ZyXEL Communications ES-305 User Manual

Intelligent layer 2 managed switch
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
ES-305
Intelligent Layer 2 Managed Switch
User's Guide
Version 1.0
6/2007
Edition 1
DEFAULT LOGIN
IP Address http://192.168.0.1
www.zyxel.com

Advertisement

Table of Contents
loading

Related Manuals for ZyXEL Communications ES-305

Summary of Contents for ZyXEL Communications ES-305

  • Page 1 ES-305 Intelligent Layer 2 Managed Switch User’s Guide Version 1.0 6/2007 Edition 1 DEFAULT LOGIN IP Address http://192.168.0.1 www.zyxel.com...

  • Page 3: About This User's Guide

    About This User's Guide About This User's Guide Intended Audience This manual is intended for people who want to configure the ES-305 using the web configurator. You should have at least a basic knowledge of TCP/IP networking concepts and topology.

  • Page 4: Document Conventions

    Syntax Conventions • The ES-305 may be referred to as the “ES-305”, the “device”, the “system”, the “switch” or the “product” in this User’s Guide. • Product labels, screen names, field labels and field choices are all in bold font.
  • Page 5 Document Conventions Icons Used in Figures Figures in this User’s Guide may use the following generic icons. The ES-305 icon is not an exact representation of your device. ES-305 Computer Notebook computer Server DSLAM Firewall Telephone Switch Router ES-305 User’s Guide...

  • Page 6: Safety Warnings

    • Do not use the device outside, and make sure all the connections are indoors. There is a remote risk of electric shock from lightning. • Do NOT obstruct the device ventilation slots, as insufficient airflow may harm your device. ES-305 User’s Guide...
  • Page 7 Safety Warnings This product is recyclable. Dispose of it properly. ES-305 User’s Guide...
  • Page 8 Safety Warnings ES-305 User’s Guide...

  • Page 9: Table Of Contents

    Contents Overview Contents Overview Introduction ..........................19 Introducing the ES-305 ......................21 Introducing the Web Configurator ....................25 Tutorial ............................27 Web Configurator and Troubleshooting ................43 System Screens ........................45 VLAN Screens ........................... 53 Troubleshooting ......................... 61 Appendices and Index ......................67...
  • Page 10 Contents Overview ES-305 User’s Guide...

  • Page 11: Table Of Contents

    Chapter 1 Introducing the ES-305......................21 1.1 Overview ..........................21 1.2 Ways to Manage the ES-305 ....................21 1.3 Good Habits for Managing the ES-305 ................22 1.4 LEDs ............................ 22 Chapter 2 Introducing the Web Configurator ..................25 2.1 Web Configurator Overview ....................25 2.2 Accessing the Web Configurator ..................
  • Page 12 6.1 Power, Hardware Connections, and LEDs ................61 6.2 ES-305 Access and Login ....................62 6.3 Internet Access ........................63 6.4 Resetting the ES-305 to Its Factory Defaults ............... 64 Part III: Appendices and Index.............. 67 Appendix A Product Specifications..................69 Appendix B Pop-up Windows, JavaScripts and Java Permissions ........
  • Page 13 Table of Contents Index............................115 ES-305 User’s Guide...
  • Page 14 Table of Contents ES-305 User’s Guide...

  • Page 15: List Of Figures

    List of Figures List of Figures Figure 1 Internet Access through the ES-305 ..................21 Figure 2 LEDs ............................22 Figure 3 Top Bar Navigation Icons ......................26 Figure 4 Tutorial: VLAN Group Settings Example .................. 28 Figure 5 Tutorial: Port VID Settings Example ..................28 Figure 6 Tutorial: Combining Group VLAN and PVID Settings ...............
  • Page 16 Figure 61 Subnetting Example: After Subnetting ................... 95 Figure 62 Conflicting Computer IP Addresses Example ................ 99 Figure 63 Conflicting Computer IP Addresses Example ................ 99 Figure 64 Conflicting Computer and Router IP Addresses Example ............ 100 ES-305 User’s Guide...

