Tripp Lite SmartRack SRWF5U Quick Manual

SmartRack 5U Low-Profile Wall Mount Rack
Enclosure Cabinet
MODEL NUMBER: SRWF5U
Description
The SRWF5U 5U+2 Low-Profile Wall Mount Rack Enclosure Cabinet is designed to integrate wall-mounting,
easy equipment access, and cable management in IT network applications with limited floor space. Ventilated
front door and bottom panels allow generous airflow to keep equipment operating safely. Adjustable horizontal
rack rails securely mount 5U of 19" rackmount equipment with M6 or they can be reversed for securing with
12-24 threaded mounting holes. The patch panel mounting brackets provide space for up to 2U of patch panels
with integral slide-out feature for easy cable access. Supports up to 150 lbs of equipment.
Features
5U low-profile wall-mounted enclosure
Adjustable horizontal mounting depths from 17" to 20" inches
Slide-out mounting brackets provides 2U of space for patch panel(s)
Ventilated front door and bottom panels for increased airflow
Locking, reversible front door
Multiple keyhole mounting slots for wall mounting
Fully assembled for quick installation
Meets all enclosure requirements towards PCI DSS (Payment Card Industry Data Security Standard) compliance

Specifications

PHYSICAL
Installed whole system maximum
rack depth (inches)
Installed whole system maximum
rack depth (cm)
20
50.80
1 / 3
Highlights
Designed for IT and education
environments where equipment
needs to be secure and out of the
way
5U with adjustable/reversible
rackmount rails
2U slide-out mounting brackets
for patch panels
Locking, reversible front door
Fully assembled for quick
installation
Meets all enclosure requirements
towards PCI DSS (Payment Card
Industry Data Security Standard)
Compliance
Applications
IT network environments, back office,
and network closets with limited floor
space and classrooms where
equipment needs to be secure and out
of the way of students.
Package Includes
SRWF5U Low-profile wall-mount
enclosure
(12) M6 screws
(12) M6 cup washers
(12) 12-24 screws
(2) Keys
Owner's Manual
