NAMES AND FUNCTIONS OF EACH PART

INDOOR UNIT
OUTDOOR UNIT
MODEL NAME AND DIMENSIONS
MODEL
RAS-19SH4
RAC-19SH4
Air filter
To prevent dust from coming into the indoor unit.
(Refer page 21)
Front panel
Indoor unit indicators
Light indicator showing the operating condition.
(Refer page 5)
Horizontal deflector
(Air Outlet)
(Refer page 16)
Remote controller
Send out operation signal to the indoor unit. So as to
operate the whole unit.
(Refer page 6)
DRAIN PIPE
Condensed water drain to outside.
CONNECTING CORD
AIR INLET (BACK, LEFT SIDE)
AIR OUTLET
WIDTH (mm) HEIGHT (mm)
780
850
– 4 –
G Vertical deflector
DEPTH (mm)
210
280
298
650
