  • Page 1: User Manual

    User manual NC191 NC221 NC241 The color and the appearance may differ depending on the product, and the specifications are subject to change without prior notice to improve the performance. BN46-00327A-01...

  • Page 2: Table Of Contents

    Table Of Contents BEFORE USING THE Copyright PRODUCT Icons used in this manual Symbols for safety precautions Cleaning Cleaning Securing the Installation Space Precautions for storage Safety Precautions Electricity and Safety Installation and Safety Operation and Safety Correct posture to use the product PREPARATIONS Checking the Contents Removing the Packaging...
  • Page 3 Table Of Contents Connection to Use "PCoIP" LAN Connection Connecting USB Devices Connecting a Microphone Connecting to Headphones or Speakers Connecting a SERIAL cable Connecting to a Secondary Monitor Connecting the Power Connect to the host PC using a LAN cable Installing the WDM driver "PCoIP"...
  • Page 4 Table Of Contents Contrast Configuring Contrast Sharpness Configuring Sharpness SAMSUNG MAGIC Bright Configuring SAMSUNG MAGIC Bright Coarse Adjusting Coarse Fine Adjusting Fine CONFIGURING TINT SAMSUNG MAGIC Color Configuring SAMSUNG MAGIC Color Configuring Red Green Configuring Green Blue Configuring Blue Color Tone...
  • Page 5 Natural Color SOFTWARE What is Natural Color? MultiScreen Installing the Software Removing the Software TROUBLESHOOTING Requirements Before Contacting Samsung Customer Service Center GUIDE Testing the Product Checking the Resolution and Frequency Check the following. Q & A SPECIFICATIONS General PowerSaver...
  • Page 6 Table Of Contents APPENDIX Contact SAMSUNG WORLD WIDE Responsibility for the Pay Service (Cost to Customers) Not a product defect A Product damage caused by customer's fault Others Correct Disposal Correct Disposal of This Product (Waste Electrical & Electronic Equipment)

  • Page 7: Symbols For Safety Precautions

    The contents of this manual are subject to change without notice to improve quality. © 2013 Samsung Electronics Samsung Electronics owns the copyright for this manual. Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited. Microsoft and Windows are registered trademarks of Microsoft Corporation.

  • Page 8: Cleaning

    Before Using the Product Cleaning Cleaning Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched. Take the following steps when cleaning. 1. Power off the monitor and computer. 2. Disconnect the power cord from the monitor. Hold the power cable by the plug and do not touch the cable with wet hands.

  • Page 9: Securing The Installation Space

    10 cm 10 cm 10 cm 10 cm 10 cm Precautions for storage Be sure to contact Samsung Customer Service Center (page 107) if the inside of the monitor needs cleaning. (Service fee will be charged.) Before Using the Product...

  • Page 10: Safety Precautions

    Before Using the Product Safety Precautions Electricity and Safety The following images are for reference only. Real-life situations may differ from what is shown in the images. Warning Do not use a damaged power cord or plug, or a loose power socket. An electric shock or fire may result.

  • Page 11: Installation And Safety

    The product may become damaged by an electric shock.  Do not use the power cord for products other than authorized products supplied by Samsung. An electric shock or fire may result.  Keep the power socket where the power cord is connected unobstructed.
  • Page 12 Before Using the Product Do not install the product on an unstable or vibrating surface (insecure shelf, sloped surface, etc.). The product may fall and break or cause a personal injury.  Using the product in an area with excess vibration may damage the product ...

  • Page 13: Operation And Safety

    Be sure to consult Samsung Customer Service Center (page 107) before  installation if you want to install the product at such a place.
  • Page 14 (paper, match, etc.) into the vent or ports of the product. If water or any foreign substance enters the product, be sure to power off the  product, remove the power cord, and contact Samsung Customer Service Center (page 107). Product failure, an electric shock or fire may result.
  • Page 15 Before Using the Product Caution Leaving the screen fixed on a stationary image for an extended period of time may cause afterimage burn-in or defective pixels. If you are not going to use the product for an extended period of time, ...

  • Page 16: Correct Posture To Use The Product

    Before Using the Product Exercise caution when adjusting the product angle or stand height. Otherwise, children's fingers or hands may become stuck and injured.  Tilting the product excessively may cause it to fall and result in personal  injury. Do not place heavy objects on the product.

