrow for screen Image not square Image is noisy Color or text not being pro- jected Image and menus reversed left to right Image and menus upside down...
  • Page 68 Image from component source appears “greenish” Image is “torn” Table 5: Problem with a computer image Symptom Only the start-up screen displays Image isn’t centered on the screen & Table 4: Problem with a video image Remedy...
  • Page 69 Table 5: Problem with a computer image Screen resolution not correct Image is “noisy” or streaked Projected colors don’t match computer or video player’s color Image appears “purplish” Auto Image Auto Image...
  • Page 70 & http://www.infocus.com/service. 1-800-799-9911 NOTE: For general product information, please call 1-800-294-6400. (31) 20 579 2820 (65) 6353-9449 techsupport@infocus.com...

  • Page 71: Appendix

    APPENDIX Specifications Temperature Operating 50 to 104 50 to 95 Non-operating -4 to 158 Altitude Operating 0 to 10,000 feet (3,048 meters) Non-operating 0 to 20,000 feet (6,096 meters) Humidity Operating and non-oper. 10% to 95% relative humidity, non-condensing Dimensions 10.4 x 11.1 x 3.3 inches (264 x 283 x 85 mm) with module 10.4 x 12.1 x 3.3 inches (264 x 307 x 85 mm) Weight...
  • Page 72 S-Video Cable 13 ft (4 m) Remote Projection Lamp Module (included in projector) Lens Cap Enhanced Connectivity Module Power Cords (one ships with projector, type depends on country) North American Power Cord Australian Power Cord UK Power Cord European Power Cord...
  • Page 73 Audio/video inputs on the Enhanced Connectivity Module Source Video CA-ATA-005 SP-AV30 SP-DVI-D SP-CEIL-LMP5 HW-PORTSCR50 HW-DLXSCRN HW-WALLSCR84 SP-LAMP-002 EW-1YEAR EW-2YEAR NOTE: You can purchase these items by contacting your dealer or InFocus Catalog Sales at 1-800-660-0024. For general product information, please call 1-800-294-6400. Audio...
  • Page 74 NOTE: Use the graph and table to help you determine projected image sizes. NOTE: Visit our website at www.infocus.com for an interactive image size calculator. It is located in the Technical Library in the Service and Support section. Projected Image Size...
  • Page 75 maximum image size Distance to Screen (feet) Table 7: Range of distance to the screen for a given screen size for 4:3 aspect ratio Diagonal Screen Size Image Width (inches) (inches) minimum image size IGURE Projected image size for 4:3 aspect ratio Distance to screen Maximum Minimum...

  • Page 77: Index

    INDEX Numerics...
  • Page 81 Limited Warranty 3URMH.WRU 3URGX.W /LPLWHG :DUUDQW\ 3HULRG ([.OXGLQJ /DPSV  7ZR  \HDUV /DPS 3URGX.W /LPLWHG :DUUDQW\ 3HULRGV GD\ RU  KRXUV $..HVVRU\ 3URGX.W /LPLWHG :DUUDQW\ 3HULRG WARRANTY LIMITATION AND EXCLUSION DISCLAIMER OF UNSTATED WARRANTIES Limited Warranty Period  KRXUV...
  • Page 82 To Be Eligible For Limited Warranty Coverage To Obtain Warranty Service LIMITATION OF LIABILITY /LPLWDWLRQ RQ %ULQJLQJ $.WLRQ *RYHUQLQJ /DZ 0DQGDWRU\ $UELWUDWLRQ...
