- Page 1 Operating Manual - English PRIMERGY SX910 S1 Storage Blade Operating Manual Edition March 2011...
-
Page 2: Copyright And Trademarks
– The contents of this manual may be revised without prior notice. – Fujitsu assumes no liability for damages to third party copyrights or other rights arising from the use of any information in this manual. – No part of this manual may be reproduced in any form without the prior written permission of Fujitsu. -
Page 3: Before Reading This Manual
Before reading this manual For your safety This manual contains important information for safely and correctly using this product. Carefully read the manual before using this product. Pay particular attention to the accompanying manual "Safety Notes and Regulations" and ensure these safety notes are understood before using the product. - Page 4 (hereafter, "high safety use"). Customers should not use this product for high safety use unless measures are in place for ensuring the level of safety demanded of such use. Please consult the sales staff of Fujitsu if intending to use this product for high safety use.
- Page 5 Only for the Japanese market: Although described in this manual, some sections do not apply to the Japanese market. These options and routines include: – USB Flash Module (UFM) – CSS (Customer Self Service) – Replacing the lithium battery Operating Manual SX910 S1...
- Page 6 Operating Manual SX910 S1...
-
Page 7: Table Of Contents
Contents Introduction ......9 Concept and target groups for this manual ..10 Documentation overview . - Page 8 Contents Putting the Storage Blade into operation ... 41 Troubleshooting and tips ....43 Index .
-
Page 9: Introduction
Introduction Figure 1: PRIMERGY SX910 S1 storage blade The PRIMERGY SX910 S1 storage blade is used as a storage subsystem for the PRIMERGY BX900 S1 blade server and the BX400 S1 blade server and their successor models. The PRIMERGY SX910 S1 storage blade allows an SAS tape drive to be installed together with the corresponding controller and occupies one bay in the PRIMERGY BX900 S1 and BX400 S1 system units. -
Page 10: Concept And Target Groups For This Manual
Introduction Up to six PRIMERGY SX910 S1 storage blades can be installed in the BX900 S1 system unit. Up to four PRIMERGY SX910 S1 storage blades can be installed in the BX400 S1 system unit. Concept and target groups for this manual This operating manual shows you how to install the storage blade in the basic unit, how to start up the storage blade and how to operate it. -
Page 11: Performance Features
For the Japanese market please use the URL: http://primeserver.fujitsu.com/primergy/manual.html. Performance features The PRIMERGY SX910 S1 storage blade is fitted with a SAS controller of the LSI 1064E type, which controls a tape drive of the LTO3HH, LTO4HH and LTO5HH types with SAS interface. -
Page 12: Notational Conventions
Notational conventions Introduction Notational conventions The following notational conventions are used in this manual: indicates commands or menu items. Text in italics "Quotation marks" indicate names of chapters and terms that are being emphasized. describes activities that must be performed in the order Ê... -
Page 13: Technical Data
Introduction Technical data Technical data Electrical data Energy consumption 40 W Heat dissipation 144 kJ/h Compliance with regulations and standards Product safety and IEC 60950-1/2 / EN 60950-1/2, ergonomics UL/CSA 60950-1/2, CNS 14336 / GB 4943 / EN 50371 Electromagnetic compatibility FCC class A CNS 13438 class A;... - Page 14 Technical data Introduction Certification Product safety Global Europe ENEC Germany GS, CE USA/Canada / CSA Japan VCCI China/Taiwan BSMI Mechanical specifications Height 204 mm (chassis height 210.5 mm) Depth 508 mm (525 mm incl. lever) Width 45 mm (1 bay in the system unit) Weight Max.
-
Page 15: Important Notes
Important notes This chapter provides safety instructions which you must observe when handling your storage blade. Safety instructions The following safety instructions are also provided in the manual "Safety Notes and Regulations" or " 安全上のご注意 ". This device meets the relevant safety regulations for IT equipment. If you have any questions about whether you can install the storage blade in the intended environment, please contact your sales outlet or our customer service team. - Page 16 Safety instructions Important notes For the Japanese market it is not required to transport the device in its original packaging. Check that the rated voltage specified on the device's ID plate is the same as the local line voltage. Never connect or disconnect data transmission lines during a storm (lightning hazard).