  • Page 17: List Of Tables

    Table 21 Subnet 3 ..........................96 Table 22 Subnet 4 ..........................96 Table 23 Eight Subnets .......................... 96 Table 24 24-bit Network Number Subnet Planning ................97 Table 25 16-bit Network Number Subnet Planning ................97 Table 26 Commands Summary ......................103 ES-305 User’s Guide...
  • Page 18 List of Tables ES-305 User’s Guide...

  • Page 19: Introduction

    Introduction Introducing the ES-305 (21) Introducing the Web Configurator (25) Tutorial (27)

  • Page 21: Introducing The Es-305

    ES-305. 1.1 Overview The ES-305 is an intelligent five-port Ethernet switch. Use it to connect up to four devices to your network. The following figure shows the ES-305 (A) connecting several devices (1 ~ 4) and allowing them to communicate with one another and access the Internet through the Internet Service Provider’s network switch (B).

  • Page 22: Good Habits For Managing The Es-305

    Chapter 1 Introducing the ES-305 1.3 Good Habits for Managing the ES-305 Do the following things regularly to make the ES-305 more secure and to manage the ES-305 more effectively. • Change the username and password. Use a password that’s not easy to guess and that consists of different types of characters, such as numbers and letters.
  • Page 23 Chapter 1 Introducing the ES-305 Table 1 LEDs (continued) STATUS DESCRIPTION LAN 1 ~ 3 Amber The LAN port has a successful Ethernet connection. Blinking The LAN port has a successful Ethernet connection, and is sending or receiving data through the port.
  • Page 24 Chapter 1 Introducing the ES-305 ES-305 User’s Guide...

  • Page 25: Introducing The Web Configurator

    ES-305 (refer to the Quick Start Guide). aunch your web browser. "192.168.0.1" as the URL (default). Type 4 By default, the ES-305 has no username or password configured. Just click OK in the screen that appears. ES-305 User’s Guide...

  • Page 26: Navigating The Web Configurator

    The management session automatically times out when the time period set in the Idle Time Out field in the Administrator Settings screen expires (default five minutes). Simply log back into the ES-305 if this happens. 2.3 Navigating the Web Configurator The bar at the top of the screen contains several icons.

  • Page 27: Tutorial

    VLAN ID, or VID. 3.1.1 VLANs and the ES-305 The ES-305 lets you set up VLANs in two ways. In the VLAN > VLAN Group Settings screen, you can configure how the ES-305 deals with incoming frames by specifying which ports (LAN 1 ~ 4 and WAN) can belong to which VLANs (a port can accept frames from more than one VLAN).

  • Page 28: Figure 4 Tutorial: Vlan Group Settings Example

    The following figure shows how the Port VID Settings screen works. In this example, some of the data frames on the LAN 2 port arrive with VLAN information already in place, whereas other data frames do not have any. The ES-305 assigns a VLAN ID to the data frames without existing VLAN information.

  • Page 29: Example Scenario

    The following figure shows your network, and the VLANs you want to set up. The computer connected to the LAN 1 port on the ES-305 (A) can connect to the Internet, the IP phone connected to the LAN 2 port can connect to the VoIP service, and the computers connected to the LAN 2 and LAN 3 ports can communicate with one another.

  • Page 30: Figure 7 Tutorial: Three Vlans

    Take the following steps to configure this setup. 1 On a computer connected to the LAN 3 or 4 port, log into the ES-305 (see your Quick Start Guide for how to do this). Click VLAN > VLAN Group Settings. Here you can define which ports accept incoming traffic for each of your VLANs.

  • Page 31: Figure 8 Tutorial: Vlan Group Settings

    2 The first rule is the default preset rule that allows devices connected to any port to manage the ES-305 and freely exchange data. Do the following to modify the first rule to allow devices connected to the LAN 3 and 4 ports to communicate with one another and manage the ES-305.

  • Page 32: Figure 9 Tutorial: Vlan Group Settings Complete

    Figure 9 Tutorial: VLAN Group Settings Complete 6 Next, click VLAN > Port VID Settings. This screen allows you to specify the VLAN ID (VID) the ES-305 gives to data frames that arrive at each port without existing VLAN information.

  • Page 33: Figure 10 Tutorial: Port Vid Settings

    • In the WAN port’s PVID field, enter 600. In this scenario there should not be any traffic coming into the ES-305 on this port without a VLAN ID, but if there is it should be directed to LAN port 1. Furthermore, if you left the default PVID (1) the ES-305 could be managed through the WAN port.

