Wireless Access Point; Virtual Server And Dmz - Sitecom WL-536 Brochure & Specs

lP Sharing
The NAT/NAPT function lets you share the ADSL line to all the Intranet users (support up to 253 users). It also provides virtual serverand virtual DMZ functions to let
your internal servers be accessed from the Internet.
Wireless Turbo G Access Point
The MAC/BBP IC features Range-OVERDRIVETMand Packet-OVERDRIVETMtechnology that combines Packet Burst and Frame Aggregation for up to 35 Mbps through-
put, without resorting to channel bonding that decreases available channels and increases interference.
Build-in High Performance ADSL2+ modem
This ADSL router can run at speeds of up to 24 Mbit/s downstream and 2 Mbit/s upstream, providing higher data rates than those found
in traditional ADSL systems. However, backward compatibility with existing ADSL services and interoperability with legacy equipment are maintained.
Support ADSL2+ standard
The ADSL router supports ADSL standard: G.dmt, G.lite, G.992.3, G.992.4, G.992.5 (Annex A)

Wireless Access Point

The wireless access point function can let your IEEE 802.11g/b wireless client devices access the Intranet through this router.
Supports Special Applications
The router can let you setup trigger ports of special applications, and let you utilize Internet services smoothly.
Anti-DoS SPI Firewall
The SPI (StatefulPacket Inspection) fi rewall can protect your Intranet PCs from illegal access and many kinds of DoS attacks from the Internet,
and alert you by e-mail in the fi rst time if some event happens. It also provides Internet access control function.

Virtual Server and DMZ

The virtual server and DMZ function let you setup your servers in the Intranet and still can provide services to the Internet users.
DHCP
Automatically assgin IPs to the Intranet PCs.
Web Confi guration
You can confi gure the router through the friendly Web user interface with a browser.
Features
• NAT/NAPT IP Sharing
• SPI Anti-DoS Firewall
• Virtual Server/DMZ
• IEEE 802.54g Turbo G Access Point
• Supports 64/128 Bit Key Length WEP Encryption
• Advanced Quality of Service (QoS) - 802.11e, WMM
• Supports Special Applications (Port Triggers)
• Supports DDNS (DynDNS, TZO)
• VPN Pass Through (IPSec/PPTP)
• Obtain WAN IP by PPPoE/Static IP/PPTP/DHCP/L2TP
• DHCP Server
• Web User Interface (Remote Confi guration)
• System Status (Port Connectivity, DHCP MAC/IP Mapping)
• Security Log
• Firmware Upgrade
• Supports ADSL standard G.dmt, G.lite, G.992.3, G.992.4, G.992.5 (Annex A)
Wireless Network ADSL 2+ Modem Router
54g Turbo
Data sheet:
Specifi cations
• Product WL-174
• CPU Trendchip TC3084
• Front End Trendchip TC3162P
• RF Ralink RT2561 ST
• Flash 2 MB NOR Flash
• RAM 8 MB SDRAM
• ADSL Ports RJ-11 x 1
• LAN Ports 10/100M UTP Port x 4
• Antenna RP-SMA Detachable Antenna
• Power 12V DC, 1A Linear Power Adaptor
• Dimension 30(H)*187(W)*100(D) mm
• Temperature 10~40 oC
• Humidity 10~90% (Non-Condensing)
• Certifi cation FCC Class B, CE Mark
WL-536
P. 2-3.
