Features of VX9100
1. Wave Type
● CELLULAR : G7W
● PCS: G7W
2. Frequency Scope
Transmit Frequency (MHz)
CELLULAR
824.04 ~ 848.97
3. Rated Output Power : CELLULAR = 0.26W
4. Output Conversion Method : This is possible by correcting the key board channel.
5. Voltage and Current Value of Termination Part Amplifier (Catalogue included)
MODE
CELLULAR
PCS
6. Functions of Major Semi-Conductors
Classification
MSM6550A
Memory MCP
(HYC0SGH0MF3P)
RFR6500
RFT6150
7. Frequency Stability
● CELLULAR : ±0.5PPM
● PCS : ±0.1PPM
PCS
1850~1909.95
PCS = 0.24W
Part Name
Voltage
AWT6321R
4.2V
AWT6321R
4.2V
Terminal operation control and digital signal processing
Flash Memory (1Gbit) + SDRAM (512Mbit)
Storing of terminal operation program
Converts Rx RF signal to baseband signal
Converts baseband signal to Tx RF signal
Receive Frequency (MHz)
CELLULAR
869.04~893.97
1930~1989.95
Current
Power
500mA
0.26W
500mA
0.24W
Function
PCS
GPS
1575.42

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VX9100 and is the answer not in the manual?

Questions and answers

Related Manuals for LG VX9100

Summary of Contents for LG VX9100

  • Page 1 Features of VX9100 1. Wave Type ● CELLULAR : G7W ● PCS: G7W 2. Frequency Scope Transmit Frequency (MHz) Receive Frequency (MHz) CELLULAR CELLULAR 824.04 ~ 848.97 1850~1909.95 869.04~893.97 1930~1989.95 1575.42 3. Rated Output Power : CELLULAR = 0.26W PCS = 0.24W 4.
