ATTACHING THE AIR CLEANSING AND DEODORIZING FILTERS

! CAUTION
Cleaning and maintenance must be carried out only by qualified service personal. Before cleaning,
stop operation and switch off the power supply.
1
Open the front panel.
G Pull up the front panel by holding it at both sides
with both hands.
2
Remove the filter.
G Push upward to release the claws and pull out the
filter.
3
Attaching the Nano Titanium filters to the filter.
G Attach the Nano Titanium filters to the frame by
gently compress its both sides and release after
insertion into filter frame.
!
Do not bend the Nano Titanium
filter as it may cause damage to
the structure.
4
Attach the filters.
G Attach the filters by ensuring that the surface written
"FRONT" is facing front.
G After attaching the filters, push the front panel at
three arrow portion as shown in figure and close it.
NOTE
G In case of removing the Nano Titanium filters, please follow the above procedures.
G The cooling capacity is slightly weakened and the cooling speed becomes slower when the Nano
Titanium filters are used. So, set the fan speed to "HIGH" when using it in this condition.
G Nano Titanium filters are not washable and can be use in 1 year time. Type number for this air
cleansing filter is <SPX-CFH15>. Please use this number for ordering when you want to renew it.
G Do not operate the air conditioner without filter. Dust may enter the air conditioner and fault may occur.
CAUTION
– 20 –
