Summary of Contents for BOXLIGHT Seattle X22N
- Page 2 Projector (Please click here if your projector is with high efficiency filter.) About the Owner’s Manual Please read the owner’s manual thoroughly to ensure correct usage of the projector and its features. After reading, store the owner’s manual in a safe place for future reference. Features 1. Dress up Design 2.
-
Page 3: Table Of Contents
Contents Contents About Owner’s Manual Contents ........................1 Contents of Your Box ....................3-A Safety Instructions ....................4 Safety Labels......................5 Part Names ........................6 Projector ........................6 Control Panel ......................7 Rear ......................... 8 Setting Up ........................9 Arrangement ......................9 Power ON / OFF ....................10 Setting Up The Projector .................. -
Page 4: Contents
Contents MENU ........................30 Advanced Menu .....................30 Presentation Menu ....................33 Security Menu ......................35 PIN Key In Operation ....................38 Network Control Software Application ..............39 Before Use ........................40 Before To Use Network Control Software ............40 Projector Auto Search....................41 Modify the Projector Setting .................43 Registering And Configuring the Projector ............44 Delete ........................ -
Page 5: Contents Of Your Box
Contents of Your Box Safety Instructions Contents of Your Box Check-list of your accessories (Please click here if your projector is with high efficiency Please make sure that following items are included in the box, filter.) along with the main. If any items missing, contact your dealer. 2. - Page 6 Safety Instructions Contents of Your Box Optional Remote control Remote control LASER INDICATOR POWER INPUT MENU LASER MUTE MOUSE-L MOUSE-R AUTO BLANK USB Cable (1.5M) Network Control Application CD Soft Bag RS232 Cable...
-
Page 7: Safety Instructions
Safety Instructions Safety Instructions The projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. WARNING / CAUTION 1. -
Page 8: Safety Labels
Safety Labels Safety Labels Safety labels are used on or within the projector to (Please click here if your projector is with high efficiency alert you to items or areas requiring your attention. filter.) WARNING LABEL EMI LABEL LAMP DOOR WARNING LABEL... -
Page 9: Part Names
Part Names Part Names (Please click here if your projector Projector is with high efficiency filter.) Control panel Operating system. Lens cover Attach when not using to protect the lens from becoming dirty or damaged. Filter cover Prevents dust and other foreign particles from being drawn into projector. Remove the filter cover to clean the air filter. -
Page 10: Control Panel
Part Names Control Panel POWER INDICATOR LAMP INDICATOR KEYSTONE (POWER) 1 15 Adjust the vertical keystone with menu-up, Power on / operation mode, Standby mode, menu-down. Cooling-down mode. VOLUME + / - 1 10 LAMP INDICATOR 1 16 Sound louder or lower. Indicates a status in the internal projector temperature, lamp door properly closed or INPUT... -
Page 11: Rear
Part Names Rear (Please click here if your projector is with high efficiency filter.) A B C MOUSE VIDEO Connect a USB mouse cable to a computer Component video signal from a video to control computer mouse functions. source. RS232 AUDIO IN 3, R / L Serial data port for controlling the projector Stereo mini jack corresponds to video with a computer or other RS-232 control input. -
Page 12: Setting Up
Setting Up Setting Up Arrangement 1. Before installation, make sure that the projector is turned off and the power cord is disconnected. 2. Do not set up and move the projector, while it is hot. 3. The distance between the projector and screen determines the actual image size. Refer to the table below to determine the screen size at a given distance. -
Page 13: Power On / Off
Setting Up (Please click here if your projector is Power ON / OFF with high efficiency filter.) Turning on the power POWER indicator 1. M ake sure that power cord is firmly and correctly connected to the projector. Outlet 2. Remove the lens cover, and the POWER AC IN AC inlet indicator will light up in green. -
Page 14: Setting Up The Projector