  • Page 17: Removing The Packaging

    Preparations Checking the Contents 1.1.1 Removing the Packaging Open the packaging box. Be careful not to damage the product when you open the packaging with a sharp instrument. Remove the styrofoam from the product. Check the components and remove the styrofoam and plastic bag. The appearance of actual components may differ from the image shown.

  • Page 18: Checking The Components

    Preparations 1.1.2 Checking the Components Contact the dealer from whom you purchased the product if any item is missing.  The appearance of the components and items sold separately may differ from the image shown.  Components Warranty card Quick setup guide User manual (Not available in some locations) Power cable...
  • Page 19 Preparations Items sold separately The following items can be purchased at your nearest retailer. LAN cable D-SUB cable USB cable RS232C cable Stereo cable DVI cable USB mouse Keyboard Headphone 1 Preparations...

  • Page 20: Parts

    Preparations Parts 1.2.1 Frontal Buttons The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. OSD Guide SOURCE AUTO Icons Description Open or close the onscreen display (OSD) menu, or return to the ...
  • Page 21 Preparations Icons Description Confirm a menu selection. Pressing the [ ] button when the OSD menu is not displayed will change the input source (Client/Analog). If you power on the product or change the input source by pressing the [ ] button, a message that shows the changed input source will appear at the top left corner of the screen.

  • Page 22: Reverse Side

    Preparations 1.2.2 Reverse Side The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. POWER IN DVI OUT SERIAL Port Description Connect to an audio output device such as headphones. Connect to a microphone.
  • Page 23 Preparations Port Description POWER IN Connect to the power cable. If the 11th digit of the model code is M, the model has internal speakers. Speakers E.g.) LF19NEBHBNM, LF22NTBHBNM, LF24NEBHBNM 1 Preparations...

  • Page 24: Installation

    Preparations Installation 1.3.1 Attaching the cradle Place a protective cloth or Insert the stand base into the Do not remove the fixing pin until cushion on a flat surface. Next, stand in the direction of the you are finished attaching the place the product with the face arrow.

  • Page 25: Adjusting The Product Tilt And Height

    Preparations 1.3.2 Adjusting the Product Tilt and Height The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality. -3°(±2°) ~ 25°(±2°) To adjust the height, remove the fixing pin. ...

  • Page 26: Installing A Wall-Mount Kit Or Desktop Stand

    Preparations 1.3.4 Installing a Wall-mount Kit or Desktop Stand Before Installation Power the product off and remove the power cable from the power socket. Place a protective cloth or Unfasten the screw from the Lift and detach the stand. cushion on a flat surface. Next, back of the product.

  • Page 27: Anti-Theft Lock

    Samsung shall not be held liable for any damage or injury caused by using improper screws or attaching the wall-mount kit or desktop stand using excessive force. Samsung shall not be held liable for any product damage or personal injury caused by using a wall- ...
  • Page 28 RDP and has been designed to support a resolution of 1280*1024(NC191),1920*1080(NC221,NC241) pixels for high-quality graphic work. This monitor enables reinforced security because it is used by connecting it to a server PC and ...

  • Page 29: Connection To Use "Pcoip

    Using "PCoIP" Connection to Use "PCoIP" Do not connect the power cable before connecting all other cables.  Ensure you connect a source device first before connecting the power cable. 2.2.1 LAN Connection Connect the LAN cable to [LAN] on the back of the product. It is not supported when the network speed is below or equal to 10Mbps.

  • Page 30: Connecting A Microphone

    Using "PCoIP" 2.2.3 Connecting a Microphone Connect a microphone to the [MIC] jack at the back of the product. 2.2.4 Connecting to Headphones or Speakers Connect an audio output device, such as headphones or speakers, to [ ] at the back of the product.

  • Page 31: Connecting To A Secondary Monitor

    Using "PCoIP" 2.2.6 Connecting to a Secondary Monitor RGB IN DVI OUT DVI OUT DVI IN Connect [DVI OUT] on the product to [DVI IN] or [RGB IN] on another monitor using a DVI or DVI to D-SUB cable. The [DVI OUT] port can be used only to connect to a dual monitor. ...

  • Page 32: Connect To The Host Pc Using A Lan Cable

    Using "PCoIP" Connect to the host PC using a LAN cable Host PC LAN Cable Monitor Connect the power cord to the power terminal at the back of the monitor. Connect the mouse and the keyboard to the USB ports. Connect the LAN port on the back of the monitor and the hub.

