OWNER'S MANUAL
P474-1100RF
Wireless
Programmable
Digital Thermostat
Wireless Operation
7-Day Programmable
4 Time Periods Per Day
Programmable Fan
Large, Easy to Read Display
Thermoglow Backlight
Auto-Changeover
MODE
Dual Setpoint
FAN
TOTALINE
2 Heat and 2 Cool Stages
2 Stage
TOTALINE
Heat & Cool
or
Heat Pump
Wireless
Replacement Components Division
Carrier Corporation 03/07

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P474-1100RF and is the answer not in the manual?

Questions and answers

Summary of Contents for Venstar P474-1100RF

  • Page 1 OWNER'S MANUAL P474-1100RF Wireless Programmable Digital Thermostat Wireless Operation 7-Day Programmable 4 Time Periods Per Day Programmable Fan Large, Easy to Read Display Thermoglow Backlight Auto-Changeover MODE Dual Setpoint TOTALINE 2 Heat and 2 Cool Stages 2 Stage TOTALINE Heat & Cool...
  • Page 2: Table Of Contents

    Rules. Operation is subject to the following two conditions: (1) this device may not FCC ID MUH-T10013 cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. P/N P474-1100RF Replacement Components Division Carrier Corporation 03/07 Page 1...
  • Page 3: Front Panel

    Front Panel MODE TOTALINE Liquid Crystal Display with Thermoglow Up/Down Buttons Mode Button Fan Button Transmission Indicator Blinking Green = Communicating with the Receiver Page 2...
  • Page 4: Display

    Display I8 88 Program Setup Locked SuMoTuWeThFrSa AUTO Night Morning Evening Fan On Mode Indicators - Page 6 Selects the operational mode of the equipment. HEAT - Indicates the heating mode. COOL - Indicates the air conditioning mode. AUTO - Indicates the system will automatically changeover between heat and cool modes as the temperature varies.
  • Page 5 Display I8 88 Program Setup Locked SuMoTuWeThFrSa AUTO Night Morning Evening Fan On Morning, Day, Evening & Night icons - Pages 8-10 Indicates the day part of the time period program. Setup icon - Pages 12-14 Indicates the thermostat is in the setup mode. Fan On icon - Page 7 Indicates constant, continuous fan operation.
  • Page 6: Quick Start

    Quick Start Set the Clock and Go During Setup & Programming: Press the MODE button. MODE W h i l e h o l d i n g M O D E , Pressing the UP or DOWN press the FAN button for button will modify the two seconds to enter Setup flashing selection.
  • Page 7: Selecting The Heat Or Cool Mode

    Selecting the Heat or Cool Mode Select Mode by Pressing the MODE Button I2 00 Heating Only The HEAT setting indicates the temperature the room has to reach before the furnace will Press turn on to heat the room. MODE I2 00 Cooling Only The COOL setting indicates the...
  • Page 8: Basic Operation

    Basic Operation Selecting Your Desired Temperature (adjusting the setpoints) AUTO OR PROGRAM MODE Pressing the UP or DOWN button in Auto or Program mode will adjust both the heat and cool set temperatures simultaneously. Adjust the desired 12:00 set temperature with the AUTO buttons.
  • Page 9: Programming A Daily Schedule

    Programming a Daily Schedule (Unit # 1 only) Press the MODE button. While holding MODE, press the UP button for two seconds to enter time period programming*. MODE Use the Programming Worksheet on the back cover to help with this section. Select the day of week.
  • Page 10 Programming a Daily Schedule (Unit # 1 only) 8 00 Start Adjust the start time for Day. Press MODE 8 00 Adjust the cooling setpoint for Day. (35 - 99 ) Press MODE 8 00 Adjust the heating setpoint for Day. (35 - 99 ) Press MODE...
  • Page 11 Programming a Daily Schedule (Unit # 1 only) 6 00 Adjust the heating setpoint for Evening. (35 - 99 ) Evening Press MODE I0 00 Start Adjust the start time for Night. Night Press MODE I0 00 Adjust the cooling setpoint for Night.
  • Page 12 Programming a Daily Schedule (Unit # 1 only) The copy command becomes available after programming the entire previous day. Select Yes to copy the previous day’s program to the day displayed. If No is selected: If Yes is selected: Selecting Yes, then pressing MODE will copy the Press previous day’s program.
  • Page 13: Advanced Setup

    Advanced Setup 12:00 Press the MODE button and DO NOT Setup MODE release. RELEASE THE BUTTONS. Immediately press the MODE Continue holding the MODE MODE button again. While holding and FAN buttons for an add- the MODE button, press the itional seven seconds to FAN button.
  • Page 14 Advanced Setup Setup Select the House Code number. The Receiver must also use this same number for proper operation. (0 - 63) Press MODE Setup Select the Unit ID number. If more than 1 thermostat is used, each will need a different Unit ID number.
  • Page 15 Advanced Setup Setup Select backlight operation*: ON - Light continuously OFF - Light for 8 seconds after a button press Press MODE 0:00 Setup Adjust the programmable fan timer: 0 - 60 minutes 0:00 = off Press Fan On Note: Available only MODE on Unit ID #1.
  • Page 16: Advanced Setup Table

    Advanced Setup Advanced Setup Table Step # Description Range Factory Default Time of Day 24 hour 12:00 am Day of the Week Mo - Su Zoning System Off / On House Code 0 - 63 Unit ID Number 1 - 4 Deadband/Temp.
  • Page 17: About Advanced Features & Operation

    About Advanced Features & Operation CALIBRATION - Under normal circumstances it will not be necessary to adjust the calibration of the temperature sensor. If calibration is required, please contact a trained HVAC technician to correctly perform the following procedure. I2 00 I2 00 Press the MODE button at the same...
  • Page 18 About Advanced Features & Operation FACTORY DEFAULTS - If, for any reason, you desire to return all the stored settings back to the factory default settings, follow the instructions below. WARNING: This will reset all Time Period and Advanced Programming to the default settings.
  • Page 19 About Advanced Features & Operation KEYPAD LOCKOUT - To prevent unauthorized use of the thermostat, the front panel buttons may be disabled. To disable, or ‘lock’ the keypad, press and hold the MODE button. While holding the MODE button, press the UP and DOWN buttons together.
  • Page 20: Warranty

    Warranty Five-Year Warranty - This Product is warranted to be free from defects in material and workmanship. If it appears within five year from the date of original installation, whether or not actual use begins on that date, that the product does not meet this warranty, a new or remanufactured part, at the manufacturer’s sole option to replace any defective part, will be provided without charge for the part itself provided the defective part is returned to the distributor through a qualified servicing dealer.
  • Page 21 Programming Worksheet see page 8 DAY PERIOD START TIME COOL HEAT Morning Evening Night Morning Copy Mon Evening Night Morning Copy Tue Evening Night Morning Copy Wed Evening Night Morning Copy Thu Evening Night Morning Copy Fri Evening Night Morning Copy Sat Evening Night...