  • Page 34: Using Snmp

    When you use the SNMP manager for the first time, or add a new device to your network, you must either scan the network for SNMP-capable devices (“nodes”) or specify each individual device’s IP address. In this example, you will scan for nodes. 1 Open the SNMP manager. Click Create New SNMP Node List. ES-305 User’s Guide...

  • Page 35: Figure 12 Tutorial: Snmp New Node List

    SNMP Profile field. Unless you have a specific reason to change these settings, leave them at their defaults and click OK. Figure 14 Tutorial: SNMP Node Discovery Window A progress window displays as the SNMP manager searches for nodes. ES-305 User’s Guide...

  • Page 36: Viewing Snmp Data

    Figure 16 Tutorial: SNMP Discovered Nodes 3.2.3 Viewing SNMP Data Once you have discovered all the SNMP-capable devices on your network, double-click the icon of the device you want to manage. The SNMP Info window displays, showing basic information about the device. ES-305 User’s Guide...

  • Page 37: Figure 17 Tutorial: Snmp Info

    SNMP agent. 3.2.3.1 Viewing SNMP Statistics To see statistics about the data provided by the ZyXEL Device’s SNMP agent, double-click Network in the manager’s navigation panel. The following screen displays, showing information on incoming and outgoing SNMP data. ES-305 User’s Guide...

  • Page 38: Figure 18 Tutorial: Snmp Statistics

    OID (Object IDentifier) and name, which uniquely identify it in the MIB. Click the SNMP Walker button and select the IP address of your ZyXEL Device from the list. Click Run. A screen similar to the following displays. ES-305 User’s Guide...

  • Page 39: Figure 20 Tutorial: Snmp Walk

    To read the specific information provided by the device’s MIB, right-click in the right-hand panel and select Display > MIB Specific from the menu that appears. The fields in the Value column change, displaying the values provided by the device’s MIB in an easily-readable format. ES-305 User’s Guide...

  • Page 40: Making Changes

    Figure 23 Tutorial: SNMP View > General The following screen displays. The System name, Contact and Location fields can be modified. Figure 24 Tutorial: SNMP General System Information 2 Enter the new information in the fields and click Set. ES-305 User’s Guide...

  • Page 41: Figure 25 Tutorial: Snmp New Information

    Chapter 3 Tutorial Figure 25 Tutorial: SNMP New Information 3 The next time you check the information (using the SNMP Walk feature, for example) you can see that the changes have been made. Figure 26 Tutorial: SNMP Changes Made ES-305 User’s Guide...
  • Page 42 Chapter 3 Tutorial ES-305 User’s Guide...

  • Page 43: Web Configurator And Troubleshooting

    Web Configurator Troubleshooting System Screens (45) VLAN Screens (53) Troubleshooting (61)

  • Page 45: System Screens

    System Screens This chapter discusses the ES-305’s System screens. 4.1 The System Status Screen This screen displays details of the ES-305 User’s Guide’s LAN settings and management information. Click System > System Status. The following screen displays. Figure 27 System Status The following table describes the labels in this screen.

  • Page 46: The Network Settings Screen

    This is the version number of the boot code currently installed on the ES- 305. 4.2 The Network Settings Screen Use this screen to configure the ES-305’s IP settings. Click System > Network Settings. The following screen displays. Figure 28 Network Settings...

  • Page 47: The Administrator Settings Screen

    Click this to return the fields in this screen to their last-saved settings. 4.3 The Administrator Settings Screen Use this screen to change the username and password information used to access the ES-305’s web configurator. You can also set the idle timeout in this screen.

  • Page 48: The Firmware Upgrade Screen

    Click this to return the fields in this screen to their last-saved settings. 4.4 The Firmware Upgrade Screen Use this screen to upload new firmware to the ES-305. The firmware determines the device’s available features and functionality. You can download new firmware releases from your nearest ZyXEL FTP site (or www.zyxel.com) to use to upgrade your device’s performance.

  • Page 49: Figure 30 Firmware Upgrade

    This field displays the date of the firmware currently installed on the ES- 305. Choose... Click this to locate the firmware file you wish to upload to the ES-305. Remember that you must decompress compressed (.zip) files before you can upload them.

