Tripp Lite PDU3VN10L2120 Quick Manual

3-Phase Monitored PDU, 5.7 kW, 36 208V outlets (30
C13, 6 C19), 10-ft. NEMA L21-20P 20A input, 0U
vertical mount
MODEL NUMBER: PDU3VN10L2120
Description
Tripp Lite 3 phase Monitored PDU / Power Distribution Unit offers real-time remote monitoring of voltage,
frequency and load levels via built-in network connection. PowerAlert interface supports custom notification of
user-specified remote conditions via email, secure web, SNMP, Telnet or SSH interface. PDU output current
consumption in amps is displayed per-phase via front panel lighted digital display and can be monitored remotely
to warn of potential overloads before critical IT mains breakers trip.
Features
5.7kW 3 phase 208V Monitored Power Distribution Unit / PDU with built-in web/network interface
Attached NEMA L21-20P 20A (3P+N+E) 208V 3 phase input plug with 10 ft. / 3m cord
0U, 70 in. / 178cm vertical form factor supports installation in 2 or 4 post equipment racks
36 total 208V outlets (30 C13, 6 C19) arranged in three breakered single phase output load banks
Lighted display with scroll-button reports power consumption in amps for all 3 loading banks, IP-address
self-identification and 180 degree display rotation for overhead or raised floor power feeds
Built-in SNMP/ethernet interface reports voltage, frequency and PDU loading per-phase via network or secure web browser interface with options for user
specified alarm and notification thresholds
Supports in-rack environmental reporting with optional ENVIROSENSE temperature / humidity sensor and rack access notification with up to 4 optional
SRSWITCH door sensors
DHCP/Manual configuration support
10/100 Mbps auto-sensing allows optimal communication with 10/100 Base-T networks
Real-time clock backup maintains the time of day and date even if the PDU is unpowered
Tiered access privileges allow an administrator and a guest to login via web browser for monitoring
Alert notifications via email or SNMP traps offer immediate event notification
Firmware upgrade ability supports future product enhancements
Supports HTTP, HTTPS, PowerAlert Network Management System, SMTP, SNMPv1, SNMPv2, Telnet, SSH, FTP, DHCP, BOOTP, NTP protocols
1 / 4
Highlights
Monitored 5.7kW 3 Phase 208V
PDU; 70 in. / 178cm 0U vertical
rackmount
Reports voltage, frequency and
load per-phase via built in
ethernet interface
Visual current meter; Toolless
button-mount installation
NEMA L21-20P 20A (3P+N+E)
208V 3 phase input; 10 ft. / 3m
line cord
30 C13 & 6 C19 single phase
outlets; Included cord retention
brackets
Temperature, humidity and
contact closure monitoring options
Applications
Ideal for 3 phase network
configurations in datacenters and
heavily configured equipment racks
Package Includes
Monitored rackmount PDU with
pre-installed mounting buttons
Cord retention brackets
Spare installation buttons (2
9mm / 4 6mm)
Rack mounting brackets
Owner's manual