  • Page 33: Installing The Wdm Driver

    Using "PCoIP" 2.3.1 Installing the WDM driver Save the WDM driver file to the desired virtual machine (VM), and unzip the file. Go to Start Control Panel Device Manager. If "TUSB3410 Device" is not shown in Device Manager List, Please disconnect and re-connect to the VM.
  • Page 34 Using "PCoIP" Right-click on "TUSB3410 Boot Device" and select "Update Driver Software". Next, click "Browse my computer for driver software". Click "Browse" to select the folder where the driver is saved. If a Windows security message pops up, click "Install this driver software anyway". 2 Using "PCoIP"...
  • Page 35 Using "PCoIP" When installation is complete, click "Close". Go to Start Control Panel Device Manager. Check and confirm that the TUSB3410 device is correctly recognized through a COM port. 2 Using "PCoIP"...

  • Page 36: Pcoip

    Using "PCoIP" "PCoIP" 2.4.1 On Screen Display (OSD) The On Screen Display (OSD) local GUI is displayed to the user when the device is powered on and a PCoIP session is not in progress. The OSD lets the user connect to a host device through the Connect window.

  • Page 37: Osd Options Menu

    Using "PCoIP" 2.4.3 OSD Options Menu Selecting the Options menu will display a list of selections. The OSD Options menu contains: Configuration  This option lets you configure various settings for the device such as network settings, session type, language, and other settings. Diagnostics ...
  • Page 38 Using "PCoIP" configuration options are a subset of the options available in the Administrative Web Interface. Network Tab You can configure the host and client network settings from the Initial Setup page or Network page. After you update the parameters on this page, click Apply to save your changes.
  • Page 39 Using "PCoIP" Primary DNS Server  The primary DNS IP address of the device. This field is optional. If the DNS server IP address is configured using the Connection Manager, the address may be set as an FQDN instead of an IP address.
  • Page 40 Using "PCoIP" Figure 2-4: IPv6 Configuration Enable IPv6  Enable this field to enable IPv6 for your PCoIP devices. Link Local Address  This field is automatically populated. Gateway  Enter the gateway address. Enable DHCPv6  Enable this field to set up Dynamic Host Configuration Protocol version 6 (DHCPv6) for your device. Primary DNS ...
  • Page 41 Using "PCoIP" Enable Manual Address  Enable this field to set up a manual (static) address for the device. Manual Address  Enter the IP address for the device. Label Tab Label page is available from the host or client. The Label page lets you add information for the device.
  • Page 42 Using "PCoIP" Discovery Tab Use the settings on the Discovery Configuration page to erase the discovery of hosts and clients in your PCoIP system and dramatically reduce the configuration and maintenance effort for complex systems. This discovery mechanism is independent of DNS SRV discovery. For SLP discovery to work, routers must be configured to forward multicast traffic between subnets.
  • Page 43 Using "PCoIP" Session Tab Session page lets you configure how the host or client device connects to or accepts connections from peer devices. The Session parameters can also be configured using the Administrative Web Interface. Figure 2-7: Session Configuration Connection Type ...
  • Page 44 Using "PCoIP" Language Tab Language page lets you change the user interface language. This setting affects the local OSD GUI. It is only available on the client.  The Language parameters can also be configured using the Administrative Web Interface. ...
  • Page 45 Using "PCoIP" OSD Tab page allows the screensaver timeout to be set using the On Screen Display parameter. The OSD parameters can also be configured using the Administrative Web Interface.  page is only available on the client. It is unavailable on the host. ...
  • Page 46 Using "PCoIP" Figure 2-11: Display Configuration Enable display override  This option is intended for legacy systems. It configures the client to send default EDID information to the host when a monitor cannot be detected or is not attached to the client. In versions of Windows prior to Windows 7, once the host had no EDID information, it would assume no monitors...

  • Page 47: Diagnostics Window

    Using "PCoIP" Reset Tab Reset Parameters page lets you reset configuration and permissions to factory default values stored in onboard flash memory. Reset can also be initiated using the Administrative Web Interface.  Resetting parameters to factory default values does not revert the firmware or clear the custom ...
  • Page 48 Using "PCoIP" The Administrative Web Interface allows you to change the log filter setting on the device which controls the level of detail of the messages in the log. When you set the filter to “terse,” the device will log short and concise messages.
  • Page 49 Using "PCoIP" Figure 2-14: Session Statistics PCoIP Packets Statistics  PCoIP Packets Sent  The total number of PCoIP packets sent in the current/last session. PCoIP Packets Received  The total number of PCoIP packets received in the current/last session. PCoIP Packets Lost ...
  • Page 50 Using "PCoIP" Figure 2-15: PCoIP Processor 2 Using "PCoIP"...