  • Page 50: The Configuration Tools Screen

    Select this to turn the ES-305 off, then on. The settings on the ES-305 remain unchanged. Restore Factory Defaults Select this to return the ES-305 to its factory default settings. Its IP address will be 192.168.0.1 and the administrator username and password will be set.
  • Page 51 LABEL DESCRIPTION Backup Settings Select this to back up (save) the ES-305’s current configuration to a file on your computer. The backup configuration file will be useful in case you need to return to your previous settings. Note: Once your ES-305 is configured and functioning...
  • Page 52 Chapter 4 System Screens ES-305 User’s Guide...

  • Page 53: Vlan Screens

    H A P T E R VLAN Screens This chapter describes the ES-305’s VLAN (Virtual Local Area Network) screens. 5.1 Introduction to IEEE 802.1Q Tagged VLANs A tagged VLAN uses an explicit tag (VLAN ID) in the MAC header to identify the VLAN membership of a frame across bridges - they are not confined to the switch on which they were created.

  • Page 54: Management Vlan Id

    VLAN (the default management VLAN ID is 1) by default. If you set all the ports on the ES-305 to not be in the management VLAN, you cannot access the ES-305. You will need to reset it to its factory default settings if you want to make configuration changes.

  • Page 55: The Vlan Group Settings Screen

    DSCP values and the configured policies. 5.2 The VLAN Group Settings Screen Use this screen to set up IEEE 802.1Q VLAN tagging on the ES-305. You can configure up to eight VLAN rules. Each rule allows you to specify how each port deals with incoming packets.

  • Page 56: Figure 35 Vlan Group Settings

    Table 7 VLAN Group Settings LABEL DESCRIPTION Enable Select this to have the ES-305 use the rule. Leave it unselected if you do not want to use the rule. Enter the VLAN ID for this rule (1 ~ 4094). P1 ~ P4, WAN Select one of the following to configure the state of each of the ES-305’s...

  • Page 57: The Port Vid Screen

    Click this to return this screen to its last-saved settings. 5.3 The Port VID Screen Use this screen to configure the VLAN ID (VID) of each port on the ES-305. The ES-305 assigns a PVID (Port VLAN ID) and IEEE 802.1p priority level to outgoing untagged traffic from each port.

  • Page 58: The Diffserv Screen

    VLAN tag. 802.1p Priority Select a priority level (0-7) for the ES-305 to assign to packets on each port. A higher number indicates a higher priority. Click this to save your changes.

  • Page 59: Figure 38 Diffserv

    DSCP value you want to change on this port, select the new value from the list. DSCP to 802.1p The ES-305 can assign an IEEE 802.1p value based on a packet’s DSCP Mapping value. If the DSCP value is changed in the DSCP Codepoint Mapping fields of this screen, the new value is used for 802.1p mapping.
  • Page 60 Chapter 5 VLAN Screens ES-305 User’s Guide...

  • Page 61: Troubleshooting

    1 Make sure you are using the power adaptor or cord included with the ES-305. 2 Make sure the power adaptor or cord is connected to the ES-305 and plugged in to an appropriate power source. Make sure the power source is turned on.

  • Page 62: Access And Login

    Java enabled. See Appendix B on page 4 Make sure your computer is in the same subnet as the ES-305. (If you know that there are routers between your computer and the ES-305, skip this step.) • If there is no DHCP server on your network, make sure your computer’s IP address is in the same subnet as the ES-305.

  • Page 63: Internet Access

    2 You cannot log in to the web configurator while someone is using the web configurator or Telnet to access the ES-305. Log out of the ES-305 in the other session, or ask the person who is logged in to log out.

  • Page 64: Resetting The Es-305 To Its Factory Defaults

    6.4 Resetting the ES-305 to Its Factory Defaults If you reset the ES-305, you lose all of the changes you have made. The ES-305 re-loads its default settings. You have to make all of your changes again.
  • Page 65 Chapter 6 Troubleshooting ES-305 User’s Guide...
  • Page 66 Chapter 6 Troubleshooting ES-305 User’s Guide...

