Q7130A, Q7230A, Q7330A
Modutrol IV Interface Modules
Q7130A
Q7330A
APPLICATION
The Q7130, Q7230, and Q7330 Modutrol IV Interface
Modules are used with Series 90 Modutrol IV Motors (M91XX)
for conversion to electronic (Series 70) control.
FEATURES
• Mounts inside the wiring box of any Series 90 Modutrol
• Mates to quick-connect terminals in motor wiring box
Q7230A
• Features solid state circuitry with surface mount
• Plastic enclosure provides easy handling and
• Q7130A provides selectable voltage range (4-7, 6-9, or
• Q7230A provides current or voltage control (4-20 mA
• Q7330A is an interface to W936 and W945 controls.
INSTALLATION INSTRUCTIONS
IV Motor (M91XX models). Module protected from
weather by the Modutrol IV NEMA 3 wiring box.
and provides screw terminals for control wiring
connections.
components.
protection for circuitry.
10.5-13.5 Vdc). Adapts M91XX Modtrol IV Motor to
function as M71XX model for M734H,J, M744D,
M745G,P replacements. Includes reversing switch to
allow replacement of electrically normally open or
electrically normally closed motors.
and 2-10 Vdc) with adjustable zero and span. Adapts
the M91XX Modutrol IV Motor to function as M72XX
model for M744S,T,Y or M745S,T,Y replacements.
Includes reversing switch to allow replacement of
electrically normally open or electrically normally
closed motors.
Adapts the M91XX Modutrol IV Motor to function as
M73XX model for M734D, M744A, M745A replacements.
Put Bar Code Here
63-2235-07
Advertisement
Table of Contents
Related Manuals for Honeywell Modutrol IV Interface Modules Q7130A
Summary of Contents for Honeywell Modutrol IV Interface Modules Q7130A
-
Page 1: Installation Instructions
Q7130A, Q7230A, Q7330A Modutrol IV Interface Modules Q7130A Q7330A APPLICATION The Q7130, Q7230, and Q7330 Modutrol IV Interface Modules are used with Series 90 Modutrol IV Motors (M91XX) for conversion to electronic (Series 70) control. FEATURES • Mounts inside the wiring box of any Series 90 Modutrol IV Motor (M91XX models). -
Page 2: Specifications
Q7230A Adjustable zero and span, voltage or current M9184D1021 control (includes 4-20 mA and 2-10 Vdc). Q7330A W936 or W945 control interface. Refer to customer.honeywell.com for cross-reference details. M744D1037 and M744D1045 do not apply. 63-2235—07 Input Impedance: Q7130A: >100k ohms. -
Page 3: Installation
INSTALLATION When Installing This Product… 1. Read these instructions carefully. Failure to follow them could damage the product or cause a hazardous condi- tion. 2. Check the ratings and description given in this specifi- cation to make sure the product is suitable for your application. - Page 4 Q7130A, Q7230A, Q7330A MODUTROL IV INTERFACE MODULES T1 T2 Fig. 3. Q7130A terminals and adjustments. Step 1. Open terminal C or R. 2. Jumper terminals C and F. 3. Remove either T terminal or disconnect power supply. Q7230 Adjustments (Fig. 5 and Table 3) The Q7230A provides adjustable range (zero and span) for two-wire current or voltage control.
- Page 5 12. Recheck the fully open position and readjust the span potentiometer, if necessary. (Turn the span potentiome- ter clockwise to close the motor, counterclockwise to open the motor.) Verify the mid point of your stroke. T1 T2 F SPAN Fig. 5. Q7230A terminals and adjustments. SEQUENTIAL OPERATION FOR ADJUSTABLE ZERO AND SPAN MODELS (10)
- Page 6 Q7130A, Q7230A, Q7330A MODUTROL IV INTERFACE MODULES Step 1. Open terminals (+), (-), F 2. Jumper F to (-) 3. Remove either T terminal (+) and (-) denotes terminals on the controller Q7330A Adjustments (Fig. 9 and Table 4) The Q7330A provides control interface for W936 and W945 controllers.
- Page 7 Step 1. Disconnect leads from terminals 1,2,3,4. 2. With motor powered jumper terminals 1 and 2. 3. Remove either T terminal or disconnect power supply. Q7130A, Q7230A, Q7330A MODUTROL IV INTERFACE MODULES Table 4. Q7330/M91XX Checkout Procedure. Proper Motor Response for Normally Closed Motor Motor closes.
- Page 8 Automation and Control Solutions Honeywell International Inc. 1985 Douglas Drive North Golden Valley, MN 55422 Honeywell Limited-Honeywell Limitée 35 Dynamic Drive Toronto, Ontario M1V 4Z9 customer.honeywell.com ® U.S. Registered Trademark © 2011 Honeywell International Inc. 63-2235—07 T.D. Rev. 01-11 Printed in U.S.A.