  • Page 51: Information Window

    Using "PCoIP" Ping Tab Ping page allows you to ping a device to see if it is reachable across the IP network. This may help you determine if a host is reachable. As a result of firmware releases 3.2.0 and later forcing the “do not fragment”...
  • Page 52 Using "PCoIP" Figure 2-17: Version VPD Information  Vital Product Data (VPD) is information set by the factory to uniquely identify each Portal or Host. MAC Address  Host/client unique MAC address Unique Identifier  Host/client unique identifier Serial Number ...

  • Page 53: User Settings Window

    Using "PCoIP" Bootloader Information  The Bootloader information reflects the current PCoIP bootloader details. Bootloader Version  Version of the current bootloader Bootloader Build ID  Revision code of the current bootloader Bootloader Build Date  Build date of the current bootloader 2.4.7 User Settings Window User Settings page allows you to access tabs to define the Certificate Checking Mode, the mouse...
  • Page 54 Using "PCoIP" VMware View Tab VMware View page allows configuration for use with a VMware View Connection Server. VCS Certificate Check Mode Lockout is enabled from the Administrative Web Interface, users  will not be able to modify the settings on this page. VMware View parameters can also be configured using the administrative web interface.
  • Page 55 Using "PCoIP" Mouse Tab Mouse page lets you change the mouse cursor speed settings for the OSD sessions. The OSD mouse cursor speed setting does not affect the mouse cursor settings when a PCoIP session is active unless the Local Keyboard Host Driver function is being used.
  • Page 56 Using "PCoIP" Keyboard Tab Keyboard page lets you change the keyboard repeat settings for the OSD session. The keyboard settings do not affect the keyboard settings when a PCoIP session is active unless  Local Keyboard Host Driver function is used. Refer to the "PCoIP Host Software for Windows User Guide: TER0810001"...
  • Page 57 Using "PCoIP" Image Image page allows you to make changes to the image quality of the PCoIP session. This applies to sessions between PCoIP zero clients and PCoIP host cards in a remote workstation. To configure the image quality settings for a VMware View virtual desktop, adjust the PCoIP session variables.
  • Page 58 Using "PCoIP" Display Topology Display Topology page allows users to change the position, rotation, and resolution of a display for a PCoIP session. To apply the Display Topology feature to a PCoIP session between a zero client and a Virtual Machine (VM), VMware View 4.5 or later is required.
  • Page 59 Using "PCoIP" A maximum of two displays can be enabled at the same time. Alignment  Select how you want displays A and B aligned when they are different sizes. This setting affects which area of the screen to use when you move the cursor from one display to the other.
  • Page 60 Using "PCoIP" Touch Screen Touch Screen page allows you to configure and calibrate certain settings of an attached TouchSystems touch screen display. Touch Screen page is only available through the OSD. It is not available in the Administrative Web Interface. Figure 2-23: Touch Screen Enable right click on hold...

  • Page 61: Password Window

    Using "PCoIP" 2.4.8 Password Window This option is available through the Management console program. Password page lets you update the local administrative password for the device. The password can be a maximum of 20 characters. Some PCoIP devices have password protection disabled by default. Password page is not available on these devices.
  • Page 62 Using "PCoIP" Figure 2-25: Authorized Password Reset Details on how to use PCoIP are subject to change without notice. To view the latest information, visit the Teradici website at http://www.teradici.com. 2 Using "PCoIP"...

  • Page 63: Wake On Lan

    Using "PCoIP" 2.4.9 Wake On LAN This feature allows you to power on the product by sending a pre-determined command from an external system to the product over a network. Make sure the network is capable of data communication with the PC that sends the command to the product.

  • Page 64: Wake On Usb

    Using "PCoIP" 2.4.10 Wake on USB If you turn off the power after activating Wake On USB on the product administrative web page, the system switches to standby mode. The Wake on USB feature switches the system from standby mode to normal mode if a change to the keyboard or mouse input is detected.

  • Page 65: Osd Logo Upload

    Using "PCoIP" 2.4.11 OSD Logo Upload Using the OSD Logo Upload page, change the logo displayed on the Teradici OSD. Configuring the settings Set the product and PC IP addresses to enable the product to connect to the PC over a network. Enter the IP address set for the product in the URL address field on the PC to access the product administrative web page.

