- Page 2 Copyright This publication, including all photographs, illustrations and software, is protected under international copy- right laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. © Copyright 2010 Disclaimer The information in this document is subject to change without notice.
-
Page 3: Important Safety Information
SP8600 User's Manual Important Safety Information Important: It is strongly recommended that you read this section carefully before using the projector. These safety and usage instructions will ensure that you enjoy many years of safe use of the projector. Keep this manual for future reference. Symbols Used Warning symbols are used on the projector and in this manual to alert you of hazardous situations. -
Page 4: Projector Installation Notice
Preface Projector Installation Notice Place the projector in a horizontal position The tilt angle of the projector should not exceed 15 degrees, nor should the projector be installed in any way other than the desktop and ceiling mount, otherwise lamp life could decrease dramatically. Allow at least 50 cm clearance around the exhaust vent. - Page 5 SP8600 User's Manual Replacing the Lamp Replacing the lamp can be hazardous if done incorrectly. See Replacing the Projection Lamp on page 29 for clear and safe instructions for this procedure. Before replacing the lamp: Unplug the power cord. Allow the lamp to cool for about one hour. Cleaning the Projector Unplug the power cord before cleaning.
-
Page 6: Table Of Contents
Preface Table of Contents GETTING STARTED ................................1 ................................1 ACKING HECKLIST ............................... 2 IEWS OF ROJECTOR ARTS Front-right View ................................2 Top view—On-screen Display (OSD) buttons and LEDs ....................3 Rear view ..................................4 Bottom view..................................5 ..............................6 EMOTE ONTROL ARTS... - Page 7 SP8600 User's Manual SPECIFICATIONS................................39 ................................. 39 PECIFICATIONS ........................40 ROJECTION ISTANCE VS ROJECTION Projection Distance and Size Table ..........................40 ................................ 41 IMING ABLE ..............................43 ROJECTOR IMENSIONS REGULATORY COMPLIANCE ............................. 44 FCC W .................................. 44 ARNING .................................... 44 ANADA ..............................
-
Page 8: Getting Started
SP8600 User's Manual ETTING TARTED Packing Checklist Carefully unpack the projector and check that the following items are included: DLP P ROJECTOR HDMI (EU) (UK) EMOTE CONTROL CABLE OWER CORD OWER CORD BATTERY NOT INCLUDED (US) CD-ROM OWER CORD UICK TART ARRANTY ’... -
Page 9: Views Of Projector Parts
SP8600 User's Manual Views of Projector Parts Front-right View ABEL ESCRIPTION EE PAGE Height-adjuster button Push to release height adjuster Height adjuster Adjust level of projector Lens Projection Lens IR receiver Receive IR signal from remote control Focus ring Focus the projected image Zoom ring Enlarge the projected image See Top view—On-screen Display (OSD) buttons... -
Page 10: Top View-On-Screen Display (Osd) Buttons And Leds
SP8600 User's Manual Top view—On-screen Display (OSD) buttons and LEDs Menu Enter ABEL ESCRIPTION EE PAGE Green Power On / Standby Power LED Power Off (AC Off) Lamp is ready to be powered-on. Lamp LED Lamp is not ready (warming up/shutting down/cooling) Flashing (see LED Error Messages on page 35) -
Page 11: Rear View
SP8600 User's Manual Rear view ABEL ESCRIPTION EE PAGE AC IN Connect the power cord Connect a USB cable from a computer (USB) COMPONENT Connect a component video enabled device S-VIDEO Connect a S-VIDEO cable from a video device COMPOSITE Connect a COMPOSITE cable from a video device Connect a RGB cable from a computer. -
Page 12: Bottom View
SP8600 User's Manual Bottom view Ceiling Mount M4x8 (Max L=12mm) 51.5 109.0 76.0 ABEL ESCRIPTION EE PAGE Tilt adjustor Rotate adjuster lever to adjust angle position. Ceiling support holes Contact your dealer for information on mounting the projector on a ceiling Height adjustor Adjuster drops down when adjuster button is pushed. -
Page 13: Remote Control Parts
SP8600 User's Manual Remote Control Parts Important: 1. Avoid using the projector with bright fluorescent lighting turned on. Certain high-frequency fluo- rescent lights can disrupt remote control operation. 2. Be sure nothing obstructs the path between the remote control and the projector. If the path be- tween the remote control and the projector is obstructed, you can bounce the signal off certain reflective surfaces such as projector screens. - Page 14 SP8600 User's Manual ABEL ESCRIPTION EE PAGE Up cursor Navigate and change settings in the OSD Enter Change settings in the OSD Power Turn the projector On or Off Right cursor Navigate and change settings in the OSD Volume + Increase volume Volume - Decrease volume...
