FULL HD Color Camera
CSDW2M60CM28
SPECIFICATIONS

TABLE OF CONTENTS

RESTRICTION FOR USE ················································1
CASES FOR INDEMNITY···············································2
USAGE PRECAUTIONS··················································3
1.INTRODUCTION ·······················································5
2.FEATURES··································································5
3.COMPONENT·····························································6
4.OPTIONAL PARTS ·····················································6
5.FUNCTION ·································································7
6.SPECIFICATION·······················································10
7.GUARANTEE ···························································17
8.SERVICE ···································································17
9.APPEARANCE ·························································18
Printed On Recycled Paper .
D4176244A

Advertisement

   Related Manuals for Toshiba CSDW2M60CM28

   Summary of Contents for Toshiba CSDW2M60CM28

  • Page 1: Table Of Contents

    FULL HD Color Camera CSDW2M60CM28 SPECIFICATIONS TABLE OF CONTENTS RESTRICTION FOR USE ················································1 CASES FOR INDEMNITY···············································2 USAGE PRECAUTIONS··················································3 1.INTRODUCTION ·······················································5 2.FEATURES··································································5 3.COMPONENT·····························································6 4.OPTIONAL PARTS ·····················································6 5.FUNCTION ·································································7 6.SPECIFICATION·······················································10 7.GUARANTEE ···························································17 8.SERVICE ···································································17 9.APPEARANCE ·························································18 Printed On Recycled Paper . D4176244A...

  • Page 2: Restriction For Use

    RESTRICTION FOR USE ● Should the equipment be used in the following conditions or environments, give consideration to safety measures and inform us of such usage: 1.:Use of the equipment in the conditions or environment contrary to those specified, or use outdoors.

  • Page 3: Cases For Indemnity

    CASES FOR INDEMNITY ● ● ● ● In the case damage or losses are caused by fire, earthquake, or other acts of God, acts by a third party, deliberate or accidental misuse by the user, or use under extreme operating conditions. ●...

  • Page 4: Usage Precautions

    USAGE PRECAUTIONS ● Handle carefully Do not drop the equipment or allow it to be subject to strong impact or vibration, as such action may cause malfunctions. Further, do not damage connected cables, since this may cause wire breakage. ● Environmental operating conditions Do not use the product in locations where the ambient temperature or humidity exceeds the specifications.

  • Page 5

    ● Occurrence of noise on the screen If an intense magnetic or electromagnetic field is generated near the camera or connected cables, noise may be generated on the screen. If this occurs, move the camera or the cable. ●If the equipment is not to be used for a long duration Turn off power to the camera for safety and attach the lens cap to the camera to protect the image pickup surface.

  • Page 6: Introduction

    1. . . . INTRODUCTION This HD color camera is a unit type medical camera utilized 1/2.8 inch sensor. A picture output is DVI-D, so that you can get high-speed and high-resolution picture. Because this camera can connect a monitor directly, it is suitable for use of observation. 2.FEATURES (1) High-frame rate This camera output a picture size of the FULL HD with 1920×1080/60p or 1920×1080/60i.

  • Page 7: Component

    ※No DVI-D cable, Mini-USB cable for camera control and Lens attached to this camera. 4. . . . OPTIONAL PARTS ・AC Adapter SPU16A-105-ASN ・AC Cable APC1025-01P (Only in Japan) ※Please contact our business charge for detail of option unit. <Connection example> DVI-D cable Monitor AC adapter AC cable Lens CSDW2M60CM28 D4176244A...

  • Page 8: Function

    5. . . . FUNCTION (1) Setup-level setting It is possible to set the setup-level. A setting range is -16LSB~+16LSB. (Factory setting:8LSB) (2) Gain setting There are 2 modes of MANU(manual) mode and AUTO mode. (Factory setting:AUTO) A setting range is -6dB~+12dB. AUTO mode always regulates gain depending on the brightness of an object.

  • Page 9

    (5) Aperture It is possible to set aperture correction revision of the output picture. A setting range is 8 phases (0~7) each High frequency and Low frequency. (Factory setting:3) ・Phase up : Picture’s edge is emphasized. (6) Gamma correction It is possible to set gamma correction of the output picture with 17 phases(0~16). (Factory setting:5) ・Phase up : The shading of the shade become clear.

