Front & Back Panel Descriptions - TC-Helicon VoiceTone Correct Product Manual

1. Guide Output
Alternate output with full time pitch correction when it's
only desired in stage monitors. Diagram below shows
possible routings
2. Main Output
Typical output for use with sound system. Diagram
below shows possible routings.
3. Mic Input
Microphone connection
P P I I T T C C H H E E N N A A B B L L E E D D
POWER
L L E E E E F F F F E E C C T T S S
E E N N A A B B L L E E D D
No
Yes
Yes
No
Front & Back Panel Descriptions
1
M M A A I I N N O O U U T T P P U U T T
No Dry
No Dry
Yes LE Effects + Pitch
Yes LE Effects
2
3
G G U U I I D D E E O O U U T T P P U U T T
Pitch
Pitch
LE Effects + Pitch
LE Effects + Pitch
13