-
Page 15: Remote Control Operating Range
SP8600 User's Manual Remote Control Operating Range The projector receives infrared signals from the remote control. It is not necessary to point the remote directly at the projector. Provided you are not holding the remote perpendicular to the sides or the rear of the projector, the remote will function well within a radius of about 7 meters (23 feet) and 15 degrees above or below the projector level. -
Page 16: Setup And Operation
SP8600 User's Manual ETUP AND PERATION Inserting the Remote Control Batteries Remove the battery compartment cover by sliding the cover in the direction of the arrow (A). Pull out the cover (B). Insert the battery (not included) with the positive side facing up. Replace the cover. -
Page 17: Connecting Input Devices
SP8600 User's Manual Connecting Input Devices A PC or notebook computer and video devices can be connected to the projector at the same time. Video devices include DVD, VCD, and VHS players, as well as movie camcorders and digital still cameras. Check the user manual of the connecting device to confirm it has the appropriate output connector. -
Page 18: Starting And Shutting Down The Projector
SP8600 User's Manual Starting and Shutting down the Projector Connect the power cord to the projector. Connect the other end to a wall outlet. POWER LED will be on. Turn on the connected devices. Ensure the POWER LED displays a solid green and not a flashing green. -
Page 19: Adjusting The Projector Level
SP8600 User's Manual Adjusting the Projector Level Take note of the following when setting up the projector: • The projector table or stand should be level and sturdy. • Position the projector so that it is perpendicular to the screen. •... -
Page 20: Adjusting The Zoom Ring, Focus And Keystone
SP8600 User's Manual Adjusting the Zoom ring, Focus and Keystone Use the Image-zoom control (on the projector only) to resize the pro- jected image and screen size Use the Image-focus control (on the projector only) to sharpen the pro- jected image Use the KEYSTONE buttons (on the projector or the remote control) to... -
Page 21: Adjusting The Volume
SP8600 User's Manual Adjusting the Volume Press the Volume +/- buttons on the remote control. The volume control appears on the display. Menu Enter Press the Left or Right Cursor buttons on the keypad to adjust Volume +/-. Press the MUTE button to turn off the volume (This feature is available only on the remote). -
Page 22: On-Screen Display (Osd) Menu Settings
SP8600 User's Manual (OSD) M CREEN ISPLAY ETTINGS OSD Menu Controls The projector has an OSD that lets you make image adjustments and change various settings. Navigating the OSD You can use the remote control cursor buttons or the buttons on the top of the projector to navigate and make changes to the OSD. -
Page 23: Setting The Osd Language
SP8600 User's Manual Setting the OSD Language Set the OSD language to your preference before continuing. 1. Press the MENU button. Press the cursor ◄► button to navigate to SETUP>>Basic. 2. Press the cursor ▲▼ button until Language is highlighted. 3. -
Page 24: Osd Menu Overview
SP8600 User's Manual OSD Menu Overview Use the following illustration to quickly find a setting or determine the range for a setting. – 17 –... -
Page 25: Picture>>Basic Menu
SP8600 User's Manual PICTURE>>Basic Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the PICTURE>>Basic menu. Press the cursor ▲▼ button to move up and down in the PICTURE>>Basic menu. Press ◄► to change values for settings. Note: Customizing the settings in PICTURE>>Basic menu is only available in User 1/ 2/ 3 mode. -
Page 26: Picture>>Advanced Menu
SP8600 User's Manual PICTURE>>Advanced Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the PICTURE>>Advanced menu. Press the cursor ▲▼ button to move up and down in the PICTURE>>Advanced menu. Press ◄► to change values for settings. ESCRIPTION Noise Reduction Press the cursor ◄►... -
