Venstar T1100RF Owner's Manual

7-day programmable residential wireless thermostat up to 2-heat & 2-cool
Hide thumbs Also See for T1100RF:

Advertisement

Table of Contents

Enlarged version
Digital
Digital
Thermostat
Thermostat
Control up to 2 Heat & 2 Cool Stages
Full Range of Compatibility for Use on
Gas/Electric, HP, Electri and Hydronic Heat
7-Day Programmable
4 Settings/Day
Auto Changeover
5 minute Built-In Compressor Protection
Self-Prompting Programming w/ Copy
Full Electronic
Display Either F or C
Back-Lit Display
Keypad Lockout
Large Easy-to-Read Display
Programmable Fan
Use with most Air Conditioning & Heating Systems including: 1 or 2 Stage
Electric Cooling & 2 Stage Gas Heating, Heat Pump, Electric or Hydronic Heat.
OWNER'S
OWNER'S
MANUAL
MANUAL
residential
THERMOSTAT
T1 1 00RF
7-DAY
7-DAY
PROGRAMMABLE
PROGRAMMABLE
up to
2-heat
up to
2-heat
& 2-cool
& 2-cool
HEAT
COOL
Dual Setpoint w/ Adjustable Deadband
'O' or 'B' Terminal
Optional Power Supply (ACC0800)
Unique Features
Non-Volatile Memory
Wireless: Transmits up to 500 feet,
through walls and floors - 418 MHZ
will not interfere with other systems
Receiver capable of listening to up
to 4 thermostats
Thermostat capable of transmitting
to multiple receivers
Applications
No wires to run
Ideal for century old homes
Ideal for keeping the baby's room
the perfect temperature
Venstar Inc. 08/07
WIRELESS
HEAT
PUMP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T1100RF and is the answer not in the manual?

Questions and answers

Related Manuals for Venstar T1100RF

Summary of Contents for Venstar T1100RF

  • Page 1 Ideal for keeping the baby’s room Programmable Fan the perfect temperature Use with most Air Conditioning & Heating Systems including: 1 or 2 Stage Electric Cooling & 2 Stage Gas Heating, Heat Pump, Electric or Hydronic Heat. OWNER’S OWNER’S MANUAL MANUAL Venstar Inc. 08/07...

  • Page 2: Table Of Contents

    Rules. Operation is subject to the following T1100RF two conditions: (1) this device may not cause harmful interference, and (2) this FCC ID MUH-T10013 device must accept any interference received, including interference that may cause undesired operation. P/N T1100RF Venstar Inc. 08/07 Page 1...

  • Page 3: Front Panel

    Front Panel 6:03 AUTO MODE Liquid Crystal Display with Thermoglow Up/Down Buttons Mode Button Fan Button Transmission Indicator Blinking Green = Communicating with the Receiver Page 2...

  • Page 4: Display

    Display I8 88 Program Setup Locked SuMTuWThFSa AUTO Night Morning Evening Fan On Mode Indicators - Page 6 Selects the operational mode of the equipment. HEAT - Indicates the heating mode. COOL - Indicates the air conditioning mode. AUTO - Indicates the system will automatically changeover between heat and cool modes as the temperature varies.
  • Page 5 Display I8 88 Program Setup Locked SuMTuWThFSa AUTO Night Morning Evening Fan On Morning, Day, Evening & Night icons - Pages 8-10 Indicates the day part of the time period program. Setup icon - Pages 12-14 Indicates the thermostat is in the setup mode. Fan On icon - Page 7 Indicates constant, continuous fan operation.

  • Page 6: Quick Start

    Quick Start Set the Clock and Go During Setup & Programming: Press the MODE button. MODE W h i l e h o l d i n g M O D E , Pressing the UP or DOWN press the FAN button for button will modify the two seconds to enter Setup flashing selection.

  • Page 7: Selecting The Heat Or Cool Mode

    Selecting the Heat or Cool Mode Select Mode by Pressing the MODE Button I2 00 Heating Only The HEAT setting indicates the temperature the room has to reach before the furnace will Press turn on to heat the room. MODE I2 00 Cooling Only The COOL setting indicates the...

  • Page 8: Basic Operation

    Basic Operation Selecting Your Desired Temperature (adjusting the setpoints) AUTO OR PROGRAM MODE Pressing the UP or DOWN button in Auto or Program mode will adjust both the heat and cool set temperatures simultaneously. Adjust the desired 12:00 set temperature with the AUTO buttons.

