- Page 1 I n s t a l l a t i o n a n d O p e r a t i o n M a n u a l Chargrill CH8300G CH8600G CHL8600G CH8900G CHL8900G CH8120G CHL8120G Date Purchased...
- Page 2 MANUFACTURED BY Moffat Limited Christchurch New Zealand INTERNATIONAL CONTACTS AUSTRALIA Moffat Pty Limited Web: www.moffat.com.au E.Mail: vsales@moffat.com.au Main Office: (tel) +61 (03) 9518 3888 (fax) +61 (03) 9518 3833 Service: (tel): 1800 622 216 Spares: (tel): 1800 337 963 Customer Service: (tel): 1800 335 315 (fax): 1800 350 281 CANADA...
-
Page 3: Table Of Contents
Contents CH8300G Gas Chargrill, 300mm wide. CH(L)8600G Gas Chargrill, 600mm wide. CH(L)8900G Gas Chargrill, 900mm wide. CH(L)8120G Gas Chargrill, 1200mm wide. Introduction ....................2 Specification ....................3 Model Numbers Covered in this Specification Gas Supply Requirements Dimensions ....................4 Installation ....................6... -
Page 4: Introduction
Introduction We are confident that you will be delighted with your WALDORF CHARGRILL, and it will become a most valued appliance in your commercial kitchen. To ensure you receive the utmost benefit from your new Waldorf CHARGRILL, there are two important things you can do. -
Page 5: Specification
” BSP Male Gas Connection * - Measure burner operating pressure at the manifold test point with one burner for CH8300G model or two burners for other models operating at full setting. Operating pressure is ex-factory set and not to be adjusted, apart from when converting between gases, if required. (Refer to ‘Gas Conversion’... -
Page 6: Dimensions
Dimensions NOTE: The CH8300G are available in Bench Model (- B) Option Only. CH(L)8300G-B CH(L)8600G-B CH(L)8900G-B CH(L)8120G-B... - Page 7 Dimensions CH(L)8600G-LS CH(L)8900G-LS CH(L)8120G-LS = Rating Plate Location for all models.
-
Page 8: Installation
Waldorf Chargrills are designed to provide years of satisfactory service, and correct installation is essential to achieve the best performance, efficiency and trouble-free operation. This appliance must be installed in accordance with National Installation Codes and in addition, in accordance with relevant National / Local Codes covering gas and fire safety. -
Page 9: Clearances
Left / Right Hand Side 200mm Rear 150mm Assembly Bench Models (CH8300G Model Only) Check all feet are securely fitted. Bench Models (CH8600G / CH8900G / CH8120G Models Only) Check all feet are securely fitted. Adjust feet to make the Chargrill steady and level. -
Page 10: Fitting Adjustable Feet / Rear Rollers To Leg Stand Units
Installation Fitting of Adjustable Feet / Rear Rollers to Leg Stand Units. Warning TO PREVENT EQUIPMENT DAMAGE AND RISK OF INJURY REMOVE ALL CHARGRILL CASTINGS BURNERS AND OTHER REMOVABLE ITEMS PRIOR TO FITTING THE LEG STAND Remove grates, griddle plates and radiants from chargrill. -
Page 11: Location
NOTE: ALL GAS FITTING MUST ONLY BE CARRIED OUT BY A QUALIFIED PERSON. Waldorf Chargrills do not require an electrical connection, as they function on gas supply only. It is essential that gas supply is correct for chargrill to be installed and that adequate supply pressure and volume is available. -
Page 12: Commissioning
Installation Commissioning Before leaving new installation; a. Check the following functions in accordance with operating instructions specified in 'Operation' section of this manual. Light the Pilot Burner. Light the Main Burner. Check Low Fire Burner Operation. Check High Fire Burner Operation. b. -
Page 13: Operation
Operation Operation Guide Caution This appliance is for professional use and is only to be used by qualified persons. Only authorised service persons are to carry out installation, servicing or gas conversion operations. Components having adjustments protected (e.g. -
Page 14: Lighting Pilot Burners
Operation Lighting Pilot Burners Warning 350°C HEN A SOLID GRIDDLE PLATE IS USED S SURFACE TEMPERATURE CAN REACH OVER WHEN THE APPLIANCE IS OPERATED AT FULL HEAT SETTING NOTE: All chargrill models incorporate a push button piezo ignition system for each individual pilot burner. -
Page 15: Griddle Plate Fitting
Operation Griddle Plate Fitting. The following options of griddle plate (Fig 4) can be fitted to the chargrill:- (A) Griddle Plate 300mm or 450mm wide - (cast). (B) Griddle Plate 300mm or 450mm - (fabricated). NOTE: If fitting a Griddle Plate to your Fig 4 chargrill, remove the required cast... -
Page 16: Cleaning And Maintenance
Cleaning and Maintenance General Caution Always turn ‘Off’ the gas supply before cleaning. This appliance is not water proof. Do not use water jet spray to clean the interior or exterior of this appliance. Clean the chargrill regularly. A clean chargrill looks better, will last longer and will perform better. Carbonised grease on the cooking surface or on the chargrill will hinder the transfer of heat from the cooking surface to the food. -
Page 17: Weekly Cleaning
Cleaning and Maintenance Weekly Cleaning NOTE: If chargrill usage is very high, we recommend weekly cleaning is carried out more frequently. Ensure protective gloves are worn during cleaning. DO NOT use harsh abrasive detergents, strong solvents or caustic detergents as they will damage chargrill and burners. -
Page 18: Periodic Maintenance
Cleaning and Maintenance Main Burners a. Clean main burners with hot water, a recommended detergent solution and a scrubbing brush. Ensure any excess water is removed from inside the burners. Dry all burners thoroughly with a dry cloth. Fig 9 b. -
Page 19: Fault Finding
Fault Finding This section provides an easy reference guide to the more common problems that may occur during operation of your equipment. The fault finding guide in this section is intended to help you correct, or at least accurately diagnose problems with your equipment. Although this section covers the most common problems reported, you may encounter a problem not covered in this section. -
Page 20: Gas Conversion And Specifications
Gas Conversion and Specifications Conversion Procedure Caution Ensure Appliance is isolated from gas supply before commencing servicing. NOTE: Gas conversions should only be carried out by qualified persons. All connections must be checked for leaks before re-commissioning the appliance. ... -
Page 21: Gas Specifications
(20, 30 / 37), (20, 30). 2H3P 2H3B/P Flue Type: A Natural Gas LP Gas (Propane / Butane) (G20) (G30 / G31) CH8600G CH8600G CH8300G CH8900G CH8300G CH8900G CH8120G CH8120G Main Burner Injectors 2.70mm 1.65mm Pilot Burner Injectors 0.35 0.45 0.25... -
Page 22: Replacement Parts List
MAIN INJECTOR - 2.70mm - NAT GAS 037165 MAIN INJECTOR - 1.65mm - LPG (PROPANE / BUTANE) 037155 MAIN INJECTOR - 1.55mm - BUTANE 227384 KNOB WALDORF 8mm GAS PF 229531 DRIP TRAY 013908 SPACER FOOT ASSY CHARGRILL CH86000G / CH8900G / CH8120G - PARTS LIST Part No. -
Page 23: Replacement Parts
Replacement Parts Gas Regulators Gas Regulators Gas Type Model Part No. Description CH8300G 228533 ½” BSP F/F Convertible. Nat. Gas CH8600G CH8900G 228531 ¾” BSP F/F Convertible. Butane CH8120G Gas Conversion Kits Gas Type to Convert to Models Nat. Gas...
