Setup Error Messages

If any of the error messages listed below appears while executing the Quick Setup function, resolve the problem as required and
then execute Quick Setup again.
When changing a Setup ID setting be sure to turn the device's power OFF, change the DIP switch settings as required, and then
turn the device ON again.
Error Message
Setup ID is discontinuous. Setup ID #n not
found.
There are two or more with same Setup ID
#n. (flashing)
There are two or more MY16-ES64(s). (flash-
ing)
MY16-ES64 is not found in ES network.
MY16-ES64 is not Primary Master. (flashing)
Setup ID of all SB168-ES is not assigned.
MY16-ES64 is not 48kHz. 96kHz is selected.
The power supply was turned off or the cable
was disconnected.
Audio routing locked on device. (flashing)
Details and Solution
The Setup ID numbers are not sequential—ID "#n" is missing.
Referring to the "Preparation" instructions on page 13, use the DIP switches to set the
Setup ID numbers in sequence beginning from #1.
Two or more SB168-ES units have the same Setup ID number.
When duplicate Setup ID numbers are detected the SB168-ES IN/OUT [TX]/[RX] indi-
cators will flash. Referring to the "Preparation" instructions on page 13, check the DIP
switch settings and make sure that each unit has a unique Setup ID.
Two or more MY16-ES64 cards have been detected on the EtherSound network.
The use of two or more MY16-ES64 cards is not supported by the Quick Setup func-
tion. The IN/OUT [TX]/[RX] indicators of the MY16-ES64 cards will flash. Redo the
connections so that only one MY16-ES64 is connected to the network.
No MY16-ES64 card can be located on the EtherSound network.
EtherSound interface cards other than the MY16-ES64 are not supported by the
Quick Setup function.
The MY16-ES64 is not functioning as Primary Master in a daisy chain network.
This type of configuration is not supported by the Quick Setup function. The IN/OUT
[TX]/[RX] indicators of the MY16-ES64 card will flash while this error message is dis-
played. Redo the connections so that the MY16-ES64 functions as Primary Master.
The Setup ID has not been set for any of the SB168-ES units on the EtherSound net-
work. The Setup ID for at least one unit must be set.
The IN/OUT [TX]/[RX] indicators of the SB168-ES units will flash while this error mes-
sage is displayed. Referring to the "Preparation" instructions on page 13, set the
Setup ID numbers of the connected SB168-ES units.
No error will occur if the Setup ID is not set for one of the SB168-ES units in a multi-
unit system, but the patch settings for that SB168-ES unit will be cleared.
The sampling frequency of the MY16-ES64 card connected to the EtherSound net-
work is set to 96 kHz (SW2).
The SB168-ES does not support 88.2 kHz or 96 kHz sampling frequencies.
The IN/OUT [TX]/[RX] indicators of the MY16-ES64 card will flash while this error
message is displayed. Referring to the "Preparation" instructions on page 13, set the
SW2 switch on the MY16-ES64 card to [48K].
The power to one of the devices connected to the EtherSound network was turned off,
or a cable was disconnected during Quick Setup execution.
Check the power cables and power switch settings of all devices and execute the
Quick Setup function again.
The Quick Setup function cannot be executed if the Lock Routing parameter in the
Control page is ON.
The IN/OUT [TX]/[RX] indicators of the MY16-ES64 card and SB168-ES units will
flash while this error message is displayed.
In order to execute the Quick Setup function all Lock Routing parameters must be
turned OFF.
