ZyXEL Communications ES-315 Quick Start Manual

ZyXEL Communications ES-315 Quick Start Manual

Intelligent layer 2 managed switch
Hide thumbs Also See for ES-315:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
ES-315
Intelligent Layer 2 Managed Switch

Quick Start Guide

Version 3.70
7/2007
Edition 1
DEFAULT LOGIN
IP Address http://192.168.1.1
Username
Password
admin
1234
Copyright © 2007. All rights reserved

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ES-315 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ZyXEL Communications ES-315

Summary of Contents for ZyXEL Communications ES-315

  • Page 1: Quick Start Guide

    Intelligent Layer 2 Managed Switch Quick Start Guide Version 3.70 7/2007 Edition 1 DEFAULT LOGIN IP Address http://192.168.1.1 Username admin Password 1234 Copyright © 2007. All rights reserved...
  • Page 2 ES-315 Quick Start Guide 1 Overview Your ES-315 is an intelligent layer-2 Ethernet switch. Use it to connect up to four Ethernet devices to your network. The following example shows your ES-315 (A) connecting several devices (1 ~ 4) and allowing them to communicate with one another and access the Internet through the Internet Service Provider’s network switch (B).
  • Page 3 3 POWER: using the included power adaptor, connect the POWER socket to an appropriate power source. Use only the power adaptor that came with the ES-315. Look at the LEDs (lights) on the front of the ES-315. ES-315 Quick Start Guide...

  • Page 4: Set Up Your Computer's Ip Address

    Make sure the device to which the corresponding port is connected is turned on and working normally. If this does not help, turn the ES-315 off and on again. 2.1 Set Up Your Computer’s IP Address This section shows you how to set up your computer to access the ES-315.
  • Page 5 3 Right-click Local Area Connection and then click Properties. 4 Select Internet Protocol (TCP/IP) (under the General tab in Windows XP) and click Properties. 5 The Internet Protocol TCP/IP Properties screen opens (the General tab in Windows XP). ES-315 Quick Start Guide...
  • Page 6 ES-315 Quick Start Guide Note down your computer’s current IP settings before you change them. You may need them later. 6 Select Use the following IP address and fill in the IP address (choose one in the range 192.168.1.2 - 192.168.1.254), Subnet mask (255.255.255.0), and...
  • Page 7 Close the Network Connections window. 3 Log Into the Web Configurator Take the following steps to access the ES-315 for initial configuration. Use Internet Explorer 6.0 and later versions or Netscape Navigator 7.0 and later versions with JavaScript enabled and pop-up blocking disabled.
  • Page 8 Blocker and then select Turn Off Pop-up Blocker). Reload the web page. If this does not help, make sure the IP addresses and subnet masks of the ES-315 and the computer are in the same IP address range (see section 2.1).

  • Page 9: Set The Password

    ES-315 Quick Start Guide The Status screen displays. 4 Set the Password For security reasons, you should change the password when you first log in. Take the following steps to do this.
  • Page 10 ES-315 Quick Start Guide 1 Click Management in the navigation panel on the left of the screen. In the menu that displays, click Access Control. Then, click Logins. 2 The following screen displays. 3 Enter the login information you want to use, as follows.
  • Page 11 Be sure to record the new password and keep it in a safe place. If you forget this information, you will need to reset the ES-315 to its factory defaults (press the Reset button in for 3 ~ 5 seconds).

  • Page 12: Set Up Your Network

    ES-315 Quick Start Guide 5 Set Up Your Network This section shows how to set the ES-315’s IP address so it is in the same subnet as the other devices on your network. If it is not in the same subnet, it cannot communicate with the other devices.
  • Page 13 ES-315 Quick Start Guide The following screen displays. If you change the ES-315’s IP address, you will need to use the new one in order to access the web configurator once you click OK.

  • Page 14: Using Dhcp

    If this does not help, contact your network administrator or Internet Service Provider (ISP). 5.1 Using DHCP If you want your ES-315 to get an IP address automatically, do the following. • Select DHCP Client in the Default Management IP Address field.

  • Page 15: Using A Static Ip Address

    • Click Apply, then click Save. Next time you want to access the ES-315’s web configurator, you must use the IP address assigned to the ES-315 by the DHCP server. • Return your computer’s IP settings to their previous values, if necessary.
  • Page 16 6 Wall-mount the ES-315 Take the following steps to hang your ES-315 on a wall. 1 Select a position free of obstructions on a sturdy wall. 2 Drill two holes for the screws, exactly 108 mm apart.
  • Page 17 They need to hold the weight of the ES-315 with the connection cables. 5 Align the holes on the back of the ES-315 with the screws on the wall. Hang the ES-315 on the screws. The following are dimensions of an M4 tap screw and masonry plug used for wall mounting.
  • Page 18 ES-315 Quick Start Guide Viewing a Product’s Certification(s) 1 Go to www.zyxel.com. 2 Select your product from the drop-down list box on the ZyXEL home page to go to that product's page. 3 Select the certification you wish to view from this...
  • Page 19 ES-315 Quick Start Guide...