Setting Up Setting Up The Projector The projector supports the following four different projection methods. 1.Front projection 3.Rear ceiling projection 2.Rear projection 4.Front ceiling projection Special installation is required in order to suspend the projector from the ceiling. Please ask your dealer for details. -
Page 15: Ceiling Mounted Installation Guide
Setting Up (Please click here if your projector Ceiling Mounted Installation Guide is with high efficiency filter.) Attach ceiling mount at four-suspension bracket fixing points when suspending from a ceiling. Special installation is required in order to suspend the projector from the ceiling. Please ask your dealer for detals. MAX M4x8 mm For Mounting. Security Anchor The product is equipped with security anchor and PIN LOCK functions to help prevent unauthorized removal projector. -
Page 16: Adjusting The Projector's Elevation
Setting Up Adjusting The Projector’s Elevation (Please click here if your projector is with high efficiency filter.) Use the adjustable foot at the front of the projector to set the image height. Holding the projector, push the foot adjust CAUTION buttons to loosen the front adjustable foot. Position the front side of the projector to the * The adjustment range of front adjustable desired height. -
Page 17: How To Connect
Setting Up How To Connect (Please click here if your projector is with high efficiency filter.) Laptop or desktop computer MOUSE RS-232 AUDIO OUT VGA OUT DVI OUT AUDIO OUT VGA OUT RGB IN S-VIDEO OUT Pb/Cb Pr/Cr AUDIO IN VIDEO OUT AUDIO OUT (L)&(R) Before starting, make sure that the projector and computer are both turned off. - Page 18 Setting Up How To Connect Laptop or desktop computer Connect the audio cable if necessary 1. If you connect end of the computer cable to the projector’s RGB IN. Please connect one other end of the audio cable to the AUDIO IN 1. 2.
-
Page 19: Remote Control
Remote Control Remote Control Remote Control Battery Installation 1. Remove the battery cover. 2. Load the batteries. Make sure the plus pole is correctly oriented. 3. Close the battery cover. Caution ► A void excessive heat and humidity. ►Do not drop the remote control. ► D o not expose the remote control to water or moisture, this could result in malfunction. ► I f the remote control will not be used for an extended period, remove the battery. -
Page 20: Power Input
Remote Control Power INPUT Power on operation mode, standby mode, cool down mode. Press “ ESC ” button to close “Menu” picture. Volume +/- Adjust Volume higher or lower. Menu MENU Display or hide the On-Screen Display main menu page. Keystone Auto Adjust the vertical keystone function. - Page 21 Remote Control INPUT INPUT Select input source: RGB 1 RGB 2 DVI-I Y,Pb,Pr S-Video Video Menu up / down Menu left / right Select and adjust the function of On-Screen Display. MENU Auto Auto Refresh the current image. Blank Blank Still Hide the current image, become black color on the screen.
-
Page 22: Remote Control (Optional)
Remote Control (Optional) Remote Control Batteries Installation 1. Remove the battery cover. 2. Load the batteries. Make sure the poles are correctly oriented. 3. Close the battery cover. Caution ►Avoid excessive heat and humidity. ►Do not drop the remote control. ► I f the remote control will not be used for an extended period, remove the batteries. ► D o not expose the remote control to water or moisture. This could result in malfunction. ► R eplace the battery when remote control operation becomes sluggish or unresponsive. - Page 23 Remote Control (Optional) Remote Control (Optional) POWER Power on / operation mode, Standby mode, Cool down mode. INPUT Select input source : RGB 1 RGB 2 DVI-I Y,Pb,Pr S-Video Video LASER MENU INDICATOR Display or hide the On-Screen Display main menu POWER INPUT page.
-
Page 24: Remote Control Batteries Installation
Menu Operation Remote Control (Optional) Remote Control Batteries Installation 1. Remove the battery cover. 2. Loading the batteries. Make sure the plus and minus poles are correctly oriented. 3. Close the battery cover. Caution 1. Avoid excessive heat and humidity. 2. - Page 25 Remote Control (Optional) Power Power on / operation mode, Standby mode, Cooling-down mode. Press ”ESC” button, it will close ”Menu” picture. Vol +/- Sound louder or lower. Menu Display or hide the OSD main menu page. Keystone +/- Adjusts the vertical keystone function. Still Keep the current image on the Screen.
