Insignia NS-19E310NA15 Quick Setup Manual

A Carefully place your TV face-down on a cushioned, clean surface to protect the screen from damages
QUICK
B Align the front of the stand column with the front of the TV stand, then insert the column into the
SETUP GUIDE
C Secure the column to the stand with three provided M5 × 12 mm screws.
D Slide the stand cover onto the stand column, then secure the cover to the column with
48" LED TV
E Secure the cover to your TV with four provided M5 × 12 mm screws.
NS-48D510NA15
Thank you
How do I prepare my TV for wall mounting?
for purchasing this state-of-the-art
A Carefully place your TV face-down on a cushioned, clean surface to protect the screen from damages
Insignia television. We hope you enjoy
the quality and reliability of this
B Insert four spacers (provided) into the mount screw holes on the back of your TV, then attach the
television for years to come.
Warning: This apparatus is intended to be supported by a UL Listed wall-mount bracket.
Roku Ready®
Your TV is certi ed to work with the
Roku Streaming Stick™.
Instantly stream 1000+ entertainment
channels, including Net ix, Hulu Plus,
Pandora, and more. Connect the
Streaming Stick (not included) to the
purple MHL jack on your TV and enjoy.
FIND YOUR
USER GUIDE ONLINE!
We are going green so a copy of your
User Guide is not provided in the box
but is available online.
Go to www.insigniaproducts.com,
then click Support & Service. Enter your
model number in the box under Manual,
Firmware, Drivers & Product Information,
then click .
START HERE
How do I attach the stand to my TV?
(not for wall mounting)
You'll need: Phillips screwdriver and a soft surface to lay the TV on.
and scratches.
stand making sure that the grooves in the column align with the ridges in the stand.
one provided M5 × 12 mm screw.
- OR -
and scratches.
wall-mount bracket to your TV using either the four M6 × 30 mm screws (provided) or the screws that
came with the wall-mount bracket. See instructions that came with the wall-mount bracket for
information about which screws to use and how to correctly hang your TV.
Which cables do you have?
Your TV has several di erent jacks for connecting devices.
STOP!
For the best video quality, use the best available
connection. Use the cables that came with your devices.
Do not plug your
power cord in until
VIDEO QUALITY
all other devices have
been connected.
BEST
BETTER
Included accessories
GOOD
Power cord
GOOD
Note: You can also connect a DVI device to your TV. See your online User Guide for connection
instructions.
Features
Front view
Remote control
and two AAA batteries
Stand cover
Back view
MENU
INPUT
Stand column
VOL +
VOL -
TV stand
CH
CH
M5 screws
(12 mm length)
(8 pcs.)
Spacers (4 pcs.)
M6 spacer screws
USB
(30 mm length)
(4 pcs.)
Images do not necessarily represent the exact design of your television.
B
A
(not for use with a TV stand)
MAKING CONNECTIONS
How do I watch TV (cable or satellite receiver) and/or connect a device such as a DVD
or Blu-ray Disc player, game console, MHL-enabled device, Roku Streaming Stick, or camcorder?
JACK TYPE CABLE CONNECTOR
Using an HDMI cable
(BEST)
HDMI video/audio
Component video and analog audio
Composite video and analog audio (AV)
USB
Coaxial video/audio
Using component cables (BETTER)
- OR -
Using an AV cable (GOOD)
Power indicator
Remote control sensor
How do I connect my TV to an antenna or cable wall jack?
AV IN
L - AUDIO - R
P P
COMPONENT IN HDMI1/ARC
Before using your new product, please read these instructions to prevent any damage.
D
Stand cover
Stand column
C
B
AV IN
L - AUDIO - R
P P
COMPONENT IN
HDMI1/ARC
AUDIO/VIDEO OUT
Component cable option
AV IN AV IN
L - AUDIO - R
L - AUDIO - R
P P
COMPONENT IN
USB P P HDMI/ARC
COMPONENT IN
USB
Note: Connect the yellow video cable
connector to the green VIDEO/Y jack
on the back of your TV.
E
Front
Spacer
Multi-purpose jacks: You can connect
any device that uses HDMI or DVI to
either HDMI jack. However, certain
devices must be connected the
HDMI2/MHL or HDMI1/ARC jack.
See the instructions that came with
your MHL or ARC device.
Note: The component and AV jacks
are shared. This means you can
connect only one component or AV
device at a time. We suggest using
HDMI if your device supports it.
HDMI/ARC
AUDIO/VIDEO
OUT
AV cable option
CABLE
OVER
