SERVICE MANUAL
COMPACT DISC CARRY
COMPONENT SYSTEM
This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
CA-DW247 U<S>,U2<S> (S/M Code No.09-003-339-4T1)
CA-DW257 LH<S> (S/M Code No.09-003-339-4T2).
CA-DW247
CA-DW257
BASIC TAPE MECHANISM : ZZM-2 YPR3NF
BASIC CD MECHANISM : DA11T3C
S/M Code No. 09-003-339-4R1
U(S)
LH(S)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CA-DW247 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aiwa CA-DW247

Summary of Contents for Aiwa CA-DW247

  • Page 1 BASIC TAPE MECHANISM : ZZM-2 YPR3NF COMPACT DISC CARRY BASIC CD MECHANISM : DA11T3C COMPONENT SYSTEM This Service Manual is the “Revision Publishing” and replaces “Simple Manual” CA-DW247 U<S>,U2<S> (S/M Code No.09-003-339-4T1) CA-DW257 LH<S> (S/M Code No.09-003-339-4T2). S/M Code No. 09-003-339-4R1...

  • Page 2: Specifications

    SPECIFICATIONS • Design and specifications are subject to change without notice ACCESSORIES/PACKAGE LIST REF. NO PART NO. KANRI DESCRIPTION 1 8A-CT9-902-010 IB,LH(ESP)FM<257 LH<S>> 1 8A-CT9-903-010 IB,U(ESF)FM<EXCEPT 257 LH<S>> 2 87-A90-312-010 PLUG,CONVERSION WTN-1157R1 <257 LH<S>> 3 87-A80-036-010 AC CORD SET ASSY,E W/FLTR VOL <257 LH<S>>...

  • Page 3: Protection Of Eyes From Laser Beam During Servicing

    PROTECTION OF EYES FROM LASER BEAM DURING SERVICING This set employs laser. Therefore, be sure to follow carefully the CAUTION instructions below when servicing. Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous WARNING! radiation exposure.

  • Page 4: Electrical Main Parts List

    ELECTRICAL MAIN PARTS LIST REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 87-010-197-080 CAP, CHIP 0.01 DM 87-010-426-080 CHIP.CAP,S 0.012U/50V(Z) 87-A20-955-010 IC,LA1828 87-010-426-080 CHIP.CAP,S 0.012U/50V(Z) 87-A21-090-010 IC,LA4600 87-A11-729-080 CHIP CA 0.47UF/25V(Z)F 87-A21-520-040 C-IC,M61509FP 87-A11-729-080 CHIP CA 0.47UF/25V(Z)F 87-020-828-010 IC,BA3416BL 87-001-440-010...
  • Page 5 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION C305 87-010-260-080 CAP, ELECT 47-25V C438 87-012-368-080 C-CAP,S 0.1-50 F C306 87-010-260-080 CAP, ELECT 47-25V C439 87-010-178-080 CHIP CAP 1000P C307 87-010-382-080 CAP, ELECT 22-25V C440 87-010-145-080 C-CAP,S 1P-50 CH C308 87-010-405-080 CAP, ELECT 10-50V...
  • Page 6 REF. NO PART NO. KANRI DESCRIPTION REF. NO PART NO. KANRI DESCRIPTION 8A-CT9-641-010 CONN,3P UL1007 LED602 8Z-CT6-632-010 LED,L-934LID CN401 87-A60-424-010 CONN,16P V TOC-B LED603 8Z-CT6-632-010 LED,L-934LID CN501 87-049-919-010 CONN,3P EH V WHT LED604 8Z-CT6-632-010 LED,L-934LID CN601 87-A60-109-010 CONN,2P V S2M-2W LED605 8Z-CT6-632-010 LED,L-934LID...

  • Page 7: Lcd Display

    LCD DISPLAY • Regarding connectors, they are not stocked as they are not the initial order items. The connectors are available after they are supplied from connector manufacturers upon the order is received. CHIP RESISTOR PART CODE Chip Resistor Part Coding Figure Resistor Code Value of resistor...
  • Page 8 WIRING-1 (MAIN/FRONT)
  • Page 9 SCHEMATIC DIAGRAM-1 (MAIN)
