Sitecom WL-536 Brochure & Specs page 3

Key features :
• Complies with the IEEE 802.11b and IEEE 802.11g 2.4GHz (DSSS) standards.
• High data transfer rate - up to 54Mbps.
• Support 64/128/256-bit WEP, WPA(TKIP, IEEE 802.1x) and AES ( TKIP ) functions for high level of security.
• Supports Software AP function, which turns the wireless station into a wireless AP.
• Complies with IEEE 802.11d country roaming standard.
• Supports the most popular operating system: Windows 98SE/Me/2000/XP.
• Supports USB 2.0/1.1/1.0 interface.
Specifi cation:
• 802.11g Wireless LAN Mini USB Adapter
• Standards :
• Bus Type :
• Frequency Band:
• Modulation:
• Data Rate:
• Securities:
• Internal Antenna
• Drivers:
• LEDs:
• Power Consumption:
• Receive Sensitivity:
• Temperature :
• Humidity :
• Certifi cation:
Wireless Network USB Adapter 54g Turbo
IEEE 802.11g/b
USB 2.0 Type A
2.4000~2.4835GHz (Industrial Scientifi c Medical Band)
OFDM with BPSK, QPSK, 16QAM, 64QAM (11g) BPSK, QPSK, CCK (11b)
54/48/36/24/18/12/11/9/6/5.5/2/1Mbps auto fallback
64/128/256-bit WEP Encryption, WPA( TKIP, IEEE 802.1x) and AES
Windows 98SE/Me/2000/XP
-Link/Activity
-Transmit Power
-15dBm (Typical)
TX: 340mA, RX: 180mA, Standby: 70mA
-72dBm@54Mbps, -85dBm@11Mbps, -93dBm@1Mbps
32~122°F (0 ~50°C)
10-95% (NonCondensing)
FCC , CE
Data sheet: WL-536
P. 3-3.
