X8STi/X8STi-F/X8STi-3F/X8STi-LN4 User's Manual
2-5

Connectors/IO Ports

Back Panel Connectors and IO Ports

5
2
4
1
3
Back Panel Connectors
1. Keyboard (Purple)
2. PS/2 Mouse (Green)
3. USB Port 0
4. USB Port 1
5. IPMI LAN (X8STi-F/-3F)
6. COM 1
6
7
7. VGA
8. LAN1
9. LAN2
10. LAN3 (X8STi-LN4)
11. LAN4 (X8STi-LN4)
2-10
11
10
8
9
12