  • Page 67: Appendices And Index

    Appendices and Index Product Specifications (69) Setting up Your Computer’s IP Address (81) Pop-up Windows, JavaScripts and Java Permissions (75) IP Addresses and Subnetting (91) Command Interpreter (101) Legal Information (107) Customer Support (111) Index (115)

  • Page 69: Appendix A Product Specifications

    DiffServ-compliant network devices along the route based on the application types and traffic flow. DSCP / IEEE 802.1p The ES-305 can add IEEE 802.1p values to traffic on the network based mapping on their DSCP (DiffServ Code Point) value.

  • Page 70: Table 12 Switching Specifications

    DESCRIPTION Firmware Upgrade Download new firmware (when available) from the ZyXEL web site and use the web configurator or an FTP tool to put it on the ES-305. Note: Only upload firmware for your specific model! Configuration Backup & Make a copy of the ES-305’s configuration. You can put it back on the Restoration ES-305 later if you decide to revert back to an earlier configuration.

  • Page 71: Figure 39 Login Screen

    Please note that if there is no activity for longer than five minutes (default timeout period) after you log in, your ES-305 will automatically log you out. You will then have to telnet into the ES-305 again. You can use the web configurator to change the inactivity time out period.

  • Page 72: Figure 40 Snmp Management Model

    An SNMP managed network consists of two main types of component: agents and a manager. An agent is a management software module that resides in a managed device (the ES-305). An agent translates the local management information from the managed device into a form compatible with SNMP.

  • Page 73: Table 14 Snmp Interface Index To Physical And Virtual Port Mapping

    Appendix A Product Specifications Some traps include an SNMP interface index. The following table maps the SNMP interface indexes to the ES-305’s physical ports. Table 14 SNMP Interface Index to Physical and Virtual Port Mapping INTERFACE PORT eth0 eth1 LAN 4...
  • Page 74 Appendix A Product Specifications ES-305 User’s Guide...

  • Page 75: Appendix B Pop-Up Windows, Javascripts And Java Permissions

    1 In Internet Explorer, select Tools, Pop-up Blocker and then select Turn Off Pop-up Blocker. Figure 41 Pop-up Blocker You can also check if pop-up blocking is disabled in the Pop-up Blocker section in the Privacy tab. 1 In Internet Explorer, select Tools, Internet Options, Privacy. ES-305 User’s Guide...

  • Page 76: Figure 42 Internet Options: Privacy

    Alternatively, if you only want to allow pop-up windows from your device, see the following steps. 1 In Internet Explorer, select Tools, Internet Options and then the Privacy tab. 2 Select Settings…to open the Pop-up Blocker Settings screen. ES-305 User’s Guide...

  • Page 77: Figure 43 Internet Options: Privacy

    3 Type the IP address of your device (the web page that you do not want to have blocked) with the prefix “http://”. For example, http://192.168.167.1. 4 Click Add to move the IP address to the list of Allowed sites. Figure 44 Pop-up Blocker Settings ES-305 User’s Guide...

  • Page 78: Figure 45 Internet Options: Security

    3 Scroll down to Scripting. 4 Under Active scripting make sure that Enable is selected (the default). 5 Under Scripting of Java applets make sure that Enable is selected (the default). 6 Click OK to close the window. ES-305 User’s Guide...

  • Page 79: Figure 46 Security Settings - Java Scripting

    2 Click the Custom Level... button. 3 Scroll down to Microsoft VM. 4 Under Java permissions make sure that a safety level is selected. 5 Click OK to close the window. Figure 47 Security Settings - Java ES-305 User’s Guide...

  • Page 80: Figure 48 Java (Sun)

    1 From Internet Explorer, click Tools, Internet Options and then the Advanced tab. 2 Make sure that Use Java 2 for <applet> under Java (Sun) is selected. 3 Click OK to close the window. Figure 48 Java (Sun) ES-305 User’s Guide...

  • Page 81: Appendix C Setting Up Your Computer's Ip Address

    After the appropriate TCP/IP components are installed, configure the TCP/IP settings in order to "communicate" with your network. If you manually assign IP information instead of using dynamic assignment, make sure that your computers have IP addresses that place them in the same subnet as the ES-305’s LAN port. Windows 95/98/Me Click Start, Settings, Control Panel and double-click the Network icon to open the Network window.