  • Page 66: Connecting And Usinga Source Device

    Connecting and Using a Source Device Before Connecting 3.1.1 Pre-connection Checkpoints Before connecting a source device, read the user manual provided with it.  The number and locations of ports on source devices may differ from device to device. Do not connect the power cable until all connections are completed. ...

  • Page 67: Connecting And Using A Pc

    Connecting and Using a Source Device Connecting and Using a PC 3.2.1 Connecting to a PC Do not connect the power cable before connecting all other cables.  Ensure you connect a source device first before connecting the power cable. Select a connection method suitable for your PC.

  • Page 68: 68 "Windows Driver" Installation

    Connecting and Using a Source Device 3.2.2 "Windows Driver" Installation You can set the optimum resolution and frequency for this product by installing the corresponding  drivers. An installation driver is contained on the CD supplied with the product.  Insert the user manual CD provided with the product into the CD-ROM drive.

  • Page 69: Setting Optimum Resolution

    An information message about setting optimum resolution will appear if you power on the product for the first time after purchase. Select a language and change the resolution to the optimum value. NC191 NC221 NC241 The optimal resolution for this monitor is as follows: The optimal resolution for this monitor is as follows:...

  • Page 70: Changing The Resolution Using A Pc

    Connecting and Using a Source Device 3.2.4 Changing the Resolution Using a PC Instructions below apply only when the product is used as a standard monitor.  Adjust the resolution and refresh rate in Control Panel on your PC to obtain optimum picture ...
  • Page 71 Connecting and Using a Source Device Changing the Resolution on Windows 7 Go to Control Panel Display Screen Resolution and change the resolution. Changing the Resolution on Windows 8 Go to Settings Control Panel Display Screen Resolution and change the resolution. 3 Connecting and Using a Source Device...

  • Page 72: Screen Setup

    Configure the screen settings such as brightness and color tone. Brightness You can adjust the general brightness of the picture. (Range: 0~100) A higher value will make the picture appear brighter. SAMSUNG This menu is not available when Bright is set to Dynamic Contrast mode.

  • Page 73: Contrast

    Screen Setup Contrast Adjust the contrast between the objects and background. (Range: 0~100) A higher value will increase the contrast to make the object appear clearer. SAMSUNG This menu is not available when Bright is in Cinema Dynamic Contrast mode.

  • Page 74: Sharpness

    Screen Setup Sharpness Make the outline of objects more clear or blurry. (Range: 0~100) A higher value will make the outline of objects clearer. SAMSUNG This menu is not available when Bright is in Cinema Dynamic Contrast mode.  MAGIC...

  • Page 75: Samsung Magic Bright

    This menu provides an optimum picture quality suitable for the environment where the product will be used. You can customize the brightness to suit your preferences. 4.4.1 Configuring SAMSUNG MAGIC Bright MENU Press any button on the front of the product to display the OSD guide. Next, press [ ] to display the corresponding menu screen.

  • Page 76: Coarse

    Press [ ] to move to Coarse and press [ ] on the product. The following screen will appear. PICTURE Brightness Contrast Sharpness SAMSUNG MAGIC Bright : Custom Coarse Fine AUTO AUTO Adjust the Coarse using the [ ] buttons.

  • Page 77: Fine

    ] on the product. Press [ ] to move to Fine and press [ ] on the product. The following screen will appear. PICTURE Brightness Contrast Sharpness SAMSUNG MAGIC Bright : Custom Coarse Fine AUTO AUTO Adjust the Fine using the [ ] buttons.

  • Page 78: Configuring Tint

    Dynamic Contrast mode. SAMSUNG MAGIC Color SAMSUNG Color is a new picture-quality improvement technology developed independently by Samsung, MAGIC which delivers vivid natural colors without picture quality degradation. 5.1.1 Configuring SAMSUNG MAGIC Color MENU Press any button on the front of the product to display the OSD guide. Next, press [ ] to display the corresponding menu screen.

  • Page 79: Red

    Configuring Tint Adjust the value of the color red in the picture. (Range: 0~100) A higher value will increase the intensity of the color. SAMSUNG This menu is not available when Color is in Full Intelligent mode. MAGIC 5.2.1 Configuring Red MENU Press any button on the front of the product to display the OSD guide.

