ATTACHING THE AIR CLEANSING AND DEODORIZING FILTERS

! CAUTION
Cleaning and maintenance must be carried out only by qualified service personal. Before cleaning,
stop operation and switch off the power supply.
1
Open the front panel.
G Pull up the front panel by holding it at both sides
with both hands.
2
Remove the filter.
G Push upward to release the claws and pull out the
filter.
3
Attaching the air-cleansing & deodorizing filters to
the filter frame.
G Attach the air-cleansing & deodorizing filters to the
frame by gently compress its both sides and release
after insertion into filter frame.
!
Do not bend the air-cleansing &
deodorizing filter as it may cause
damage to the structure.
4
Attach the filters.
G Attach the filters by ensuring that the surface written
"FRONT" is facing front.
G After attaching the filters, push the front panel at
three arrow portion as shown in figure and close it.
NOTE
G In case of removing the air-cleansing & deodorizing filters, please follow the above procedures.
G The cooling capacity is slightly weakened and the cooling speed becomes slower when the air-cleansing
& deodorizing filters are used. So, set the fan speed to "HIGH" when using it in this condition.
G Air-cleansing & deodorizing filters are not washable and can be use in 1 year time. Type number for
this air cleansing filter is <SPX-CFH11>. Please use this number for ordering when you want it.
G Do not operate the air conditioner without filter. Dust may enter the air conditioner and fault may occur.
CAUTION
– 16 –