  • Page 10

    (10) Grid It is possible to show a monitor screen grid lines. You can regulate the grid interval by one pixel of unit and set the following items. ・Grid type Translucent ・Grid interval :4~1920 Vertical Horizontal :4~1080 ・Grid Width 1 pixel ・Grid color Changeable (11) Color matrix...

  • Page 11: Specification

    6. . . . SPECIFICATION [ [ [ [ Electronic Specification] ] ] ] (1) Image sensor 1/2.8 type CMOS sensor ・Total pixels 2144(H)×1588(V) ・Valid pixels 2096(H)×1561(V) ・Valid number of output pixels 1920(H)×1080(V) ・Pixel size 2.5µm(H)×2.5µm(V) ・Scanning area 1/2.8 type (2) Scanning system Progressive (3) Synchronization system...

  • Page 12

    (10) White balance MWB / OPWB / AWB / PresetWB change (Fatory setting:OPWB) ・MWB (Manual white balance) Corrective range 3000K~6500K Setting method R-gain and B-gain can be set independently. (0~+12dB each R and B) ・OPWB (One push white balance) Corrective range 3000K~6500K Detection area Center of the screen...

  • Page 13

    (16) Power source ・Dc connector supply DC 12V± 10% (Ripple voltage 50mV ・Camera control connector supply DC 5V± 5% (Ripple voltage 50mV ※ When both DC cable and Mini-USB cable for camera control were connected, +12V from DC cable is given priority. ※A note There is a possibility that the camera malfunction according to falling supply voltage depending on a Mini-USB cable for camera control to use.

  • Page 14

    [ [ [ [ Internal sync specification] ] ] ] (1) Pixel clock rate 148.500/1.001MHz±100ppm (2) Scanning rate Horizontal 67.433kHz Vertical 59.94Hz [ [ [ [ Electronic shutter specification] ] ] ] (1) Shutter system Rolling shutter (2) Shutter speed MANU / AUTO change (Fatory setting:AUTO) ・MANU(9 phase) PRESET setting...

  • Page 15

    [ [ [ [ Machine externals specification] ] ] ] (1) Dimensions 44mm(W) × 34mm(H) × 77mm(D) (Protruding portions such as screws and connectors are not included.) (2) Weight Approx. 100g (3) lens mount C-mount (4) Camera body grounding Conductive between circuit GND and camera body / Insulation status [...

  • Page 16

    [ [ [ [ Connecter Description] ] ] ] (1) DVI-D connector Picture output connector ・Connector model (Camera side) XM4M-2432-1312 (OMRON) ・Pin assignment Pin No. Function TX2- TX2+ TX2/4 Shield TX4-(N.C.) TX4+(N.C.) DDC Clock DDC Data N.C. 9 10 11 12 13 14 15 16 TX1- 17 18 19 20 21 22 23 TX1+...

  • Page 17

    (3) Power supply connector This is a connector for +12V power supply. ・Connector model (Camera side) LGP3831-0200F (SMK) ・Conformity plug standard EIAJ RC-5320A voltage category 4 (4) Lens control Connector This is a connector for control auto Iris lens. ・Control system DC control ・Connector model (Camera side) D4-157J-250 (TECHNICAL ELECTRON)

  • Page 18: Guarantee

    7. . . . GUARANTEE The period of guarantee is 12 months after the product delivery. If any trouble because of responsibility of our company occurred during the period, we repair it free of charge according to [SERVICE]. But in the case of following, guarantee becomes inapplicable. ・The trouble because of an error in use and unfair repair and remodeling.

  • Page 19: Appearance

    9. . . . APPEARANCE D4176244A...

  • Page 20

    (International Business Department) Phone : +81-42-589-8771 : +81-42-589-8774 URL : http://www.toshiba-teli.co.jp/ Distributor This product must be classified for disposal according to the laws of each country and municipal laws. Information contained in this document is subject to change without prior notice.