  • Page 80: Green

    Configuring Tint Green Adjust the value of the color green in the picture. (Range: 0~100) A higher value will increase the intensity of the color. SAMSUNG This menu is not available when Color is in Full Intelligent mode. MAGIC 5.3.1 Configuring Green MENU Press any button on the front of the product to display the OSD guide.

  • Page 81: Blue

    Configuring Tint Blue Adjust the value of the color blue in the picture. (Range: 0~100) A higher value will increase the intensity of the color. SAMSUNG This menu is not available when Color is in Full Intelligent mode. MAGIC 5.4.1 Configuring Blue MENU Press any button on the front of the product to display the OSD guide.

  • Page 82: Color Tone

    Configuring Tint Color Tone Adjust the general color tone of the picture. SAMSUNG This menu is not available when Color is in Full Intelligent mode. MAGIC 5.5.1 Configuring the Color Tone Settings MENU Press any button on the front of the product to display the OSD guide. Next, press [ ] to display the corresponding menu screen.

  • Page 83: Gamma

    COLOR and press [ ] on the product. Press [ ] to move to Gamma and press [ ] on the product. The following screen will appear. COLOR SAMSUNG MAGIC Color Green Blue Normal Color Tone Mode1 Gamma Mode2 Mode3...

  • Page 84: Resizing Or Relocating The Screen

    Resizing or Relocating the Screen H-Position & V-Position H-Position: Move the screen to the left or right. V-Position: Move the screen up or down. This menu is available in Analog mode only. 6.1.1 Configuring H-Position & V-Position MENU Press any button on the front of the product to display the OSD guide. Next, press [ ] to display the corresponding menu screen.

  • Page 85: Menu H-Position & Menu V-Position

    Resizing or Relocating the Screen Menu H-Position & Menu V-Position Menu H-Position: Move the menu position to the left or right. Menu V-Position: Move the menu position up or down. 6.2.1 Configuring Menu H-Position & Menu V-Position MENU Press any button on the front of the product to display the OSD guide. Next, press [ ] to display the corresponding menu screen.

  • Page 86: Setup And Reset

    Setup and Reset Reset Return all the settings for the product to the default factory settings. 7.1.1 Initializing Settings (Reset) MENU Press any button on the front of the product to display the OSD guide. Next, press [ ] to display the corresponding menu screen.

  • Page 87: Language

    Setup and Reset Language Set the menu language. A change to the language setting will only be applied to the onscreen menu display.  It will not be applied to other functions on your PC.  7.2.1 Changing the Language MENU Press any button on the front of the product to display the OSD guide.

  • Page 88: Display Time

    Setup and Reset Display Time Set the on-screen display (OSD) menu to automatically disappear if the menu is not used for a specified period of time. Display Time can be used to specify the time after which you want the OSD menu to disappear. 7.3.1 Configuring Display Time MENU Press any button on the front of the product to display the OSD guide.

  • Page 89: Menu Transparency

    Setup and Reset Menu Transparency Set the transparency for the menu windows: 7.4.1 Changing Menu Transparency MENU Press any button on the front of the product to display the OSD guide. Next, press [ ] to display the corresponding menu screen. Press [ ] to move to SETUP&RESET...

  • Page 90: Power Key

    Setup and Reset Power Key The power button on the product is used to perform two functions. The default setting is Power Off. 7.5.1 Enabling Power Key MENU Press any button on the front of the product to display the OSD guide. Next, press [ ] to display the corresponding menu screen.

  • Page 91: Information Menu And

    INFORMATION Menu and Others INFORMATION View the current input source, frequency and resolution. 8.1.1 Displaying INFORMATION MENU Press any button on the front of the product to display the OSD guide. Next, press [ ] to display the corresponding menu screen. Press [ ] to move to INFORMATION.

  • Page 92: Installing The Software

    Samsung Electronics to resolve this problem. This software works with Samsung products only and enables you to adjust the displayed colors on the screen to match the colors of the printed pictures. For more information, refer to the online help of the software (F1).

  • Page 93: Installing The Software

    Installing the Software MultiScreen MultiScreen program can be installed on the VDI server's virtual machine or on a host PC with a compatible Windows-series operating system. Virtual Desktop Infrastructure: a PC equipped with VMware View Teradici Hostcard MultiScreen enables users to use the monitor by partitioning multiple sections. 9.2.1 Installing the Software Insert the installation CD into the [CD-ROM] drive.