-
Page 17: Electrostatic Sensitive Device Label
Important notes Electrostatic sensitive device label Electrostatic sensitive device label Modules with electrostatic-sensitive components Systems and components that might be damaged by electrostatic discharge (ESD) are marked with the following label: Figure 2: ESD label When you handle components fitted with ESDs, you must observe the following points under all circumstances: Remove the power plug before installing or removing components containing ESDs. -
Page 18: Ce Conformity
Consult the dealer or an experienced radio/TV technician for help. Fujitsu is not responsible for any radio or television interference caused by unauthorized modifications of this equipment or the substitution or attachment of connecting cables and equipment other than those specified by Fujitsu. The correction of interferences caused by such unauthorized modification, substitution or attachment will be the responsibility of the user. -
Page 19: Rfi Suppression
Important notes RFI suppression The use of shielded I/O cables is required when connecting this equipment to any and all optional peripheral or host devices. Failure to do so may violate FCC and ICES rules. WARNING: This is a class A product. In a domestic environment this product may cause radio interference in which case the user may be required to take adequate measures. -
Page 20: Environmental Protection
Important notes Environmental protection Environmentally-friendly product design and development This product has been designed in accordance with the Fujitsu standard for "environmentally friendly product design and development". This means that key factors such as durability, selection and labeling of materials, emissions, packaging, ease of dismantling and recycling have been taken into account. - Page 21 Details regarding the return and recycling of devices and consumables within Europe can also be found in the "Returning used devices" manual, via your local Fujitsu branch or from our recycling center in Paderborn: Fujitsu Technology Solutions Recycling Center D-33106 Paderborn Tel.
- Page 22 Environmental protection Important notes Operating Manual SX910 S1...
-
Page 23: Installation
Installation CAUTION! Follow the safety instructions in the chapter "Important notes" on page The storage blade should not be subjected to any extreme environmental conditions (see section "Technical data" on page 13). Protect the storage blade from dust, humidity and heat. Make sure that the storage blade is acclimatized for the time indicated in this table before putting it into operation. -
Page 24: Installation Procedure
Installation procedure Installation procedure Ê Unpacking a storage blade (see the next section on this page). Ê Installing a storage blade in the system unit (see the section "Installing/removing a Storage Blade" on page 25). Ê Putting a storage blade into operation (see the section "Putting the Storage Blade into operation"... -
Page 25: Installing/Removing A Storage Blade
Installing/removing a Storage Blade Installing/removing a Storage Blade For configuration see PRIMERGY BX900 S1 / PRIMERGY BX400 S1 Operating manual. CAUTION! Follow the safety instructions in chapter "Important notes" on page 3.3.1 Installing/removing in a PRIMERGY BX900 S1 Fitting rules 10 11 12 18 13 14 15 16 Figure 3: Numbering of the server blade slots... - Page 26 Installing/removing a Storage Blade Removing the dummy module Any unused slots on the front of the system unit are fitted with appropriate dummy modules to comply with electromagnetic compatibility (EMC) regulations and to ensure sufficient cooling of the system components. The power supply unit slots on the back do not necessarily have to be populated.
- Page 27 Installing the storage blade The PRIMERGY SX910 S1 storage blade can be installed during operation and is recognized by the management blade. You must restart the related server blade to enable the storage blade to communicate with the server blade, see the section "Putting the Storage Blade into operation"...
- Page 28 Installing/removing a Storage Blade Ê Open the release lever (2). Ê Push the storage blade as far as possible into the empty slot (3). Figure 6: Locking the storage blade Ê Push the release lever up until it clicks into place under the locking lever. Operating Manual SX910 S1...
- Page 29 Installing/removing a Storage Blade Removing the storage blade To remove the storage blade, you must first switch off the related server blade(s). Ê Switch the server blade off: either using the On/Off button on the server blade or using the Web interface of the management blade (see the "PRIMERGY BX900 Blade Server Systems ServerView Management Blade S1 User Interface Description"...
