Page 1: User Manual
USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read carefully through this brief but comprehensive manual before installing and switching on the monitor. Please keep this manual in a... - Page 3 Congratulations! This product is TCO Certified for Sustainable IT TCO Certified is an international third party sustainability certification for IT products. TCO Certified ensures that the manufacture, use and recycling of IT products reflect environmental, social and economic responsibility. Every TCO Certified product model is verified by an accredited independent test laboratory.
-
Page 4: Ce Marking Declaration Of Conformity
For displays with glossy bezels the user should consider the placement of the display as the bezel may cause disturbing refl ections from surrounding light and bright surfaces. We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com... -
Page 5: Table Of Contents
WALL MOUNTING ................5 Fitting and Removal of Base : ProLite XUB2390HS / ProLite XUB2790HS ..6 FITTING AND REMOVAL OF BASE : ProLite XU2290HS / ProLite XU2390HS ...7 CONTROLS AND CONNECTORS : ProLite XUB2390HS / ProLite XUB2790HS .8 CONTROLS AND CONNECTORS : ProLite XU2290HS / ProLite XU2390HS ..9 CONNECTING YOUR MONITOR : ProLite XUB2390HS / ProLite XUB2790HS .10... -
Page 6: For Your Safety
Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object inside may cause fi re, electric shock or damage. - Page 7 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fi re, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.
-
Page 8: Special Notes On Lcd Monitors
Power Switch for some hours. Contact your dealer or iiyama service center for the backlight replacement when the screen is dark, fl ickering or not lighting up. Never attempt to replace it by yourself. -
Page 9: Before You Operate The Monitor
CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama offi ce. -
Page 10: Wall Mounting
WALL MOUNTING When you use with the wall mounting, in consideration of thickness of the mounting WARNING stage, tighten the M4 Screw with washer which “L” length is 7mm to fasten the monitor. Using the screw longer than this may cause electric shock or damage because it may contact with the electrical parts inside the monitor. -
Page 11: Fitting And Removal Of Base : Prolite Xub2390Hs / Prolite Xub2790Hs
FITTING AND REMOVAL OF BASE : ProLite XUB2390HS / ProLite XUB2790HS Put the monitor on a stable surface. The monitor may cause injury or damage if it CAUTION falls or is dropped. Do not give a strong impact to the monitor. It may cause damage. ... -
Page 12: Fitting And Removal Of Base : Prolite Xu2290Hs / Prolite Xu2390Hs
FITTING AND REMOVAL OF BASE : ProLite XU2290HS / ProLite XU2390HS Put the monitor on a stable surface. The monitor may cause injury or damage if it CAUTION falls or is dropped. Do not give a strong impact to the monitor. It may cause damage. -
Page 13: Controls And Connectors : Prolite Xub2390Hs / Prolite Xub2790Hs
CONTROLS AND CONNECTORS : ProLite XUB2390HS / ProLite XUB2790HS <Front> <Back> Power Indicator NOTE Blue: Normal operation Orange: Power Management Power Switch ( Menu Button (MENU) + / Volume Button ( + ) - / ECO Button ( - ) Auto Button (AUTO) Speakers Keyhole for Security Lock... -
Page 14: Controls And Connectors : Prolite Xu2290Hs / Prolite Xu2390Hs
CONTROLS AND CONNECTORS : ProLite XU2290HS / ProLite XU2390HS <Front> <Back> Power Indicator Blue: Normal operation NOTE Orange: Power Management Power Switch ( Menu Button (MENU) + / Volume Button ( + ) - / ECO Button ( - ) -
Page 15: Connecting Your Monitor : Prolite Xub2390Hs / Prolite Xub2790Hs
An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce. -
Page 16: Connecting Your Monitor : Prolite Xu2290Hs / Prolite Xu2390Hs
An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce. -
Page 17: Computer Setting
Signal Timing Change to the desired signal timing listed on page 32: COMPLIANT TIMING. ADJUSTING THE VIEWING ANGLE : ProLite XU2290HS / ProLite XU2390HS For optimal viewing it is recommended to look at the full face of the monitor. -
Page 18: Adjusting The Height And The Viewing Angle
ADJUSTING THE HEIGHT AND THE VIEWING ANGLE : ProLite XUB2390HS / ProLite XUB2790HS For optimal viewing it is recommended to position yourself directly opposite to the full face of the monitor, then adjust the monitor’s height and angle to your own preference. ... -
Page 19: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 32. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 21 for SCREEN ADJUSTMENTS. -
Page 20: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS Luminance Luminance Contrast Brightness i-Style Color Standard Adv. Contrast :Exit :Move AUTO MENU :Select Adjustment Item Problem / Option Button to Press Too dull Contrast Too intense Too dark Brightness * Too bright For general windows environment and monitor Standard default setting. -
Page 21: Image Setup
Image Setup Image Setup Clock Phase H.Position V.Position Aspect Ratio Full AUTO :Exit :Move MENU :Select Adjustment Item Problem / Option Button to Press Too narrow Clock* Too wide Phase* To correct fl ickering text or lines Too left H. Position* Too right Too low V. - Page 22 Color Temp. Color Temp. Gamma Gamma1 Color Temp. Warm User-Red User-Green User-Bule AUTO :Exit :Move MENU :Select Adjustment Item Problem / Option Button to Press Gamma1 Normal Gamma Gamma2 High contrast Gamma3 Dark Warm Greenish white Normal Yellowish white Cool Bluish white User-Red Color Temp.