  • Page 94: Removing The Software

    Installing the Software "Hardware" At least 32MB of memory  At least 60MB of free space on the hard disk drive  9.2.2 Removing the Software Click [Start], select [Settings]/[Control Panel], and then double-click [Add or Remove Programs]. Select "MultiScreen" from the program list and click the [Add/Delete] button. 9 Installing the Software...

  • Page 95: Troubleshooting Guide

    10.1 Requirements Before Contacting Samsung Customer Service Center 10.1.1 Testing the Product Before calling Samsung Customer Service Center, test your product as follows. If the problem persists, contact Samsung Customer Service Center. Check if your product is operating normally by using the product test function.

  • Page 96: Guide

    Troubleshooting Guide Screen issue Not Optimum Mode is displayed. This message appears if the signal from the graphics card exceeds the maximum resolution or frequency for the product. Change the maximum resolution and frequency to suit the product performance, referring to Standard Signal Mode Table (page 103).

  • Page 97: Guide

    Troubleshooting Guide 10.2 Q & A Question Answer How can I change the Set the frequency on your graphics card. frequency? Windows XP: Go to Control Panel Appearance and  Themes Display Settings Advanced Monitor, and adjust Refresh rate under Monitor settings. Windows ME/2000: Go to Control Panel Display ...
  • Page 98 Troubleshooting Guide Question Answer How can I change the Windows XP: Go to Control Panel Appearance and  resolution? Themes Display Settings, and adjust the resolution. Windows ME/2000: Go to Control Panel Display  Settings, and adjust the resolution. Windows Vista: Go to Control Panel Appearance and ...

  • Page 99: Specifications

    Specifications 11.1 General Model Name NC191 NC221 NC241 Image Size 19 Inches (48.1 cm) 21.5 Inches (54.6 cm) 23.6 Inches (59.8 cm) 376.32 mm (H) x 476.64 mm (H) x 521.28 mm (H) x Panel 301.06 mm (V) 268.11 mm (V) 293.22 mm (V)
  • Page 100 The above specifications are subject to change without notice to improve quality. This device is a Class B digital apparatus. (USA only) Dispose unwanted electronics through an approved recycler. To find the nearest recycling location, go to our website: www.samsung.com/recyclingdirect or call, (877) 278 - 0799 11 Specifications...
  • Page 101 Specifications CALIFORNIA USA ONLY (Applicable for networking models only.) This Perchlorate warning applies only to primary CR(Manganese Dioxide) Lithium coin cells in the product sold or distributed ONLY in California USA "Perchloate Material - special handling may apply, See www.dtsc.ca.gov/hazardouswaste/ perchlorate."...

  • Page 102: Powersaver

    Switch off) Typical Rating Power lamp Blinking NC191 26 W 41 W Power NC221 31 W 46 W Less than 7.5 W Less than 1.1 W Consumption NC241 28 W 43 W The power consumption level can vary in different operating conditions or when settings are ...

  • Page 103: Standard Signal Mode Table

    Specifications 11.3 Standard Signal Mode Table This product can be set to only one resolution for each screen size to obtain the optimum picture  quality due to the nature of the panel. Therefore, a resolution other than the specified resolution may degrade the picture quality.
  • Page 104 49.702 59.810 83.500 VESA,1280 x 960 60.000 60.000 108.000 VESA,1280 x 1024 63.981 60.020 108.000 VESA,1280 x 1024 79.976 75.025 135.000 NC221 Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) MAC,640 x 480 35.000 66.667 30.240...
  • Page 105 Specifications NC241 Horizontal Vertical Pixel Clock Sync Polarity Resolution Frequency Frequency (MHz) (H/V) (kHz) (Hz) IBM,640 x 350 31.469 70.086 25.175 MAC,640 x 480 35.000 66.667 30.240 VESA,640 x 480 31.469 59.940 25.175 VESA,640 x 480 37.861 72.809 31.500 VESA,640 x 480 37.500 75.000 31.500...
  • Page 106 Specifications Vertical Frequency  Repeating the same picture dozens of times per second allows you to view natural pictures. The repeat frequency is called "vertical frequency" or "refresh rate" and is indicated in Hz. 11 Specifications...