  • Page 82: Figure 49 Windows 95/98/Me: Network: Configuration

    2 Select Client and then click Add. 3 Select Microsoft from the list of manufacturers. 4 Select Client for Microsoft Networks from the list of network clients and then click 5 Restart your computer so the changes you made take effect. ES-305 User’s Guide...

  • Page 83: Figure 50 Windows 95/98/Me: Tcp/Ip Properties: Ip Address

    • If you do not know your DNS information, select Disable DNS. • If you know your DNS information, select Enable DNS and type the information in the fields below (you may not need to fill them all in). ES-305 User’s Guide...

  • Page 84: Figure 51 Windows 95/98/Me: Tcp/Ip Properties: Dns Configuration

    5 Click OK to save and close the TCP/IP Properties window. 6 Click OK to close the Network window. Insert the Windows CD if prompted. 7 Turn on your ES-305 and restart your computer when prompted. Verifying Settings 1 Click Start and then Run.

  • Page 85: Figure 52 Windows Xp: Start Menu

    Appendix C Setting up Your Computer’s IP Address Figure 52 Windows XP: Start Menu 2 In the Control Panel, double-click Network Connections (Network and Dial-up Connections in Windows 2000/NT). Figure 53 Windows XP: Control Panel 3 Right-click Local Area Connection and then click Properties. ES-305 User’s Guide...

  • Page 86: Figure 54 Windows Xp: Control Panel: Network Connections: Properties

    • If you have a dynamic IP address click Obtain an IP address automatically. • If you have a static IP address click Use the following IP Address and fill in the IP address, Subnet mask, and Default gateway fields. • Click Advanced. ES-305 User’s Guide...

  • Page 87: Figure 56 Windows Xp: Internet Protocol (Tcp/Ip) Properties

    To manually configure a default metric (the number of transmission hops), clear the Automatic metric check box and type a metric in Metric. • Click Add. • Repeat the previous three steps for each default gateway you want to add. • Click OK when finished. ES-305 User’s Guide...

  • Page 88: Figure 57 Windows Xp: Advanced Tcp/Ip Properties

    • If you know your DNS server IP address(es), click Use the following DNS server addresses, and type them in the Preferred DNS server and Alternate DNS server fields. If you have previously configured DNS servers, click Advanced and then the DNS tab to order them. ES-305 User’s Guide...

  • Page 89: Figure 58 Windows Xp: Internet Protocol (Tcp/Ip) Properties

    Properties window. 10 Close the Network Connections window (Network and Dial-up Connections in Windows 2000/NT). 11 Turn on your ES-305 and restart your computer (if prompted). Verifying Settings 1 Click Start, All Programs, Accessories and then Command Prompt. 2 In the Command Prompt window, type "ipconfig" and then press [ENTER]. You can also open Network Connections, right-click a network connection, click Status and then click the Support tab.
  • Page 90 Appendix C Setting up Your Computer’s IP Address ES-305 User’s Guide...

  • Page 91: Appendix D Ip Addresses And Subnetting

    Therefore, each octet has a possible range of 00000000 to 11111111 in binary, or 0 to 255 in decimal. The following figure shows an example IP address in which the first three octets (192.168.1) are the network number, and the fourth octet (16) is the host ID. ES-305 User’s Guide...

  • Page 92: Figure 59 Network Number And Host Id

    Subnet masks can be referred to by the size of the network number part (the bits with a “1” value). For example, an “8-bit mask” means that the first 8 bits of the mask are ones and the remaining 24 bits are zeroes. ES-305 User’s Guide...

  • Page 93: Table 16 Subnet Masks

    For example, 192.1.1.0 /25 is equivalent to saying 192.1.1.0 with subnet mask 255.255.255.128. The following table shows some possible subnet masks using both notations. Table 18 Alternative Subnet Mask Notation ALTERNATIVE LAST OCTET LAST OCTET SUBNET MASK NOTATION (BINARY) (DECIMAL) 255.255.255.0 0000 0000 255.255.255.128 1000 0000 ES-305 User’s Guide...

  • Page 94: Figure 60 Subnetting Example: Before Subnetting

    The “borrowed” host ID bit can have a value of either 0 or 1, allowing two subnets; 192.168.1.0 /25 and 192.168.1.128 /25. The following figure shows the company network after subnetting. There are now two sub- networks, A and B. ES-305 User’s Guide...