- Page 23 OSD Setup OSD Setup H.Position V.Position OSD Timeout Language English AUTO :Exit :Move MENU :Select Adjustment Item Problem / Option Button to Press OSD is too left H.Position OSD is too right OSD is too low V.Position OSD is too high You can set the OSD display duration time OSD Timeout between 5 and 100 seconds.
- Page 24 Extra Extra Reset DDC / CI Input Select Auto Over Drive HDMI audio Line in Opening Logo Information Input: D-SUB Resolution: 1920<H> * 1080<V> H. Frequency: 67KHz V. Frequency: 60Hz :Exit :Move AUTO MENU :Select Adjustment Item Problem / Option Button to Press Factory-preset data is restored.
-
Page 25: Screen Adjustments
Direct You can skip the Menu items and display an adjustment scale directly by using the following button operations. Volume: Press the + Button when the Menu is not displayed. Adjustment Item Problem / Option Button to Press Too soft Volume Too loud ... -
Page 26: Screen Adjustments
If the screen has a fl icker or blur, or the picture does not fi t in the display area after performing the Auto Image Adjust, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http:// www.iiyama.com). - Page 27 C Pressing and holding of the AUTO Button for about 3-4 seconds. (Auto Adjust) D Adjust the image manually by following procedure below when the screen has a fl icker or blur, or the picture does not fi t in the display area after performing the Auto Image Adjust. E Adjust the V.Position so that the top and bottom of the picture frame will fi...
- Page 28 G Adjust the Phase to correct horizontal wavy noise, fl icker or blur in the zebra pattern. In case the strong fl icker or blurs remain on a part of the screen, repeat steps F and NOTE G because the Clock may not be adjusted correctly. If the fl icker or blurs still remain, set the refresh rate of computer to low (60Hz) and repeat steps from C again.
-
Page 29: Power Management Feature
POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of ENERGY ® STAR and VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. - Page 30 MONITOR or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem...
-
Page 31: Recycling Information
A strange noise The Audio Cable is properly connected. is heard. RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com/recycle for monitor recycling. 26 TROUBLE SHOOTING / RECYCLING INFORMATION... -
Page 32: Appendix
APPENDIX Design and specifi cations are subject to change without prior notice. SPECIFICATIONS : ProLite XU2290HS Size Category 21.5" LCD Panel Panel technology IPS Size Diagonal: 21.5" (54.7cm) Pixel pitch 0.248mm H × 0.248mm V Brightness 250cd/m (Typical) Contrast ratio 1000 : 1 (Typical), Adv. -
Page 33: Specifications : Prolite Xub2390Hs
SPECIFICATIONS : ProLite XUB2390HS Size Category 23" LCD Panel Panel technology IPS Size Diagonal: 23" (58.4cm) Pixel pitch 0.265mm H × 0.265mm V Brightness 250cd/m (Typical) Contrast ratio 1000 : 1 (Typical), Adv. Contrast Function Available Viewable angle Right / Left / Up / Down: 89 degrees each (Typical) Response time 5ms (Gray to Gray) Display Colours... -
Page 34: Specifications : Prolite Xu2390Hs
SPECIFICATIONS : ProLite XU2390HS Size Category 23" LCD Panel Panel technology IPS Size Diagonal: 23" (58.4cm) Pixel pitch 0.265mm H × 0.265mm V Brightness 250cd/m (Typical) Contrast ratio 1000 : 1 (Typical), Adv. Contrast Function Available Viewable angle Right / Left / Up / Down: 89 degrees each (Typical) Response time 5ms (Gray to Gray) Display Colours... -
Page 35: Specifications : Prolite Xub2790Hs
SPECIFICATIONS : ProLite XUB2790HS Size Category 27" LCD Panel Panel technology IPS Size Diagonal: 27" (68.6cm) Pixel pitch 0.311mm H × 0.311mm V Brightness 250cd/m (Typical) Contrast ratio 1000 : 1 (Typical), Adv. Contrast Function Available Viewable angle Right / Left / Up / Down: 89 degrees each (Typical) Response time 5ms (Gray to Gray) Display Colours... -
Page 36: Dimensions : Prolite Xu2290Hs
DIMENSIONS : ProLite XU2290HS 499.5mm/19.7” 44.0mm/1.7” 492.5mm/19.4” 219.5mm/8.6” DIMENSIONS : ProLite XU2390HS 532.5mm/21.0” 44.0mm/1.7” 526.0mm/20.7” 219.5mm/8.6” DIMENSIONS : ProLite XUB2390HS 532.5mm/21.0” 44.0mm/1.7” 526.0mm/20.7” 250.0mm/9.8” ) : Maximum adjustment range APPENDIX 31... -
Page 37: Dimensions : Prolite Xub2790Hs
DIMENSIONS : ProLite XUB2790HS 622.5mm/24.5” 45.0mm/1.7” 615.5mm/24.2” 300.0mm/11.8” ) : Maximum adjustment range COMPLIANT TIMING Horizontal Vertical Dot Clock Video Mode Frequency Frequency 31.469kHz 59.940Hz 25.175MHz 640 × 480 31.500MHz 37.500kHz 75.000Hz 35.156kHz 56.250Hz 36.000MHz SVGA 800 × 600 37.879kHz 60.317Hz 40.000MHz 46.875kHz...