  • Page 107: Appendix

    Appendix Contact SAMSUNG WORLD WIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center. NORTH AMERICA U.S.A 1-800-SAMSUNG (726-7864) http://www.samsung.com CANADA 1-800-SAMSUNG (726-7864) http://www.samsung.com/ca (English) http://www.samsung.com/ca_fr (French) MEXICO 01-800-SAMSUNG (726-7864) http://www.samsung.com...
  • Page 108 VENEZUELA 0-800-100-5303 http://www.samsung.com EUROPE AUSTRIA 0810 - SAMSUNG http://www.samsung.com (7267864, € 0.07/min) BELGIUM 02-201-24-18 http://www.samsung.com/be (Dutch) http://www.samsung.com/be_fr (French) BOSNIA 051 133 1999 http://www.samsung.com BULGARIA 07001 33 11 , normal tariff http://www.samsung.com CROATIA 062 SAMSUNG (062 726 786) http://www.samsung.com Appendix...
  • Page 109 800 - SAMSUNG (800-726786) http://www.samsung.com Samsung Electronics Czech and Slovak, s.r.o., Oasis Florenc, Sokolovská 394/17, 180 00, Praha 8 till 8.2.2013 . From 8.2.2013: Samsung Electronics Czech and Slovak, s.r.o. V Parku 2343/24, 148 00 - Praha 4 DENMARK 70 70 19 70 http://www.samsung.com...
  • Page 110 +381 11 321 6899 http://www.samsung.com (old number still active 0700 7267864) SLOVAKIA 0800 - SAMSUNG (0800-726 786) http://www.samsung.com SPAIN 902 - 1 - SAMSUNG (902 172 678) http://www.samsung.com SWEDEN 0771 726 7864 (SAMSUNG) http://www.samsung.com SWITZERLAND 0848-SAMSUNG http://www.samsung.com/ch (7267864, CHF 0.08/min) (German) http://www.samsung.com/ch_fr...
  • Page 111 1800 266 8282 INDONESIA 0800-112-8888 http://www.samsung.com/id 021-5699-7777 JAPAN 0120-327-527 http://www.samsung.com MALAYSIA 1800-88-9999 http://www.samsung.com/my NEW ZEALAND 0800 SAMSUNG (0800 726 786) http://www.samsung.com PHILIPPINES 1-800-10-SAMSUNG (726-7864) http://www.samsung.com/ph for PLDT 1-800-3-SAMSUNG (726-7864) for Digitel 1-800-8-SAMSUNG (726-7864) for Globe 02-5805777 SINGAPORE 1800-SAMSUNG (726-7864) http://www.samsung.com...
  • Page 112 Appendix MENA KUWAIT 183-2255 (183-CALL) http://www.samsung.com/ae (English) http://www.samsung.com/ae_ar (Arabic) MOROCCO 080 100 2255 http://www.samsung.com OMAN 800-SAMSUNG (726-7864) http://www.samsung.com/ae (English) http://www.samsung.com/ae_ar (Arabic) QATAR 800-2255 (800-CALL) http://www.samsung.com/ae (English) http://www.samsung.com/ae_ar (Arabic) SAUDI ARABIA 9200-21230 http://www.samsung.com/sa (Arabic) SYRIA 18252273 http://www.samsung.com/Levant (English) TURKEY 444 77 11 http://www.samsung.com...

  • Page 113: Responsibility For The Pay Service (Cost To Customers)

    External impact or drop.  Use of supplies or separatly sold product unspecified by Samsung.  Repair from a person besides an engineer of outsourcing service company or partner of Samsung  Electronics Co., Ltd. Remodeling or repairing the product by customer.

  • Page 114: Correct Disposal

    Appendix Correct Disposal Correct Disposal of This Product (Waste Electrical & Electronic Equipment) (Applicable in countries with separate collection systems) This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other household waste at the end of their working life.

  • Page 115: Terminology

    Appendix Terminology OSD (On Screen Display) On screen display (OSD) allows you to customize on-screen settings to optimize the picture quality as required. You can change the screen brightness, tint, size and many other settings using menus displayed on the screen. Coarse Coarse refers to the frequency of radio wave vibrations per second.
  • Page 116 Appendix Vertical Frequency One image is made of numerous horizontal lines. The vertical frequency is measured in Hz and represents how many images can be created per second by those horizontal lines. A vertical frequency of 60 means that an image is transmitted 60 times per second. The vertical frequency is also called "refresh rate"...
  • Page 117 Configuring Volume in the Initial Screen Connect to the host PC using a LAN cable Connecting and Using a PC Parts Connection to Use "PCoIP" Power Key Contact SAMSUNG WORLD WIDE Contrast Copyright Correct posture to use the product Q & A Display Time...
  • Page 118 Index Terminology What is a "PC over IP"? Index...