-
Page 30: Installing/Removing In A Primergy Bx400 S1
Installing/removing a Storage Blade 3.3.2 Installing/removing in a PRIMERGY BX400 S1 Fitting rules Figure 7: Numbering of the server blade slots Slots 2, 4, 6, 8 can be fitted with SX910 S1 storage blades. They provide the server blades in the adjacent slots to the right or left with backup functionality. Different configurations of the storage blades can be operated in the system unit. - Page 31 Installing/removing a Storage Blade Removing the dummy module Any unused slots on the front of the system unit are fitted with appropriate dummy modules to comply with electromagnetic compatibility (EMC) regulations and to ensure sufficient cooling of the system components. To add a storage blade, you must first remove a dummy module from the relevant slot.
- Page 32 Installing/removing a Storage Blade Installing a dummy module Any unused server blade or storage blade slots must be fitted with dummy modules to comply with EMC regulations for the system and to ensure sufficient cooling of the components. Figure 9: Dummy server blade module The handle (1) is movable and acts as a release lever.
- Page 33 Installing/removing a Storage Blade The following describes how to install a BX920 S2 server blade. Storage blades are installed in the same way. Figure 10: Installing the BX920 S2 server blade Ê Undo the locking mechanism of the release lever (1). Ê...
- Page 34 Installing/removing a Storage Blade Figure 11: Locking the BX920 S2 server blade Ê Push the release lever up until it clicks into place under the locking lever (1). Removal is carried out in reverse order. Operating Manual SX910 S1...
- Page 35 Installing/removing a Storage Blade Removing the storage blade To remove the storage blade, you must first switch off the related server blade(s). Ê Switch the server blade off: either using the On/Off button on the server blade or using the Web interface of the management blade (see the "PRIMERGY BX400 Blade Server Systems ServerView Management Blade S1 User Interface Description"...
- Page 36 Installing/removing a Storage Blade Operating Manual SX910 S1...
-
Page 37: Installation And Operation
Installation and operation Control and display elements 4.1.1 Indicators on the Storage Blade Figure 12: Indicators on the storage blade ID card Power (green) – Lights up: the left server blade is switched on – Does not light: the left server blade is switched off Power (green) –... - Page 38 Control and display elements Installation and operation ID card You can pull out the ID card (see figure 12 on page 37 above) as far as it will go and push it back in again. The ID card contains various system information, such as the product name, serial number, order number, MAC addresses and DNS name (in the Japanese market, only the product name and the serial number).
-
Page 39: Controls And Indicators On The Tape Drive
Installation and operation Control and display elements 4.1.2 Controls and indicators on the tape drive This section describes the controls and indicators on the LTO-4 tape drive. For information about the LTO-3 and LTO-5 tape drive please refer to the "LTO-3 Half-Height SAS Tape Drive"... -
Page 40: Operating Manual
Control and display elements Installation and operation Meaning of the indicators on the LTO-4 tape drive Drive condition Seven-segment LED dot Two-color status LED Powered off Blank Powered on Blank Green Initializing/power-on self-tests Post pattern Flashing Amber underway Successful initialization/ power- Blank On for 3 Green... -
Page 41: Putting The Storage Blade Into Operation
Putting the Storage Blade into operation Putting the Storage Blade into operation The PRIMERGY SX910 S1 storage blade can be installed during operation and is recognized by the management blade. You must restart the related server blade to enable the storage blade to communicate with the server blade. - Page 42 Putting the Storage Blade into operation Installation and operation Operating Manual SX910 S1...
-
Page 43: Troubleshooting And Tips
Troubleshooting and tips CAUTION! Follow the safety instructions in chapter "Important notes" on page If the power-on indicator of the storage blade (see figure 12 on page remains dark after you have switched on the related server blade, follow these instructions: All information on troubleshooting faults that may occur when operating server blades or storage blades in the PRIMERGY BX900 S1 system unit and... -
Page 45: Index
Index acclimatization time labels ambient conditions Low Voltage Directive 13, CE marking 13, meaning of the symbols certification product safety notational conventions Class A Compliance Statement consumables control panel packaging product name delivery note disposal, devices recycling devices dummy module regulations and standards installing 26, return of devices... - Page 46 Index unpacking weight Operating Manual SX910 S1...