-
Page 26: Menu Operation
Menu Operation How To Operate On-Screen Display 1. You could press "Menu" button. It will be shown blue main menu. The first main menu is " PICTURE" menu. 2. Choose which item you want to enter, you could press up / down /left/ right button of control panel or remote control to adjust item or value. Up / Down / Right / Left button LASER INDICATOR... -
Page 27: Menu (Pc Mode)
MENU (PC Mode) MENU (PC Mode) Picture Menu Step: 1. U se the ▲ /▼ buttons to select an item. 2. U se the ◄ / ► cursor buttons to select an item or adjust the value. Item Selection Description BRIGHTNESS 000/100 Adjust the image brightness level. CONTRAST 000/100 Adjust the image contrast level. SHARPNESS 000/004 Adjusts the image sharpness. -
Page 28: Audio Menu (Pc Mode)
MENU (PC Mode) Audio Menu Step: 1. U se the ▲ /▼ buttons to select an item. 2. U se the ◄ / ► buttons to select an item or adjust the value. Item Selection Description VOLUME 00/40 Adjust the volume. MUTE OFF/ON Mute the volume OFF / ON. -
Page 29: Setting Menu (Pc Mode)
MENU (PC Mode) Setting Menu Step: 1. U se the ▲ /▼buttons to select an item. 2. U se the ◄ / ► buttons to select an item or adjust the value. Item Selection Description Move the image position horizontally. H POSITION 000/100 This function is only selected for computer signal. Move the image position vertically. -
Page 30: Menu (Video Mode)
MENU (Video Mode) MENU (Video Mode) Picture Menu Step: 1. U se the ▲ /▼ buttons to select an item. 2. U se the ◄ / ► cursor buttons to select an item or adjust the value. Item Selection Description BRIGHTNESS 000/100 Adjust the image brightness level. CONTRAST 000/100 Adjust the image contrast level. -
Page 31: Audio Menu (Video Mode)
MENU (Video Mode) Audio Menu Step: 1. U se the ▲ /▼ buttons to select an item. 2. U se the ◄ / ► buttons to select an item or adjust the value. Item Selection Description VOLUME 00/40 Adjust the volume. MUTE OFF/ON Mute the volume OFF / ON. -
Page 32: Setting Menu (Video Mode)
MENU (Video Mode) Setting Menu Step: 1. U se the ▲ /▼buttons to select an item. 2. U se the ◄ / ► buttons to select an item or adjust the value. Item Selection Description AUTO KEYSTONE OFF/ON Automatically Correct keystone distortion in image. KEYSTONE V -70/+70 Correct vertical keystone distortion in image manually. AUTO SEARCH OFF/ON Search signal source manually or automatically. -
Page 33: Menu
MENU MENU Advanced Menu Step: 1. U se the ▲ /▼buttons to select an item. 2. U se the ◄ / ► buttons to select an item or adjust the value. Item Selection Description ZOOM / PAN EXECUTE Execute digital zoom and pan function. FREEZE OFF/ON Freeze the current image on the screen. BLANK OFF/ON Hide the image, display a black screen. - Page 34 MENU Advanced Menu LOGO SETTING This function allows you to customize the start-up logo. IMPORTANT: To execute the logo function, you must enter the PIN code first. Item Selection Description Select Mode( ► cursor button) DEFAULT The factory logo. LOGO MODE USER The image you captured. The blank image.
-
Page 35: Advance Menu
MENU Advance Menu Logo Capture How to use this function? Select Logo Capture item in the logo setting menu, and press ► button. You can see the red frame to select captured area. Image Use 4 direction buttons to adjust the position of the frame. -
Page 36: Presentation Menu
MENU Presentation Menu Step: 1. U se the ▲ /▼buttons to select an item. 2. U se the ◄ / ► buttons to select an item or adjust the value. Item Selection Description Automatically invert the image when the projector is AUTO CEILING OFF / ON turned upside down, i.e. when the projector is mounted on the ceiling. -
Page 37: Reset Lamp Timer
MENU Presentation Menu Reset Lamp Timer The lamp timer is the time counted after the last resetting. The usage time of the lamp is shown in the PRESENTATION Menu. Pressing the RESET button or the ► button displays a dialog. To reset the lamp time, select the RESET using the ► button. NOTE ► T he replacement warning message is set to appear after about 2000 hours of lamp use in order to maintain the initial brighreplacement message appears, replace the lamp with a new one as soon as possible, even ifit is still working. -
Page 38: Security Menu
MENU Security Menu Step: 1. U se the ▲ /▼buttons to select an item. 2. U se the ◄ / ► buttons to select an item or adjust the value. Item Selection Description OFF: Turn off PIN lock protection. ON 1: P IN code is needed only in the first time after AC power has been switched off. ON 2: PIN code is needed every time while the projector PIN LOCK is turned on. - Page 39 MENU Security Menu Step: 1. U se the ▲ /▼buttons to select an item. 2. U se the ◄ / ► buttons to select an item or adjust the value. Item Selection Description FILTER TIMER Show the filter use hour. RESET FILTER Reset the filter timer after cleaning / changing filter. TIMER 500 hours Select (500 / 800 / 1000 hours) depending on the FILTER COUNTER 800 hours environment.(default : 500 hours).
