ACTi E33 Specifications

5mp bullet with d/n, ir, basic wdr, fixed lens
Hide thumbs Also See for E33:
1
2

Advertisement

Quick Links

Download this manual See also: User Manual
B ull e t C am e ra
E33
* The bracket is included.
PHOTO INDICATION
Internal
2
1
1
Reset Button
2
Power LED
ACCESSORY OPTIONS
Camera Bracket
PMAX-1103
w w w . a c t i . c o m
External
3
3
Ethernet Port
Aluminum, max. load 10 kg (22.05
lb), tilt angle 90°, swivel angle 360°
* Latest product information: www.acti.com/product/
* Accessory information: www.acti.com/accessory/
5MP Bullet with D/N, IR, Basic WDR, Fixed lens
• Progressive Scan CMOS
• Day and night function with mechanical IR cut filter
• Minimum illumination 0 lux with IR LED on
• Built-in f4.2 mm / F1.8 Megapixel fixed lens
• 15 fps at 2592x1944 resolution
• Selectable H.264 HP, MJPEG compressions with dual
streaming
• Video motion detection
• Weatherproof IP66 rated casing
• Powered by PoE Class 2

DIMENSION DIAGRAM

Popular Mounting Solutions
Corner
PMAX-1103
PMAX-0402
Pole
PMAX-1103
PMAX-0502
* For more mounting solutions, please refer to Mounting Accessory section of Buyer's
Guide or Project Planner on www.acti.com
Unit: mm [inch]
Unit: mm [inch]
+
+
121101

Advertisement

loading
Need help?

Need help?

Do you have a question about the E33 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ACTi E33

Summary of Contents for ACTi E33

  • Page 1: Dimension Diagram

    PMAX-1103 PMAX-0502 * For more mounting solutions, please refer to Mounting Accessory section of Buyer’s Guide or Project Planner on www.acti.com * Latest product information: www.acti.com/product/ w w w . a c t i . c o m * Accessory information: www.acti.com/accessory/...

  • Page 2: Bullet Camera

    Operating Humidity 10% ~ 85% RH Approvals CE, FCC, IP66 • Integration Unified Solution Fully compatible with ACTi software ISV Integration Software Development Kit (SDK) available; ONVIF compliant Firmware Access Browser Microsoft Internet Explorer 6.0 or newer * All specifications are subject to change without notice. w w w . a c t i . c o m * All brand names and registered trademarks are the property of their respective owners.
