Short code Full-text message
LSER LAMP SENSING CIRCUIT ERROR (s/w versions from ver. 1.3)
Lamp sensing circuit reports that lamp should be on but is not actually on.
LSRR LAMP SENSING CIRCUIT ERROR (s/w versions prior to ver. 1.3)
Lamp sensing circuit reports that lamp should be on but is not actually on.
LTIM LAMP LIFE WARNING
Lamp on counter has timed out and it is time to change the lamp. The counter must be reset once
this is done.
MAER MAGENTA ERROR
MALE MAINS LOW
The input voltage on the electronic ballast is too low to strike the lamp.
MALW MAINS LOW
Mains voltage is below acceptable level. The lamp may not be able to strike.
PAER PAN ERROR
PANA PAN NOT ADJUSTED
Pan needs to be adjusted by a qualified service technician.
PCDE PAN/TILT CALIBRATE DATA PCB (s/w versions prior to ver. 1.3)
Unable to read/write data to external EEPROM board (calibrate date) on yoke
PSER PAN SENSOR ERROR
PTCM PAN/TILT SENSOR CAL MISSING
The pan/tilt sensors are not calibrated.
PTCO PSU TEMP CUTOFF
Ballast in thermal cutoff
PTCS PAN/TILT CALIBRATE SENSOR (s/w versions prior to ver. 1.3)
Pan/tilt sensors not calibrated
PTER PSU TEMP HIGH
The temperature on a PCB in the power supply unit or ballast is high. A fan might be defective or the
ambient temperature may be too high.
R1ER GOBO WHEEL ROTATION ERROR
SHNA SHUTTER NOT ADJUSTED
No shutter adjustment data in EEPROM
SHUE SHUTTER ERROR
SLER SAFETY LOOP ERROR
Lamp safety loop circuit activated: the lamp access hatch is open or lamp is too hot
SSTO SYSTEM STATE TIMEOUT
Failure to communicate with module during self-check at startup. Service intervention required.
Fixture control possibly disabled, depending on nature of error.
TIER TILT ERROR
TINA TILT NOT ADJUSTED
Tilt needs to be adjusted by a qualified service technician.
TSER TILT SENSOR ERROR
UECH UPLOAD ERROR CHARGER
Could not upload new firmware to the Charger module.
UECM UPLOAD ERROR CMY
Could not upload new firmware to the CMY module.
UECO UPLOAD ERROR COOLING
Could not upload new firmware to the Cooling module.
UEEF UPLOAD ERROR EFFECT
Could not upload new firmware to the Effects module.
UEPT UPLOAD ERROR PAN/TILT
Could not upload new firmware to the Pan/Tilt Focus module.
UEPU UPLOAD ERROR POWER UNIT
Could not upload new firmware to the Power Unit module.
UEUI UPLOAD ERROR UI
Could not upload new firmware to the User Interface module.
UEZF UPLOAD ERROR ZOOM/FOCUS
Could not upload new firmware to the Zoom Focus module.
UPLB UPLOAD ERROR ON BALLAST (s/w versions prior to ver. 1.3)
UPLC UPLOAD ERROR ON COOLING (s/w versions prior to ver. 1.3)
Table 6: Error messages
