High Tech Pet HUMANE CONTAIN HC-7000 User Manual page 17

Adding a GATE
If you want a permanent opening or gate in
the containment field, you must use what is
commonly called a double loop, as shown
in Figure 9. Carefully follow the current
around the wiring and you will realize that
this layout is actually still a single loop of
wire that is folded back upon itself. If the
gate is narrow, you may have to reduce the
boundary field next to the gate. This can be
done by triangulating or folding the wire back
on itself for a short distance as shown inside
Figure 9. Do not bury the wire near the
gate until after the entire system is working
and adjusted for the proper field strength in
all areas of the installation. In double loop
installations, it is very important to have
the inside and outside wires separated
MAKING A CONTAINMENT FIELD WITH MULTIPLE GATES
TWISTED WIRE
FIELD WILL CANCEL
Figure 10
place as many other openings/gates in the boundary field as you wish by
twisting the inner and outer wires together, or simply bringing the two wires
together tightly. This concept, shown in Figure 10.
TIP: The amount of twist and the direction of the twist is of little
importance, as long as the wires are touching each other along the
entire "gate" section.
__________________________________________________________________________________________
High Tech Pet Products, Inc.
GATE
6 FOOT
SEPARATION
RECOMMENDED
TX
www.hightechpet.com
MAKING A CONTAINMENT FIELD WITH A GATE
WIDE
GATE
Wire
NARROW
GATE
Wire
TWISTED WIRE
FIELD WILL CANCEL
TX
Figure 9
by at least 6 feet all around the
containment area if you want a
normal containment field width of
3 to 10 feet. Use 12 feet of wire
separation if you desire a wider
containment field width – up to 20
feet. Using less wire separation
reduces the field strength and
requires the dog to be closer
to the wire before receiving
a correction. Whatever wire
separation you choose, maintain
a consistent separation between
the inside and outside wires if
you want a consistent correction
distance. Remember the double
loop requires almost twice as
much boundary wire, and burying
of that wire, as a single loop, so
plan accordingly.
Once you have chosen to use
the "double loop" layout, you can
Meijer.com
Wire
Wire
6 FOOT
SEPARATION
RECOMMENDED
17
