LANCOM ES-2126+
Quality of Service
DiffServ/TOS
Port priority
Q- in- Q Tagging
Security
MAC address limitation
802.1x
Broadcast Storm Control
Performance
Switching technology
MAC addresses
Throughput
Virtual Stacking Management (VSM)
VLAN
LAN protocols
Link Aggregation Control Protocol
(LACP)
Multicasting
GVRP/GARP
Spanning Tree Protokoll (STP) / Rapid
STP
Interfaces
Ethernet ports
Serial interface
Management
Port Mirroring
Security
SNMP
RFC 1213 MIB (MIBII)
RFC 1757 RMON MIB
RFC 1493 Bridge MIB
RFC 1643 Ethernet MIB
Webconfig
LANconfig
LANmonitor
Firmware update
Hardware
Power supply
Environment
Housing
Fans
Port based (VIP Port), 802.1p, Priority queuing of packets based on DiffServ/TOS fields
Supports four level priority queues to prioritize inbound and outbound traffic
Supports priority in a Q- in- Q
MAC address learning limit, to set up the maximum amount of MAC that each port can learn
802.1x access control on all ports, user- or MAC- based
Multicast/Broadcast/Unknown unicast storm suppression
Store and forward with latency less than 5 μs
Support of max 8K MAC addresses
max. 8.8 Gbps on the backplane
Supports stacking of up to 16 devices, several switches can be managed via one ip address
Port based and IEEE 802.1q tag based VLAN with up to 4,096 VLAN and up to 256 active VLANs; Supports ingress and egress
packet filter in port based VLAN
2 Fast- and 1 Gigabit Ethernet groups, max 4 member per group, supports DA, SA and DA+SA MAC based trunking with
automatic failover
Supports IGMP snooping inkluding active and passive mode
802.1q with GVRP/GARP
802.1d/1w
24 ports 10/100 Mbps fast ethernet, 2 Combo ports TP/SFP 10/100/1000 Mbps
Serial configuration interface
Support 1:N port mirroring, Sniffer functions with three modes: TX monitor- , RX monitor- , and TX- RX monitor mode
Access rights (read/write) can be set up separately, access control list
SNMP management via SNMPv1 or v2c and private MIB
Interface MIB
Address Translation MIB
IP MIB
ICMP MIB
TCP MIB
UDP MIB
SNMP MIB
Statistics Group 1
History Group 2
Alarm Group 3
Event Group 9
completely
completely
Integrated web server with setup wizard for the configuration via Internet browsers with HTTP
Supported by LANconfig (LANCOM management software): automatic detection, properties, opening of web configuration
Monitoring application for Microsoft Windows for (remote) surveillance and logging of the device and port status
Upload of firmware via TFTP
Internal power supply unit (110–230 V, 50- 60 Hz)
Temperature range 0–40°C; humidity 5–90%; non- condensing
Robust metal housing, 19" 1U (440 x 44 x 209 mm) with removable mounting brackets, network connectors on the front
1
Scope of features: as of LCOS version 7.6x
