- Page 1 IP2DVI Instruction Manual Ethernet to DVI Video Adapter Ethernet to DVI Video Adapter over IP...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an en- dorsement of the product(s) to which this manual applies by the third-party company in question.
-
Page 3: Table Of Contents
Table of Contents Introduction ..............1 Packaging Contents..............1 System Requirements ..............1 Installation ............... 1 Hardware Installation ..............1 Driver Installation .................2 Display mode ..............7 Specifications ..............8 Technical Support ............9 Warranty Information ............9... -
Page 4: Introduction
Introduction Packaging Contents • 1 x IP2DVI video adapter • 1 x Power Adapter • 1 x Driver and Software CD • 1 x Instruction Manual System Requirements • DVI enabled monitor/projector • TCP/IP network access • Microsoft Windows XP/Vista (32-bit) ®... -
Page 5: Driver Installation
LED Indicator Colour Description ON: receiving power from adapter Power OFF: no power supplied from adapter ON: network connection detected Link Green OFF: no network connection detected Flashing: data transfer Driver Installation Windows XP Insert the provided CD into your disc drive. Locate and double-click the Setup.exe file in the Driver folder to launch the setup program. - Page 6 When the Found New Hardware Wizard screen appears, select ‘Install the software automatically (Recommended)’ and click Next. Click ‘Finish’ to complete the installation. Launch the Cat5ShareStation utility from the icon on the Desktop. A list of all available IP2DVI units detected on the network will appear.
- Page 7 Then a pop-up message will appear in the notification area indicating the installation is complete. If your monitor is not yet connected to the IP2DVI, make the connection and power on your monitor. After the connection, the remote monitor should display an image...
- Page 8 Windows Vista Insert the provided CD into your disc drive. Locate and double-click the Setup.exe file in the Driver folder to launch the setup program. During the installation, the screen may flicker a couple of times. This is normal. When this section of the installation is complete, click ‘Finish’...
- Page 9 A pop-up message will appear in the notification area indicating the installation is complete. If your monitor is not yet connected to the IP2DVI, make the connection and power on your monitor. After the connection, the remote monitor should display an image...
-
Page 10: Display Mode
To change the display mode, right-click on the tray icon located in the System Tray, next to the clock. The IP2DVI connected monitor can be configured to: Extend your Windows desktop (default) Extend your Windows desktop to Right / Left / Above / Below the... -
Page 11: Specifications
Specifications 1 x RJ45 female External Connectors 1 x DVI-I 29-pin female 1 x Power (red) LEDs 1 x LAN Link (green) Maximum Resolution 1280 x 1024 Supported Colour Depth 16 and 32 bit • Extended Desktop (left/right/ above/below) Supported Display Modes •... -
Page 12: Technical Support
Technical Support StarTech.com’s lifetime technical support is an integral part of our com- mit-ment to provide industry-leading solutions. If you ever need help with your product, visit www.startech.com/support and access our com- prehensive selection of online tools, documentation, and downloads. - Page 13 StarTech.com has been making “hard-to-find easy” since 1985, providing high quality solutions to a diverse IT and A/V customer base that spans many channels, including government, education and industrial facilities to name just a few. We offer an unmatched selection of computer parts, cables, A/V products, KVM and Serv-...