  • Page 9: Programming A Daily Schedule

    Programming a Daily Schedule (Unit # 1 only) Press the MODE button. While holding MODE, press the UP button for two seconds to enter time period programming.* MODE Use the Programming Worksheet on the back cover to help with this section. Select the day of week.
  • Page 10 Programming a Daily Schedule (Unit # 1 only) 8 00 Start Adjust the start time for Day. Press MODE 8 00 Adjust the cooling setpoint for Day. (35 - 99 ) Press MODE 8 00 Adjust the heating setpoint for Day. (35 - 99 ) Press MODE...
  • Page 11 Programming a Daily Schedule (Unit # 1 only) 6 00 Adjust the heating setpoint for Evening. (35 - 99 ) Evening Press MODE I0 00 Start Adjust the start time for Night. Night Press MODE I0 00 Adjust the cooling setpoint for Night.
  • Page 12 Programming a Daily Schedule (Unit # 1 only) The copy command becomes available after programming the entire previous day. Select Yes to copy the previous day’s program to the day displayed. If No is selected: If Yes is selected: Selecting Yes, then pressing MODE will Press copy the previous day’s program.

  • Page 13: Advanced Setup

    Advanced Setup 12:00 Setup Press the MODE button and DO NOT MODE release. RELEASE THE BUTTONS. Immediately press the MODE Continue holding the MODE MODE button again. While holding and FAN buttons for an add- the MODE button, press the itional seven seconds to FAN button.
  • Page 14 Advanced Setup Setup Select the House Code number. The Receiver must also use this same number for proper operation. Press (0 - 63) MODE Setup Select the Unit ID number. If more than 1 thermostat is used, each will need a different Unit ID number.
  • Page 15 Advanced Setup Setup Select backlight operation:* ON - Light continuously OFF - Light for 8 seconds after a button press Press MODE 0:00 Setup Adjust the program- mable fan timer: 0 - 60 minutes 0:00 = off Press Fan On Note: Available only on Unit ID #1.

  • Page 16: Advanced Setup Table

    Advanced Setup Advanced Setup Table Step # Description Range Factory Default Time of Day 24 hour 12:00 am Day of the Week M - Su Zoning System Yes / No House Code 0 - 63 Unit ID Number 1 - 4 Deadband/Temp.

  • Page 17: About Advanced Features & Operation

    About Advanced Features & Operation CALIBRATION - Under normal circumstances it will not be necessary to adjust the calibration of the temperature sensor. If calibration is required, please contact a trained HVAC technician to correctly perform the following procedure. Press the MODE button twice. The thermostat temperature will be I2 00 Press...
  • Page 18 About Advanced Features & Operation FACTORY DEFAULTS - If, for any reason, you desire to return all the stored settings back to the factory default settings, follow the instructions below. WARNING: This will reset all Time Period and Advanced Programming to the default settings.
  • Page 19 ACC0800 RF power supply adaptor is used to power the thermostat and eliminate the need for replacing batteries each year. Use only the Venstar accessory ACC0800 for proper operation. LOW BATTERY WARNING - The two AA lithium batteries must be replaced at least once every 12 months to ensure proper operation.
  • Page 20 About Advanced Features & Operation BATTERY REPLACEMENT - To replace the batteries: Separate the thermostat from the backplate by pulling the top of the back- plate with one hand while pulling on the top corner of the thermostat with your other hand. Then turn the thermostat over to remove the batteries from the holder and replace with AA Lithium batteries.

  • Page 21: Warranty

    Warranty One-Year Warranty - This Product is warranted to be free from defects in material and workmanship. If it appears within one year from the date of original installation, whether or not actual use begins on that date, that the product does not meet this warranty, a new or remanufactured part, at the manufacturer’s sole option to replace any defective part, will be provided without charge for the part itself provided the defective part is returned to the distributor through a qualified servicing dealer.
  • Page 22 Programming Worksheet see page 8 DAY PERIOD START TIME COOL HEAT Morning Evening Night Morning Copy Mon Evening Night Morning Copy Tue Evening Night Morning Copy Wed Evening Night Morning Copy Thu Evening Night Morning Copy Fri Evening Night Morning Copy Sat Evening Night...