Page 27: Hsg Adjustment
SP8600 User's Manual HSG Adjustment Press the ENTER button to enter the HSG Adjustment sub menu. ESCRIPTION Press the ◄► buttons to set the Primary Color. Primary Color Notes: There are six sets (R/ G/ B/ C/ M/ Y) of colors to be customized. Press the ◄►... -
Page 28: Display Menu
SP8600 User's Manual DISPLAY Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the DISPLAY menu. Press the cursor ▲▼ button to move up and down in the DISPLAY menu. Press ◄► to change values for settings. ESCRIPTION Press the cursor ◄►... -
Page 29: Pc Detail Adjustment
SP8600 User's Manual PC Detail Adjustment Press the ENTER button to enter the PC Detail Adjustment sub menu. Note: Customizing the settings in PC Detail Adjustment menu is only available when PC input source (analog RGB) is selected. ESCRIPTION Press the ENTER/AUTO button on the control panel or the ENTER/AUTO button on the Auto remote control to automatically adjust frequency, phase, and position. -
Page 30: Setup>>Basic Menu
Press the cursor ◄► buttons to select a different localization menu. Press the cursor ◄► buttons to select a different startup screen. Splash Logo (Range: InFocus/ Blue/ Black) Press the cursor ◄► buttons to choose from four projection methods: Projection Front Table/ Front Ceiling/ Rear Table/ Rear Ceiling. -
Page 31: Menu Settings
SP8600 User's Manual Menu Settings Press the ENTER button to enter the Menu Settings sub menu. ESCRIPTION Press the ◄► buttons to select from five OSD locations: Menu Position Top-Left/ Top-Right/ Center/ Bottom-Left/ Bottom-Right. Press the ◄► buttons to set the Menu Display timer before the OSD times out. Menu Display Time (Range: 5sec/ 10sec/ 15sec/ 20sec/ 25sec/ 30sec) Source... -
Page 32: Setup>>Advanced Menu
SP8600 User's Manual SETUP>>Advanced Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the SETUP>>Advanced menu. Press the cursor ▲▼ button to move up and down in the SETUP>>Advanced menu. ESCRIPTION Audio Press the ENTER button to enter the Audio sub menu. -
Page 33: Audio
SP8600 User's Manual Audio Press the ENTER button to enter the Audio sub menu. ESCRIPTION Volume Press the ◄► buttons to adjust the audio Volume. Bass Press the ◄► buttons to adjust the audio Bass. Treble Press the ◄► buttons to adjust the audio Treble. Mute Press the ◄►... -
Page 34: Hdmi
SP8600 User's Manual HDMI Press the ENTER button to enter the HDMI sub menu. ESCRIPTION Press the ◄► buttons to select from three HDMI display formats: HDMI Format Auto/ PC signal/ Video signal. HDMI Amplifier Gain Press the ◄► buttons to adjust HDMI Amplifier Gain. Closed Caption Press the ENTER button to enter the Closed Caption sub menu. -
Page 35: Status Menu
SP8600 User's Manual STATUS Menu Press the MENU button to open the OSD menu. Press the cursor ◄► button to move to the STATUS Menu. ESCRIPTION Source Displays the activated input source. Resolution Displays the current resolution of input source. Lamp Hour Displays the number of hours the lamp has been in use. -
Page 36: Maintenance And Security
SP8600 User's Manual AINTENANCE AND ECURITY Replacing the Projection Lamp The projection lamp should be replaced when it burns out. It should only be replaced with a certified replacement part, which you can order from your local dealer. Important: a. The projection lamp used in this product contains a small amount of mercury. b. - Page 37 SP8600 User's Manual Remove the lamp compart- ment cover. Remove the three screws from the lamp module. Lift the module handle up. Pull firmly on the module handle to remove the lamp module. – 30 –...
- Page 38 SP8600 User's Manual Reverse steps 1 to 6 to install the new lamp module. While installing, align the lamp module with the connector and ensure it is level to avoid damage. Note: The lamp module must sit securely in place and the lamp connector must be con- nected properly before tightening the screws.