-
Page 40: Auto Filter Alert
MENU Auto Filter Alert Auto Filter Alert is in SECURITY category to show the air filter use time and alert user to change filter. Pressing ► cursor button will display a dialog. When the operating time reaches the set time, a warning message will appear on the screen to remind user of filter cleaning / replacing. Filter Replace... Filter has been used for more than 500 hours. NOTE ► Please reset the Filter time only when you replace the filter. -
Page 41: Pin Key In Operation
MENU PIN Key In Operation When the projector is turned on and the PIN LOCK PROTECTION is set to [ON], the image will show as on the right side. 1. Press the MENU button on the projector or remote control. Enter PIN code by keypad or remote control. -
Page 42: Network Control Software Application
Network Control Software Application Network Control Software Application (Please click here if your projector is with high efficiency filter.) NOTE: This Network Control Software Application is an optional function and support model with RJ45 LAN port only. Register the projector(s) which needs to be controlled. ... -
Page 43: Before Use
Before Use Before Use Before To Use Network Control Software I f the system is Windows 2000, NT 4.0 or XP, the PC should be started by the Administrator. B efore starting the Network Control software, please check the following. ... -
Page 44: Projector Auto Search
Before Use Projector Auto Search. C lick the (Projector search), located projector will show on the network correctly. (Graph2) <Graph 2> NOTE When the security warning window appears while Network Control is executing, please select "Unblock" to decontrol area network linking against from System Administer. - Page 45 Before Use Projector Auto Search. P rojector Auto Search can rank group names or display names by clicking the monitor window title (Group Name) or (Host Name). This will help you easily to understand projectors status. <Graph 4-2> A fter registering, you can click button (Data single capture) in the tool bar or ...
-
Page 46: Modify The Projector Setting
Before Use Modify The Projector Setting I f modifying the registered projector setting is needed, please move your cursor to the data table and click the item that you would like to modify, the detail will be shown on the right side table. <... -
Page 47: Registering And Configuring The Projector
Registering And Configuring The Projector Registering And Configuring The Projector Delete S elect the registered projector in monitor window. Click mouse right key and select “ Delete ” to erase the registered projector data. < Graph 6 > : Register Table. -
Page 48: Projector Setting
Registering And Configuring The Projector Projector Setting S elect the registered projector in monitor window. Click mouse right key and select “ projector setting ” to modify the registered projector data. After finishing the setting, you can save by clicking button or cancel by clicking button. < Graph 7 > : Register table. <... - Page 49 Registering And Configuring The Projector Projector Setting Click button (system setting) to modify system alert setting. < Graph 9 > <Graph 10>...