  • Page 95: Figure 61 Subnetting Example: After Subnetting

    Table 19 Subnet 1 LAST OCTET BIT IP/SUBNET MASK NETWORK NUMBER VALUE IP Address (Decimal) 192.168.1. IP Address (Binary) 11000000.10101000.00000001. 00000000 Subnet Mask (Binary) 11111111.11111111.11111111. 11000000 Subnet Address: Lowest Host ID: 192.168.1.1 192.168.1.0 Broadcast Address: Highest Host ID: 192.168.1.62 192.168.1.63 ES-305 User’s Guide...

  • Page 96: Table 20 Subnet 2

    Similarly, use a 27-bit mask to create eight subnets (000, 001, 010, 011, 100, 101, 110 and 111). The following table shows IP address last octet values for each subnet. Table 23 Eight Subnets SUBNET LAST BROADCAST SUBNET FIRST ADDRESS ADDRESS ADDRESS ADDRESS ES-305 User’s Guide...

  • Page 97: Table 24 24-Bit Network Number Subnet Planning

    SUBNET 255.255.128.0 (/17) 32766 255.255.192.0 (/18) 16382 255.255.224.0 (/19) 8190 255.255.240.0 (/20) 4094 255.255.248.0 (/21) 2046 255.255.252.0 (/22) 1022 255.255.254.0 (/23) 255.255.255.0 (/24) 255.255.255.128 (/25) 255.255.255.192 (/26) 1024 255.255.255.224 (/27) 2048 255.255.255.240 (/28) 4096 255.255.255.248 (/29) 8192 ES-305 User’s Guide...

  • Page 98: Configuring Ip Addresses

    You must also enable Network Address Translation (NAT) on the ES-305. Once you have decided on the network number, pick an IP address for your ES-305 that is easy to remember (for instance, 192.168.1.1) but make sure that no other device on your network is using that IP address.

  • Page 99: Figure 62 Conflicting Computer Ip Addresses Example

    LAN and WAN addresses must be on different subnets. In the following example, the LAN and WAN are on the same subnet. The LAN computers cannot access the Internet because the router cannot route between networks. Figure 63 Conflicting Computer IP Addresses Example ES-305 User’s Guide...

  • Page 100: Figure 64 Conflicting Computer And Router Ip Addresses Example

    LAN port both use 192.168.1.1 as the IP address. The computer cannot access the Internet. This problem can be solved by assigning a different IP address to the computer or the router’s LAN port. Figure 64 Conflicting Computer and Router IP Addresses Example ES-305 User’s Guide...

  • Page 101: Appendix E Command Interpreter

    • Type quit to close the session when finished. Command Examples This section provides some examples of commands you can use on the ES-305. This list is intended as a general reference of examples. The commands available in your ES-305 may differ from the examples given here.

  • Page 102: Commands Summary

    Root Directory When you first log in to the command interface, you are in the root directory. The CMD> prompt displays. From here you can access all of the ES-305’s command directories. The command directories are as follows. • cfg: these commands manage configuration settings.

  • Page 103: Table 26 Commands Summary

    CFG> del SNMP_SYSLOC These commands let you see and save changes prof to the ES-305’s profile (its configuration settings). Return profile to initial factory default settings. All init configuration changes are lost. Save all current profile settings to non-volatile save memory.
  • Page 104 Displays current Address Resolution Protocol show table entries. Clears all Address Resolution Protocol table flush entries. Use this command to log off an http user logged in http logout to the ES-305’s web configurator. ES-305 User’s Guide...
  • Page 105 ES-305. Use this command to see the total and available memory on the ES-305 Use this command to reboot the ES-305. Note that this command does not reset the device to its default configuration.
  • Page 106 Appendix E Command Interpreter ES-305 User’s Guide...

  • Page 107: Appendix F Legal Information

    ZyXEL Communications Corporation. Published by ZyXEL Communications Corporation. All rights reserved.
  • Page 108 ZyXEL. This warranty shall not apply if the product has been modified, misused, tampered with, damaged by an act of God, or subjected to abnormal working conditions. ES-305 User’s Guide...