-
Page 39: Cleaning The Projector
SP8600 User's Manual Cleaning the Projector Cleaning the projector to remove dust and grime will help ensure trouble-free operation. Warning: 1. Be sure to turn off and unplug the projector at least 30 minutes before cleaning. Failure to do so could result in a severe burn. -
Page 40: Using The Kensington ® Lock
SP8600 User's Manual ® Using the Kensington Lock If you are concerned about security, attach the projector to a permanent object with the Kensington slot and a security cable. Note: Contact your vendor for details on purchasing a suitable Kensington security cable. The security lock corresponds to Kensington’s MicroSaver Security System. -
Page 41: Troubleshooting
SP8600 User's Manual ROUBLESHOOTING Common problems and solutions These guidelines provide tips to deal with problems you may encounter while using the projector. If the problem remains unsolved, contact your dealer for assistance. Often after time spent troubleshooting, the problem is traced to something as simple as a loose con- nection. -
Page 42: Led Error Messages
SP8600 User's Manual LED Error Messages OWER RROR ESSAGES LINK LINK LINK Lamp Ready Start (AC Power standby) Cooling flashing Over Temperature Thermal Break Sensor error 4 blinks 4 blinks Lamp error 5 blinks Lamp End of lamp life detected 5 blinks 3 blinks Burner Fan error... -
Page 43: Lamp Problems
SP8600 User's Manual Problem: The image is flat with no contrast Adjust the Contrast setting on the Image menu of the OSD. Problem: The color of the projected image does not match the source image. Adjust the Color Temperature and Gamma settings on the Image menu of the OSD. Lamp Problems Problem: There is no light from the projector 1. -
Page 44: Audio Problems
3. Have the projector serviced. Need Assistance? If you need assistance, visit our website at www.infocus.com/service or call us. Check out our HOW TO section there for additional information on using this projector for home theater applications. This product is backed by a limited warranty. An extended warranty plan may be purchased from your dealer. -
Page 45: Hdmi Q & A
SP8600 User's Manual HDMI Q & A Q. What is the difference between a “Standard” HDMI cable and a “High-Speed” HDMI cable? Recently, HDMI Licensing, LLC announced that cables would be tested as Standard or High- Speed cables. ․Standard (or “category 1”) HDMI cables have been tested to perform at speeds of 75Mhz or up to 2.25Gbps, which is the equivalent of a 720p/1080i signal. -
Page 46: S Pecifications
SP8600 User's Manual PECIFICATIONS Specifications SP8600 Model Display type TI DLP DMD 0.65” Native Resolution 1920 x 1080 3.4 kg (7.5 lbs) Weight 1 meters ~ 10 meters Projection distance Projection screen size 30" ~ 300" Projection lens Manual Focus/Manual Zoom Zoom ratio Vertical keystone correction +/- 30 degrees... -
Page 47: Projection Distance And Size Table
SP8600 User's Manual Projection Distance vs. Projection Size Projection Distance and Size Table 16:9 SCREEN PROJECTION DISTANCE VERTICAL DIAGONAL WIDTH HEIGHT OFFSET IN LENGTH LENGTH AVERAGE INCH (WITH MAX (WITH MIN ZOOM) ZOOM) 1056 1162 1267 1016 1408 1549 1690 1270 1107 1760... -
Page 48: Timing Mode Table
SP8600 User's Manual Timing Mode Table The projector can display several resolutions. The following table outlines the resolutions that can be displayed by the projector. HDMI OMPOSITE IGNAL ESOLUTION OMPONENT / S-V IDEO ANALOG DIGITAL — NTSC — 15.734 60.0 －... - Page 49 SP8600 User's Manual HDMI OMPOSITE IGNAL ESOLUTION OMPONENT / S-V IDEO ANALOG DIGITAL 720p 37.5 50.0 — — 720p 45.0 60.0 — — 1080i 33.8 60.0 — — HDTV 1080i 28.1 50.0 — — 1080p 67.5 60.0 — — 1080p 56.3 50.0 —...
-
Page 50: P Rojector D Imensions
SP8600 User's Manual Projector Dimensions 326 mm – 43 –... -
Page 51: Fcc W Arning
SP8600 User's Manual EGULATORY OMPLIANCE FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device pur- suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