-
Page 50: System Setting / Monitor / Default Setting / Auto Detect Optimal Setting
Registering And Configuring The Projector System Setting Monitor Item Description Lamp Timer Lamp timer from projector. Air Filter Alert Air Filter Timer from projector. System Status/ System Status and Tempeture. Level from projector in Power On Tempeture Level status. Input Source Input Source from projector in Power ON status. -
Page 51: Link
Registering And Configuring The Projector Link S elect the registered projector in monitor window. Click mouse right key and select “ Link ” to show up the control panel table and the projector connected status. < Graph 12 > : The control panel table... -
Page 52: Control Panel Window Introduction
Control Panel Window Introduction Control Panel Window Introduction P ower Control Icon Name Power on Power off I nput Source Icon Name Video S-Video Y,Pb,Pr DVI-I RGB 1 Change Input Source F unction Key Icon Name Icon Name Freeze Down... -
Page 53: Function Key / Projector Status
Control Panel Window Introduction Function Key Icon Name Lower Contrast Zoom In Zoom Out Volume Up Volume Down Projector Status Icon Name System Status Input Source Status Lamp Timer Air Filter Timer... -
Page 54: Network Control Window Introduction
Control Panel Window Introduction Network Control Window introduction Icon Name Description Scan all Capture the projector information 1 time only. According to the system setting, get the projector Start Auto Scan information automatically. Stop Auto Capture Search the projector in the same network to Auto Search register and modify the setting. -
Page 55: Maintenance Of Projector
Maintenance Of Projector Maintenance of Projector Air Filter (Please click here if your projector is with high efficiency filter.) When a warning message appears to remind you to clean the air filter, please replace a new one as soon as possible. Please check and clean the air filter periodically. Replacing the Air Filter When the use time reaches the filter counter time, the projector will display a message that indicates to replace a new filter. If there is no spare air filter available, please contact your dealer. New one Turn off the projector, and unplug the power cord. Allow the projector to sufficiently cool down. Remove the filter cover from the right side of projector. Pull out the air filter. ... -
Page 56: Lamp / Replacing New Lamp
Maintenance of Projector Lamp (Please click here if your projector is with high efficiency filter.) 1. If you want to replace new lamp, but the projector was just turned off, please let the projector cool down and unplug power cord at least 60 minutes. 2. If the projector is mounted in the ceiling, contact your dealer to replace the lamp. - Page 57 Maintenance of Projector WARNING The projector uses a high-pressure mercury lamp. The explosion of lamp with a loud bang or burn out could possibly cause injury or a fire. When the bulb burts, it is possible for shards of glass to fly into the lamp housing; and for gas containing mercury to escapefrom the projector’s vent holes. If the lamp has broken, do not check the inside of the projector. Please ventilate the room immediately.
-
Page 58: Other Care / Cleaning The Lens
Maintenance of Projector Other Care Cleaning The Lens If the lens is dirty and dusty, display quality maybe decreased. Before cleaning the lens, please make sure that the projector is cool down adequately. After the projector has cooled down adequately, lightly wipe the lens with the available lens-cleaning cloth. -
Page 59: Troubleshooting
Troubleshooting Troubleshooting Indicator The power and lamp indicators show the status of the projector. Before requesting repair, check the projector status using the chart below. If the problem cannot be resolved, contact your dealer. In normal status~~~ POWER LAMP CONDITIONS DESCRIPTION Blinking In Stand by mode... -
Page 60: Error For Machine Defects
Troubleshooting Error For Machine Defects The following problems may be confused with a machine defect. Check and follow the table. If it couldn’t be improved, contact your dealer. Symptom Cause / Remedy The power cord is disconnected. Plug the power cord into an AC outlet. Intending to turn on the projector again during the cool down mode. - Page 61 Troubleshooting Error For Machine Defects Symptom Cause / Remedy The projector is not connected correctly. Check audio cable if connect correctly. The volume is set to minimum. No audio Adjust the volume. Mute is turned on. Press the MUTE button. No battery.
-
Page 62: List Of Supported Monitor Displays
Troubleshooting List of Supported Monitor Displays Computer mode Signal Refresh Rate (Hz) Resolution (dots) 640x480 VESA 60 /72 /75/85 640x480 SVGA 56 /60/72/75 /85 800x600 60 /70/75/85 1024x768 SXGA 70 /75 1152x864 SXGA 60 /75 1280x960 SXGA 1280x1024 WXGA 60 /75 1280x800 WXGA+ 60/75/85... -
Page 63: Appendix
Appendix Appendix Menu Tree (PC Mode) Front Ceiling Auto Ceiling B rightness Rear Ceiling And Rear Contrast Lamp Mode PRESENTATION PICTURE Sharpness Lamp Nature Cinema Display Mode Reset Lamp Timer Daylight (optional) Green Board White Board Black Board Volume AUDIO Mute H Position V Position... - Page 64 Appendix Menu Tree (Video Mode) B rightness Front Ceiling Auto Ceiling Rear Contrast Ceiling And Rear PICTURE Sharpness Lamp Mode PRESENTATION Nature Cinema Display Mode Lamp Daylight Green Board Reset Lamp Timer White Board (optional) Black Board Volume AUDIO Mute Auto Keystone Auto Sync SETTING...
