TC-Helicon HarmonyControl Product Manual page 7

Quick Start
Step 3:
Connect the included MIDI cable or any standard cable
from the MIDI Out jack on HarmonyControl to the
MIDI input on your harmony processor.
If your harmony processor is on the list of Auto- or
Detect-compatible units (see the Compatibility Chart
in this manual), connect the second set of jacks on the
included MIDI cable or any standard MIDI cable
between the MIDI output of your harmony processor
and HarmonyControl.
MIDI
4
IN
MIDI MIDI
Out
Harmony
Processor
8
GUITAR
OUT IN OUT
In
Step 4:
Connect HarmonyControl's power adapter to your
wall power socket and then to the Power input jack on
the product.When power is applied, one or more LEDs
on the unit will flash momentarily.
If your harmony processor is Auto-compatible and
you've connected the MIDI cables correctly, the Auto
LED will light a moment after power-up.
MIDI
4
IN
GUITAR
OUT IN OUT
8
