Martin MAC III PERFORMANCE User Manual page 49

Basic 16-bit
16-bit Extended
Mode Mode DMX Value
10 - 14
15 - 19
20 - 24
25 - 29
30 - 34
35 - 39
40 - 44
45 - 49
50 - 54
8 9
55 - 59
60 - 89
90 - 119
120 - 149
150 - 179
180 - 209
210 - 232
233 - 255
0 - 255
9 10
3 - 126
127 - 129
130 - 253
254 - 255
10 11
0 - 255
0 - 255
11 12
0 - 255
12 13
127 - 128
129 - 255
13 14
0 - 255
14 15
127 - 128
129 - 255
15 16
0 - 255
Percent Function
Gobo selection, indexing, shake, rotation
Indexed gobo selection: set indexed angle on channel 9 (16-bit) or 10 (16-bit
ext.)
0 - 9 0 - 4 Open
4 - 5 Gobo 1 - Leaf breakup
5 - 8 Gobo 2 - Dot breakup
8 - 10 Gobo 3 - Limbo
10 - 12 Gobo 4 - Linear 3
12 - 14 Gobo 5 - Raytraces
Continuous gobo rotation: set gobo rotation speed on channel 9 (16-bit) or 10
(16-bit ext.)
14 - 16 Gobo 1 - Leaf breakup
16 - 18 Gobo 2 - Dot breakup
18 - 20 Gobo 3 - Limbo
20 - 22 Gobo 4 - Linear 3
22 - 24 Gobo 5 - Raytraces
Gobo shake centered on indexed position: set indexed angle on channel 9
(16-bit) or 10 (16-bit ext.). Shake angle increments in following steps:
10°, 15°, 30°, 45°, 60°, 90°, 135°, 180°, 270° and 360°
Gobo 1 - Leaf breakup, 360° slow → 10° fast
24 - 34
Gobo 2 - Dot breakup, 360° slow → 10° fast
35 - 45
Gobo 3 - Limbo, 360° slow → 10° fast
46 - 56
Gobo 4 - Linear 3, 360° slow → 10° fast
57 - 67
Gobo 5 - Raytraces, 360° slow → 10° fast
68 - 78
Continuous gobo wheel scroll with continuous gobo rotation: set gobo rotation
speed on channel 9 (16-bit) or 10 (16-bit extended)
CW gobo wheel scroll, fast → slow*
79 - 89
CCW gobo wheel scroll, slow* → fast
90 - 100
*If gobo crossfading is enabled in control menu (PERSONALITY
X-FADE), slow = 5% speed. If gobo crossfading is disabled, slow = 30%
speed
Gobo indexing, direction, speed (MSB)
If indexed gobo is selected on channel 8 (16-bit) or 9 (16-bit ext.)
Gobo indexing, 0 → 395°
0 - 100
If continuous gobo rotation is selected on channel 8 (16-bit) or 9 (16-bit ext.)
0 - 2 0 No gobo rotation
CW, fast → slow
1 - 50
51 No gobo rotation
CCW, slow → fast
52 - 99
100 No gobo rotation
Gobo fine indexing or rotation speed (LSB)
If indexed gobo is selected on channel 8 (16-bit) or 9 (16-bit ext.)
0 - 100 Gobo indexing, fine
If continuous gobo rotation is selected on channel 8 (16-bit) or 9 (16-bit ext.)
0 - 100 Gobo rotation speed, fine
Framing blade 1, position
Out → in
0 - 100
Framing blade 1, angle
0 -126 0 - 49
Angle –
50
Parallel
51 - 100
Angle +
Framing blade 2, position
Out → in
0 - 100
Framing blade 2, angle
0 -126 0 - 49
Angle –
50
Parallel
51 - 100
Angle +
Framing blade 3, position
Out → in
0 - 100
Table 3: MAC III Performance DMX Protocol
MAC III Performance DMX protocol
→
GOBO
49