- Page 65 Appendix Appearance (Please click here if your projector is with high efficiency filter.)
- Page 66 Projector About the Owner’s Manual Please read the owner’s manual thoroughly to ensure correct usage of the projector and its features. After reading, store the owner’s manual in a safe place for future reference. Features 1. Dress up Design 2. Designed for tough environment 3.
- Page 67 Safety Instructions Contents of Your Box Check-list of your accessories Please make sure that following items are included in the box, along with the main. If any items missing, contact your dealer. 1.Projector 2. Computer cable 4. Quick Start Guide 3.Power cord 5.
- Page 68 Safety Labels Safety labels are used on or within the projector to alert you to items or areas requiring your attention. WARNING LABEL EMI LABEL LAMP DOOR WARNING LABEL Back...
- Page 69 Safety Labels Projector Control panel Operating system. Filter cover Prevents dust and other foreign particles from being drawn into projector. Remove the filter cover to clean the air filter. Focus ring Use the focus ring to focus the projector image. Front IR receiver Rotate the focus ring until the image is clear.
-
Page 70: Audio Out
Part Names Rear MOUSE VIDEO Connect a USB mouse cable to a computer Component video signal from a video to control computer mouse functions. source. RS232 AUDIO IN 3, R / L Serial data port for controlling the projector Stereo mini jack corresponds to video with a computer or other RS-232 control input. -
Page 71: Turning Off The Power
Part Names Power ON / OFF Turning on the power POWER indicator 1. M ake sure that power cord is firmly and correctly connected to the projector. 2. The POWER indicator will light up in green. Outlet 3. Press POWER button on the control panel or AC inlet the remote control to turn on the projector. -
Page 72: Ceiling Mounted Installation Guide
Setting Up Ceiling Mounted Installation Guide Attach ceiling mount at four-suspension bracket fixing points when suspending from a ceiling. Special installation is required in order to suspend the projector from the ceiling. Please ask your dealer for detals. MAX M4x8 mm For Mounting. Security Anchor The product is equipped with security anchor and PIN LOCK functions to help prevent unauthorized removal projector. - Page 73 Setting Up Adjusting The Projector’s Elevation Use the adjustable foot at the front of the projector to set the image height. Holding the projector, push the foot adjust CAUTION buttons to loosen the front adjustable foot. Position the front side of the projector to the * The adjustment range of front adjustable desired height.
- Page 74 Setting Up How To Connect Laptop or desktop computer MOUSE RS-232 AUDIO OUT DVI OUT AUDIO OUT VGA OUT VGA OUT RGB IN S-VIDEO OUT Pb/Cb Pr/Cr AUDIO IN VIDEO OUT AUDIO OUT (L)&(R) Before starting, make sure that the projector and computer are both turned off. Connect the computer cable.
- Page 75 Network Control Software Application NOTE: This Network Control Software Application is an optional function and support model with RJ45 LAN port only. Register the projector(s) which needs to be controlled. “ Auto search ” can help you to seek the projector(s) source easily. After registering in the work group, you can start to control the projector.
- Page 76 Maintenance of Projector Air Filter When a warning message appears to remind you to clean the air filter, please replace a new one as soon as possible. Please check and clean the air filter periodically. Replacing the Air Filter When the use time reaches the filter counter time, the projector will display a message that indicates to replace a new filter. If there is no spare air filter available, please contact your dealer. Press New one Turn off the projector, and unplug the power cord. Allow the projector to sufficiently cool down. Remove the filter cover from the right side of projector. Pull out the air filter. Install a new air filter. Put the filter cover on.
- Page 77 Maintenance of Projector Lamp 1. If you want to replace new lamp, but the projector was just turned off, please let the projector cool down and unplug power cord at least 60 minutes. 2. If the projector is mounted in the ceiling, contact your dealer to replace the lamp.
- Page 78 Appendix Appearance 137.8 67.8 360.3 137.8 110.9 31.09 261.3 187.5 Back...
