Tripp Lite SmartRack SRWF5U36 Owner's Manual

SmartRack
®
5U 2U
5 Rack Units 2U Patch Panel
Bracket
A Front Door
(Lockable/Reversible)
B Top Panel Door
(Lockable)
C Horizontal Mounting Rails
(Adjustable/Reversible)
D
5U Vertical Mounting Brackets
E
2U Slide-Out Patch Panel
Mounting Brackets
F
Cable Access Holes
G
Vents
H
Wall-Mounting Slots
I
Keys
Also Includes: Owner's Manual and
rackmount equipment mounting
hardware (12 M6 screws, 12 M6 cup
washers and 12 12-24 screws).
H
REAR VIEW

Specifications

Model
Rack Spaces
Equipment Mounting Depth
Load Rating*
Unit Dimensions (H x W x D)
Shipping Dimensions (H x W x D) 45.5 x 28 x 12 in. (1155 x 711 x 304 mm)
Unit Weight
Shipping Weight
Standards
* The load rating includes the combined weight of the unit and installed equipment. The unit must be
mounted to a stable surface with user-supplied anchors capable of bearing the full load. Tripp Lite
has a policy of continuous improvement. Specifications are subject to change without notice.
SRWF5U36
Low-Profile Wall-Mount Rack Enclosure Cabinet
150
150 lb. Sturdy Steel
Load Rating Construction
F
I
SRWF5U36
5U
Up to 36 in. (914 mm)
150 lb. (68 kg)
43.2 x 25.6 x 9.7 in. (1097 x 650 x 245 mm)
55 lb. (25 kg)
77.8 lb. (35 kg)
Tested to EIA-310-E, NOM, RoHS, PCI-DSS
MODEL:
EIA/ECA
310-E
Locking Doors Accommodates
& Side Panels Standard 19-inch
Equipment
E
C
D
G
• Wall-mount enclosures provide convenient, locking
storage for rackmount IT devices and other equipment
that should be off the floor, out of the way and secure
• Low-profile design with vertical equipment mounting
is ideal for back office or network closet applications
where space is limited
• 2U slide-out mounting brackets located at the top of
the unit provide space for separate patch panels and
allow for easy cable access
SEE NEXT PAGE FOR DETAILED UNIT MEASUREMENTS
Convenient Adjustable
Cable Access Mounting Rails
G
A
